- Page 1 HomeLink ™ Series Phoneline 10M Ethernet Bridge Use this User Guide to install the following Linksys product: HomeLink Phoneline 10M Ethernet Bridge (Model No.: HPB200) User Guide...
-
Page 2: Copyright And Trademarks
(1) year from the date of purchase. If the product proves defective during this warranty period, call Linksys Customer Support in order to obtain a Return Authorization number. BE SURE TO HAVE YOUR PROOF OF PURCHASE ON HAND WHEN CALLING. -
Page 3: Table Of Contents
Phoneline 10M Ethernet Bridge Introduction The HomeLink Phoneline 10M Ethernet Bridge The Linksys HomeLink Phoneline 10M Ethernet Bridge offers a complete Internet connection solution for your Home Phoneline network. The HomeLink Bridge makes sharing your broadband access easier than ever. This unique new device features two 10BaseT/100BaseTx RJ-45Ethernet ports and one HomeLink RJ-11 Port. -
Page 4: Features
Package Contents • One HomeLink Phoneline 10M Ethernet Bridge • One AC Adapter & Power Cord • One User Guide and Registration Card Linksys HomeLink™ Series Phoneline 10M Ethernet Bridge Getting to Know the HomeLink Phoneline 10M Ethernet Bridge Rear Panel Ports HPNA 2.0... -
Page 5: Front Panel Leds
Using the HomeLink Phoneline 10M Ethernet Bridge Installation Overview Since the HomeLink Phoneline 10M Ethernet Bridge is a stand-alone device that requires no software or system configuration, its setup involves nothing but plugging everything in and turning all your hardware on. However, there are a few limitations to the amount of physical distance your network can cover without running the risk of data corruption. -
Page 6: Connecting Your Devices To The Bridge
4. Power everything on. Connect the supplied power cord to the power adapter, then to the Power port on the rear of the Bridge. Plug the power cord into an electrical outlet. The Phoneline 10M Ethernet Bridge installation is now complete. Linksys HomeLink™ Series Phoneline 10M Ethernet Bridge... -
Page 7: Appendix
1. Shut down all of your network components. 2. Disconnect the Bridge's power supply and wait five seconds. 3. Plug the Bridge’s power supply back into the power outlet. Linksys HomeLink™ Series Phoneline 10M Ethernet Bridge Appendix Twisted Pair Cabling There are different grades, or categories, of twisted-pair cabling. -
Page 8: Telephone Cabling
The connectors on phone cables are called RJ-11 connectors, and have four wires inside the plastic tips. Standard telephone cables like the ones you use every day in your home should do the job. Linksys HomeLink™ Series Phoneline 10M Ethernet Bridge Specifications Standards... -
Page 9: Linksys Warranty Information
FROM THE PRODUCT'S PACKAGING ON HAND WHEN CALLING. RETURN REQUESTS CANNOT BE PROCESSED WITHOUT PROOF OF PURCHASE. IN NO EVENT SHALL LINKSYS’ LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDEN- TAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFTWARE, OR ITS DOCU- MENTATION.
