DisChargePlus
O P E R A T I N G I N S T R U C T I O N S

Introduction:

The DisChargePlus Battery Tester is designed to measure the
remaining capacity, or useful energy for which a 36 or 48 volt
battery set is capable. The discharge rate, time, and shut off
voltage are programmable.

Specifications:

• Operates from battery voltage, either 36 or 48 volt battery
packs (no AC power required)
• Electronically controlled (uses microcontroller)
• Programmable voltage or time shutoff - 3 rates of
discharge
• LCD digital display for easy reading
• Built-in thermal protection
• 8 foot DC cord with cord wrap brackets
• Large 200 amp clamps for battery connections

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DisChargePlus and is the answer not in the manual?

Questions and answers

Summary of Contents for FSIP DisChargePlus

  • Page 1 O P E R A T I N G I N S T R U C T I O N S Introduction: The DisChargePlus Battery Tester is designed to measure the remaining capacity, or useful energy for which a 36 or 48 volt battery set is capable.
  • Page 2 Important Safety Instructions: • Before using discharge unit, read all instructions and cautionary markings on electric vehicle, battery, battery charger, and all accessories using battery. • Position the discharger on a foundation of stone, brick, concrete or grounded metal. • To reduce the risk of fire, do not use the discharger near flammable materials or vapors.
  • Page 3 Identifying Defective Cells/Batteries: During the discharge cycle, batteries should be monitored by Proper Care and Use of Batteries: voltage individually, and should stay fairly even. Batteries that drop faster than the others are probably defective. Batteries that CAUTION: Always wear protective eye shields and clothing fall much below 1.75 volts per cell should be replaced.
  • Page 4 Using the DisChargePlus: Testing should be done in a cool, clean, dry, and well-ventilated 3. The solenoid will close, and the system voltage will be environment. Position the discharger on stone, brick, concrete or displayed, along with the rate of discharge. Press the grounded metal.
