NOTE: Although the rim and backboard are very strong, they are NOT designed for hanging. The rim is designed to safely
flex 2" at the front of the rim. NEVER HANG ON THE RIM – THIS WILL VOID YOUR WARRANTY. DO NOT ADJUST
THE TENSION ON YOUR SPRING. Visit
Mini Pro 1.0 Contents:
(1) Backboard Assembly
(1) Rim Assembly
(1) Net
(2) 1/4" x 1" x 12" Rubber Frame Pads
(1) Upper Bracket
(1) Mini Rubber Basketball
Caring for your backboard:
Your backboard is made from polycarbonate which is known for its durability and break resistance. Wash your backboard
with mild soap and water. Use a clean soft cloth, applying only light pressure. Rinse with clear water and dry by blotting
with a damp cloth or chamois. Do not use window cleaning sprays, kitchen scouring compounds, or solvents.
Assembly Instructions:
These assembly instructions are for the Mini Pro 1.0 hoop set. To simplify assembly, the backboard and rim are pre-
assembled. You will need a Phillips head screwdriver, a 3/8" wrench or an adjustable wrench, a drill with 3/16" bit, a
pencil, and it is also recommended, but not necessary, you have stud finder and a level.
If you have questions during assembly, please contact us at 888-564-1082 or service@justintymesports.com. You can
find video of the assembly process at http://www.justintymesports.net/installation
I. Upper Bracket
1.
Install the Upper Bracket using (2) of the #10-24 x
1/2" Frame Screws and Locknuts.
Note: The Upper Bracket attaches to the inside of the
Frame. The tab of the bracket should point up, but you
may have it point down if you wish. This will adjust
measurements when you go to mount the hoop.
MINI PRO 1.0 BASKETBALL HOOP
http://www.justintymesports.net/faq/
for full details of your warranty.
(2) #10-24 x 1/2" Frame Screws
(2) #10-24 Self Locking Nuts
(4) 1/4"-20 x 1" Rim Screws
(3) 1/4" x 2" Bracket Screws
(3) 1/4" Washers
Figure 1
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for JustinTymeSports MINI PRO 1.0
- Page 1 Assembly Instructions: These assembly instructions are for the Mini Pro 1.0 hoop set. To simplify assembly, the backboard and rim are pre- assembled. You will need a Phillips head screwdriver, a 3/8" wrench or an adjustable wrench, a drill with 3/16” bit, a pencil, and it is also recommended, but not necessary, you have stud finder and a level.
- Page 2 Washers provided (screws are long enough to mount through ½" drywall). You can use bar soap on the bracket screws as a lubricant so the screws will turn in easier. JustinTymeSports, LLC Grand Rapids, MI 49548 www.justintymesports.net © Copyright 2016...
