Summary of Contents for Fume Extraction Systems X-Tract Series
- Page 1 Fume Extractor Operations Manual Applicable to the X-Tract Fume Extractors series 200 & 500...
-
Page 2: Table Of Contents
Operations Manual Contents Safety .................................. 3 Safety Symbols ............................3 OSHA ................................4 General Situation ............................6 Installation ................................. 7 Working Principle ............................7 Usage Method..............................8 Maintenance ..............................9 Common faults ............................9 Warranty ................................. 10 Product Certification ............................ 11... -
Page 3: Safety
Operations Manual Safety Safety Symbols This sign indicates that there is a danger of electric shock. Electric shock is likely to cause casualties. This sign indicates caution or warning, indicating that you should pay attention to some problems. This sign indicates moisture resistance, and may lead to electrical accidents when neglected. -
Page 4: Osha
Operations Manual OSHA Personal safety precautions 1.1 Electrical Single phase or three-phase power supplies are used in the system, this is potentially dangerous to humans. Care is to be taken when working on the system. a. Check whether the terminals are in good contact with each other regularly. b. - Page 5 Operations Manual Operation Notes 1. To achieve the purpose of mobile devices, Do not pull the suction arm forcibly. 2. Please turn it off when you move the device, Make sure the power cord and the compressed air line are of sufficient length. 3.
-
Page 6: General Situation
Operations Manual General Situation The X-Tract series of movable welding fume purifier is an economical and efficient product for cleaning and dedusting. The basic structure of the equipment consists of the box, fan, filter element, suction arm, electrical control and other parts, The product is simple and practical, stable in performance and convenient for use and maintenance. -
Page 7: Installation
Operations Manual Installation Inspiratory arm After installing the sealing ring Installation of inspiratory arm Seal ring Usually installed in equipment Connect the air intake Working Principle The welding dust first passes through the protective net of the dust suction port, to intercept sparks and other large particles suspended, and then dust gas into the box, filtered by the filter core. -
Page 8: Usage Method
Operations Manual Usage Method 1. Starting method Press the start-stop button, The button is locked, At the same time, the indicator light is on. 2. Stopping method Press the start-stop button again, The button is released, Meanwhile, the indicator goes out. 3. -
Page 9: Maintenance
Operations Manual Maintenance Common faults The whole machine does not work and the indicator light is not on 1. Check that the power plug is in place 2. Open the machine housing, find the fuse, replace the fuse core The power indicator is on and the fan does not start 1. -
Page 10: Warranty
Operations Manual Please clean the dust on the surface of the filter element periodically. It can be cleaned manually with compressed air or washed by water. If not cleaned in time, it will cause damage to the fan impeller and motor. This damage is not in the scope of quality guarantee. -
Page 11: Product Certification
Operations Manual Product Certification... - Page 12 Operations Manual...
