- Page 1 WATER MANAGEMENT SYSTEM INSTALLATION AND USER MANUAL FOR WMS-6 OUTDOOR Amyuni Water Systems WMS-6 Outdoor Water Management System...
-
Page 2: Typical Applications
WATER PUMPS FROM STARTING, …) The Water Management System or WMS devices are designed to provide maximum flexibility. The four outputs of WMS-3 or eight outputs of WMS-6 can be programmed to handle different types of situations including but not limited to: ... -
Page 3: Typical Installation Diagram
WMS-6 Outdoor Pump Controller Controls Pressure Switch Garden Irrigation System Sprinkers, Drip lines, ... 200L Pressure Tank Mains Water Supply Mains Supply Valve Water Level Probe 10 000L Underground Tank Water Well Amyuni Water Systems WMS-6 Outdoor Water Management System... - Page 4 THREE INPUT SWITCHES CAN BE CONNECTED TO FLOATING DEVICES OR GENERAL- PURPOSE ON/OFF SWITCHES MEASURE QUANTITY OF WATER AVAILABLE IN WATER DEPOSIT AND ADJUST THE SCHEDULES ACCORDINGLY [REQUIRES THE OPTIONAL WATER DEPTH MEASUREMENT MODULE] Amyuni Water Systems WMS-6 Outdoor Water Management System...
- Page 5 60 Watts or about 2.5 Amperes. Examples of AC devices: Electric valves used in irrigation systems Garden lights working on low AC voltage Electric water valves Amyuni Water Systems WMS-6 Outdoor Water Management System...
- Page 6 STEP 1: The WMS-6 Outdoor device is designed to be wall mounted in an indoor or outdoor location. Remove the transparent cover and use two to four of the holes in the corners to mount the device:...
- Page 7 Mechanical relay connectors Two groups of electronic relay outputs WMS-6 Top View with Cover Removed STEP 4: Plugin the WMS power adapter and connect all electrical devices to their power source then proceed to programming the device. Amyuni Water Systems...
- Page 8 All the settings below are saved in permanent memory that will not get erased even if the device is disconnected for a long period of time. MAIN CONFIGURATION PAGE - STATUS Amyuni Water Systems WMS-6 Outdoor Water Management System...
-
Page 9: Output Relays
Apart from showing the status of each valve, you can also manually turn On or Off each valve for a specific duration. In order to do that, set the duration in the “Manual Override” selection list, then click on the corresponding button to turn the valve On. OUTPUT RELAYS Amyuni Water Systems WMS-6 Outdoor Water Management System... -
Page 10: Input Switches
Same as for the output valves, show you the status of the 1 relay on the WMS-3 or 2 relays on the WMS-6. These can also be renamed in the Settings page. You can also turn On or Off the relays manually by clicking on the corresponding button. -
Page 11: Date And Time
Each configuration section contains an “Apply” button to confirm the change in settings relative to that section only. Make sure you click on “Apply” before moving to another section otherwise the section’s settings will not be saved. DATE AND TIME Amyuni Water Systems WMS-6 Outdoor Water Management System... -
Page 12: Programming Page
“Water Pump” to indicate that the relay activates the water pump. PROGRAMMING PAGE The WMS devices can store up to 16 different programs which are configured through the programming page: Amyuni Water Systems WMS-6 Outdoor Water Management System... -
Page 13: New Program
The program will only run on odd numbered days of the month Even Days The program will only run on even numbered days of the month Start Time Program start time in 24-hour format Duration Amyuni Water Systems WMS-6 Outdoor Water Management System... - Page 14 Output Status Set the status of each of the 4 outputs (WMS-3) or 8 outputs (WMS-6) when the program is running. Note that more than one output can be active at the same time. In case of sprinkler systems, you need to make sure that the input water pressure is sufficient for all the active outputs.
-
Page 15: Administration Page
Administration Page Device Security A password can be set to disable unauthorized access to the device through WiFi. If the device is connected to a router, it remains accessible through the network. Amyuni Water Systems WMS-6 Outdoor Water Management System... -
Page 16: Electrical Specifications
0.5 Amps @ 27VAC for each output (O1 to O6) Maximum continuous current at relay outputs Normally Open (NO) Connections: 10 Amps @ 230 Volts Normally Closed (NC) Connections: 3 Amps @ 230 Volts Amyuni Water Systems WMS-6 Outdoor Water Management System...
