Summary of Contents for DAccess Security Systems ML10 Series
- Page 1 ML10/PL10 Series DIY Smart Lock With Fingerprint Security Make your life easy and safe ML10/PL10 series is a smart lock with embedded fingerprint recognition technology. It is DIY design, which can replace knob lock easily and quickly. You even can do it by yourself.
- Page 2 Safe and Convenient Forgot or lost your key? In a hurry? Can’t remember your password? Your finger is your key.
- Page 3 Rugged, sleek and compact design Zinc alloy metal casing Decorated with acrylic panel or stainless steel panel...
- Page 4 Touch to Open With infrared sensor detection, no need to press power button.
- Page 5 Idle handle design When the door is locked, the clutch is in idle position, the handle will be turned. However, the door will remain locked. This is crucial for the prevention of a forcible entry.
- Page 6 Reversible design Handle and strike are reversible design, which fits all door open direction right outward left outward right inward left inward...
- Page 7 Optional lock body American standard single latch German standard mortise with one latch and one deadbolt - Backset is adjustable (60mm or 70 mm) - Turn handle upward to lock the deadbolt for more security 93mm 104mm 70mm 60mm 10.50mm 15.mm...
- Page 8 Easy to replace Backset is 60 mm (2 3/8 inch) or 70 mm (2 3/4 inch), which can replace knob lock perfectly. There is no risk to damage the door.
-
Page 9: Easy To Install
Easy to install Easy installation with just a screwdriver- no wiring required Installation steps are showed with pictures... -
Page 10: Easy To Use
Easy to use QUICK START GUIDE Add Delete Admin-10 Normal User-60 Temporary User-20 QUICK START GUIDE Power-on Operation: Touch the infrared sensor hole on the inner side of ngerprint sensor holder. Register First Admin: Touch the infrared sensor hole to power lock ->... - Page 11 Quality is reliable moisture-proof Keep testing clutch motor 60000 times PCB surface with epoxy encapsulated is moisture-proof design 1 year warranty service...
-
Page 12: Low Battery Warning
Low battery warning If the lock is in low battery,LED and buzzer will make the indication. The door can be opened 100 times since you are notified of low battery. You have enough time to change the battery. Mechanical key and 9V battery can be used for emergency unlocking if the batteries are completely died. -
Page 13: Normal Open Mode
Normal Open Mode When you host a social event, it is inconvenient if people frequently enter and leave. In this case,you can set the lock to Normal Open mode, and no need to unlock. Just enjoy your party ! - Page 14 PL10 / PL10D If you need the same features with lower price PL10/PL10D with rugged casing of ABS material is the best choice !
-
Page 15: Specifications
Specifications Model Name ML10 PL10 ML10D PL10D Material Zinc Alloy Zinc Alloy Lock Body American standard single latch German standard morise with one latch and one deadbolt Backset 60mm or 70mm(adjustable) 70mm Admin -10 User Capacity Normal User - 60 Temporary User - 20 Operating Temperature 0-45°C... - Page 16 DAccess Security Systems Pvt. Ltd. Office No.05, 3rd Floor, Revati Arcade-||, Sr. No.-1/1A/1/1/7/3, Opposite to Kapil Malhar Society, Baner, Pune -411048, Maharashtra, India. Phone No.: +91 20 41241256 / 41201237, +91 93702 99634 Email: info@daccess.co.in | Website: www.daccess.co.in...
