- Page 1 USB 3.0 to Dual HDMI/DisplayPort Adapter User Manual The adapter built-in DisplayLink DL-6950 chip, if you have any issue, please visit the website: https://support.displaylink.com/ for more information.
- Page 2 PRODUCT SUMMARY The adapter built-in DisplayLink DL-6950 chip. DL-6950 is the next generation universal docking solution from DisplayLink. Based on the industry leading DL3 compression technology DL-6950 extends the benefits of low latency, pixel perfect, graphics to high resolution monitors. Plug it in and it works. The adapter integrates a USB 3.0 device interface, DL3 codec, two DisplayPort++ (dual mode) interfaces, or two HDMI 2.0 interfaces, GbE, and audio on one SoC.
- Page 3 Double click on the driver file to start the installation process. Follow the steps to complete the installation. Once the installation is complete, please reboot your computer. NOTE: 1. If you are working on a company computer, contact your IT specialist to log in as an Administrator having the rights to install the driver.
-
Page 4: Configuring Display Settings
positions of the extended displays can be configured and is described below. Mirror (also known as clone or duplicate) mode: The DisplayLink display mirrors the content of you main display. Note that in mirror mode, both displays must have the same resolution, which may not be optimal for the display. - Page 5 Windows 10...
- Page 6 The arrangement of the displays can be changed by dragging the screens to the correct position, to reflect the physical positions of the displays on your desk. USING THE DISPLAYLINK UI...
-
Page 7: Configuring Mirror Mode
1. From the taskbar, click the Show hidden icons arrow to show all available icons. 2. Click the DisplayLink icon: or A menu appears with several options. 3. Choose "Extend" from the device submenu Configuring mirror mode... - Page 8 It is possible to only mirror 2 displays using the windows interface. It is not possible to mirror more than 2 displays. If you want to mirror more than 2 displays, we recommend 3rd party display management tools, for example Actual Multiple Monitors.
- Page 9 Windows 10...
- Page 10 USING THE DISPLAYLINK UI...
- Page 11 1. From the taskbar, click the Show hidden icons arrow to show all available icons. 2. Click the DisplayLink icon: or A menu appears with several options. 3. Choose "Mirror" from the device submenu Configuring Replace mode ...
- Page 12 Note that your laptop or tablet display will be re-enabled when the DisplayLink display is disconnected. USING THE WINDOWS DISPLAY INTERFACE To make the DisplayLink display the main display and disable the laptop or tablet screen, choose "Show desktop only on 2" from the Multiple displays menu, and click "Apply": Windows 7 - 8.1 Windows 10...
- Page 13 USING THE DISPLAYLINK UI...
- Page 14 1. From the taskbar, click the Show hidden icons arrow to show all available icons. 2. Click the DisplayLink icon: or A menu appears with several options. 3. Choose "Notebook Monitor Off" from the device submenu...
- Page 15 Setup the Adapter for Mac OS 1. Install Driver 1. Download the driver from the link https://www.displaylink.com/ downloads select the correct driver for your operating system. Double click on the driver file to start the installation process. Follow the steps to complete the installation. Once the installation is complete, please reboot your computer.
- Page 16 It is possible to use the ‘Gather Windows’ button to bring all the ‘Display Preferences’ windows onto the main display. Setting the Display Resolutions To change the display’s resolution, select an available resolution from the Display Preferences window of the display you wish to change:...
-
Page 17: Setting The Position Of Displays
The resolutions available depend on both the DisplayLink enabled product and the capabilities of the connected display. If you wish to rotate your display, you can configure the orientation using the ‘Rotate’ drop down. Select the appropriate angle of rotation to match your display’s set up. - Page 18 To move the position of a display, click and hold the display you wish to move then drag it to the desired position. The display will be highlighted with a red border whilst you are moving the display to its new position. SETTING THE DISPLAY TO MIRROR MODE When in Mirror mode, additional displays will display what is being shown on the primary display.
- Page 19 SETTING THE DISPLAY TO EXTEND MODE To extend connected displays, make sure that the “Mirror Display” on the ‘Arrangement’ pane is unchecked.
-
Page 20: Changing The Main Display
USING BOTH EXTENDED AND MIRRORED DISPLAYS To work with both extended and mirrored displays, turn off mirroring then in the Arrangement pane press and hold 'cmd' and 'alt' and drag and drop the display you wish to mirror over the primary display. Repeat this with each display you wish to mirror, those untouched will remain extending. - Page 21 Frequently Asked Questions For the question and troubleshooting, please refer to https:// support.displaylink.com/...
