- Page 1 Installation Operation Maintenance Purifier Plus™ Purge Emission Collection Canister PRG-IOM-3E...
-
Page 2: Table Of Contents
Table of Contents General Information......... 3 Model Number Description . -
Page 3: General Information
PRP = Purge Plus Digit 4 - Development Sequence A = First Development Digit 5, 6 - Future Use Digit 7 - Tank Origin 0 = Trane 1 = Out source Digit 8 - Tank Type N = New R = Regenerated... -
Page 4: Warnings And Cautions
General Information Warnings and Cautions Warnings and Cautions appear at appropriate locations throughout this manual. Read these carefully. WARNING CAUTION Indicates a potentially hazardous Indicates a potentially hazardous situation which, if not avoided, situation which, if not avoided, could result in death or serious may result in minor or moderate injury. -
Page 5: About This Manual
“filters” the refrigerant from the purge exhaust and personal injury or death. holds it for recovery at a later date. Proper application of a Trane Purifier Purge and a Purifier Plus collection canister can result in “near zero” refriger- ant emissions due to the purging of non-condensable from low pressure chillers. - Page 6 General Information Field supplied items • (3) 3/8” Flare nuts • 3/8” OD refrigeration-grade copper tubing (Length determined by location of canister) • (4) ¼” Bolts (Use when canister is bolted directly to chiller such as Option #3 in Figure 2). Figure 1 —...
-
Page 7: Installation
Installation Initial Installation WARNING Do not pressurize from an external The mounting location of the Purifier Plus™ canister is determined by: source. Pressurizing tank from an 1. The style of chiller external source could cause tank to rupture, resulting in death or 2. - Page 8 Installation Table 1: Purifier Purge™ Pump Out Minutes Chiller Refrigerant Model R113 R123 PRGA 5000 1500 2000 PRGB 5000 3000 4000 PRGC 5000 3000 4000 Figure 4 — Change Canister Label Figure 5 — Typical Unit Nameplate Change Purifier Plus™ Canister Minutes Order No.
-
Page 9: Tank Replacement
The contents of this canister must date on line “B” of the Change Purifier Plus™ Canister label (Figure 4) the be reclaimed at a Trane authorized facility. Disposal of the canister or carbon is saturated and the canister needs to be replaced. -
Page 10: Return Instructions
Trane regeneration site. The replacement Purifier Plus shipping box can be reused to ship, free of charge, the saturated Purifier Plus canister back to Trane for regeneration. Upon receipt of the Purifier Plus canister at the Trane regeneration site, the tank will be regenerated and the refrigerant in the tank will be recovered. -
Page 11: Maintenance
Maintenance Caution: Normal maintenance is required for the canister. Keep the canister clean and dry in a corrosive free environment. DO NOT PAINT THE TANK. The performance of the carbon is Specifications tracked by weight. Any added weight will invalidate the tank •... -
Page 12: Data Sheet
Purge Model Number Purge Serial Number (or N/A) Send Tank & Data Sheet (using supplied pre-paid label) to: Trane Purge Cylinder Regeneration Program 350 Sunpac Court Henderson, NV 89015 See PRG-IOM-3E for details on tank removal, packaging, shipping, and installation. - Page 13 La Crosse Aftermarket Business Unit 3600 Pammel Creek Road La Crosse, WI 54601 Since The Trane Company has a policy of continuous product improvement, it reserves the right to change www.trane.com design and specifications without notice. An American Standard Company...
