Summary of Contents for FRESH AERO FlightLights
- Page 1 FRESH AERO FlightLights LED Taxi/Landing/Recognition Light for Sonex, Van’s RV & other Homebuilt Aircraft Manual Steelebrook Group...
-
Page 2: Features Include
Taxi/Landing/Recognition Light for Sonex, RV & Other Homebuilt Aircraft Thank you for purchasing the Fresh Aero LED Taxi/Landing/Recognition (TLR) Light for Sonex, Van’s RV and other homebuilt Aircraft. We’re confident you’ll be pleased with this innovative LED TLR light specifically designed for your homebuilt and sport aircraft. -
Page 3: Other Legal Notices
Important Notice: If you have questions regarding the installation or operation of the Fresh Aero TLR Light, or just need another manual, please call or write Fresh Aero Aviation at the contact numbers or e-mail address on the last page of this Guide. Manuals are also available on our web site in PDF format at www.freshaero.com. - Page 4 Copyright 2015 Fresh Aero reserves all rights to this manual including the right to alter the features and contents of this publication without obligation or advance notice.
- Page 5 Fresh Aero FlightLights LED Taxi/Landing/Recognition Light for Sonex, RV & Other Homebuilt Aircraft Installation Identification Photos Photo 1 The holes in the ends of the brackets just attach to adjacent wing ribs at a convenient location forward of the spar (or inside of a cowling). The brackets are custom fabricated to fit your aircraft and layout templates are included.
- Page 6 Read and understand all the proceeding safety precautions and warnings before installing the TLR Light. FAA Approval Information (USA Installations): The Fresh Aero TLR Light is designed and manufactured for homebuilt (experimental) aircraft. If you install this product on a certified aircraft, you will need at least a FAA field approval to be completely legal and airworthy.
- Page 7 Fresh Aero FlightLights LED Taxi/Landing/Recognition Light for Sonex, RV & Other Homebuilt Aircraft Installing the Taxi/Landing Light … continued 1.3 Locate the Bracket Mounting Template at the back of this manual and cut out the center section on the outside red line. Locate the template cutout on the rib with the rib flange facing away and center the template with the forward line aligned with the flange forward vertical end.
- Page 8 Fresh Aero FlightLights LED Taxi/Landing/Recognition Light for Sonex, RV & Other Homebuilt Aircraft Installing the Taxi/Landing Light … continued 1.9 Mount light box between the brackets and hand start the the included 5 mm hex screws and lock washers in the holes in the box. Tighten by hand as much as possible. “Aim” light box to the desired position using the rotational adjustment for up and down positioning.
- Page 9 Please consider the following additional “hints & tips” for installing these lights on finished aircraft. If you purchased the Fresh Aero Lens Mounting Kit, just follow the procedures in our manual that was included with your lens kit. If the lens kit was purchased from another source, follow the instructions included with that kit.
- Page 10 (337 form) to be completely legal and airworthy. Please talk to your local FAA Flight Standards Office for more information. Thanks again for purchasing the Fresh Aero FlightLights TLR Light. We have tried to make this light and manual as user friendly as possible. We always welcome your comments and suggestions for future revisions.
