- Page 1 CROMA512REC DMX 512S Recorder User Manual Version:3.1 02 APR 2020 This product manual contains important information about the safe installation and use of this product. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
- Page 2 DMX RECORDER SERIES I. Product Introduction This product is a 512S Recorder. Suitable applications include small disco, Club, Private party and other small places. 512S Recorder record chases in advance so that people can use it easily. 512S Recorder cannot make program alone. All programs should be made by other DMX 512 consoles and then record to it.
- Page 3 DMX RECORDER SERIES IV. Contents in the package 512S Recorder * AC Adaptor * User Manual V. Control Panel Instruction Front panel MENU Number Description Function USB port USB disk backup and download LCD display Display current function or menu data MENU MENU button is used to select menu interface This button is used to select item of submenu...
- Page 4 DMX RECORDER SERIES Number Description Function Input Voltage AC 88～256V 50/60Hz Used to send DMX512 signal to the fixture DMX OUT RS232 RS232 connect central control PANEL/CENTRAL Rj45 connector, connecting central control or touch panel AUDIO AV audio input and adjust sensitivity of audio AUDIO &...
- Page 5 DMX RECORDER SERIES 7.Reset—Factory data reset Press MENU button to select menu “7. Reset”, press ENTER button to enter it. Press UP/DOWN button to select Yes/No and press ENTER to confirm. VII. Menu Vocabulary Menu vocabulary Menu vocabulary Number Number Play stopped File error Select an index...
- Page 6 DMX RECORDER SERIES IX.AUTO PLAY 1. Use signal cable to connect output interface of Recorder and intelligent light. 2. Power on Recorder and intelligent light. 3. Press MENU button to select menu “2.play mode”, press ENTER button and then press UP/DOWN button to select one of auto mode, such as “multi”, “cycle”...
- Page 7 DMX RECORDER SERIES 2.Click the effect button of panel to playback the chase of Recorder. 3.RJ45 network port line sequence: Pin 1：si g nal - P in 2：s ig n al + Pin 3：GN D P in4：5 V P i n 5：5 V Pin 6：GN D P in7：N C P i n 8：NC...
- Page 8 DMX RECORDER SERIES Example: (1) Play CHASE 1 and then stop. ： The command code issued by the central control is 9A 00 00 01 01 00 1C 9A 00 00 00 01 00 1B 9A 00 00 01 01 00 1C 9A→...
