Melec ML-ZIG-010D Manual

ML-ZIG-010D
Product information
The ZIG-010D dual output solution allowS you to give commands via the TUYA app and put out
DALI signal or 0/1-10V signal which can be used for dimming items such as the NOX floods or DALI
fittings. Fully compliant to DALI DT6 and DT8 standards and can work in conjunction with the R4
if required.
TECHNICAL INFORMATION
Input Output, DALI
Power Signal DALI PS
current
110-240Vac Zigbee Max.
2.4Hxz 50mA
Rated impulse withstand voltage
IP rating
Overvoltage category
PTI
Glow wire temperature
Micro-environment pollution degree
Type and/or connection of switches
Contiguration of switching device
Test conditions (between contact and actuator speed)
Test conditions functional or simulated
Endurance method "a" or "b"
36MM
*Total power consumed including driver
** Average life is calculated on expected average lifespan
T. 1300 222 445 | www.melec.com.au
Data subject to change, please visit our website for up to date specifications: melec.com.au
Output,
0/1-10V
DALI current Current
consumption
Max. 4mA Max. 20mA
2500V
IP20
II
175V
750°C
pollution degree 2
1 pole, 1 way
Electronic switch with SD with parallel mechanical switching device
Switches having a contact making and breaking speed independent from the speed of actuation.
Simulated
b
95MM
85MM
For further information about our Warranties please go to: melec.com.au/legal/warranties
Output,relay
Switching Current Operating
temperature
voltage
110-240vac Resistive -20-+50°c
5A
LED
1.6A
20.5MM
Environment Others
Relative Dimensions
humidity
8%-80% 80x36x20.5mm
