Instruction Manual

Sanctuary Adjustable Massage Table

Model # 8910b

Table of Contents

Need help?

Do you have a question about the 8910b and is the answer not in the manual?

Questions and answers

Summary of Contents for Minerva 8910b

Page 1 Instruction Manual Sanctuary Adjustable Massage Table Model # 8910b...
Page 2 Important Warning Improper use of this device may cause injury. Be sure to read all operating instructions before use. Check the padding and upholstery when unpacking the table. Do not use it if there are damaged signs. (Our warranty excludes damage caused by improper set-up, accident, abuse, or use for unintended purpose.) Weight limit (including client and accessories): Max Working Capacity: 1000 lbs/454kg.
Page 3 (Fig. 1) (Fig.2) (Fig.3) (Fig.4) Step 2: Unfold the legs and tighten the legs with provided bolts and nuts (Part C, E and F) at each corner by socket wrench and open-end wrench (Part A and B). (Fig.2/3) Ensure each nut and bolt and washer on table is installed properly. (Fig.4) Step 3: Place the short side ply-woods into its related side slots and make sure they are installed into the inner slot correctly and tightly.
Page 4 Step 7: Inspect the assembly carefully and set your table up. (Fig. 15) Check above instructions term by term to ensure every nut, bolt and washer on table is installed correctly and tightens every nut and screw again. When setting up your table, it’s forbidden to carry the table top when turning over the table.
Page 5 Instruction for Use Operating the manually Pneumatic-lift table top Kaiser-Tilt and Kaiser-Deluxe series tables come with an adjustable backrest and a variable height leg rest which are controlled by gas pump. The switch is riveted at both side of the table. Do not sit on the elevated backrest or leg rest.
Page 6 The Side Armrests Kaiser-Tilt and Kaiser-Deluxe series tables come with Side Armrests which are removable to provide complete access for the therapist and allow a client to get on and off the table during the massage process. Our stationary massage tables are equipped with optional Leveled Side Armrests and Leveled Side Armrests as below.
Page 7 How to Use the Adjustable Face Cradle Put the tubular arms of the face cradle into the outlets in the end of the table. (Fig.31) Position the lock lever so that it extends out horizontally with the ridges on top. (Fig.32) Adjust the face cradle to your desired position and remove the lever down wards to lock the face cradle into place.
Page 8 All warranties set forth above, no other expressed or implied warranties or guarantees any more, are the sole and exclusive warranties we provided. Thank you for purchasing your massage table from Minerva Beauty! 390 Jim Daws Rd. | Monroe, GA 30655 | 888-332-0123 | sales@minervabeauty.com...
