Owner
CONSTRUCTED WITH AMERICAN STEEL
PACKAGED AND ASSEMBLED IN AMERICA
Read, Understand and Follow ALL Instructions prior to use.
Lea, entienda y siga todas las instrucciones antes de usar.
Stryper Manual.indd 1
Stryper Manual.indd 1
s Manual
'
S&B Lawn Systems, Inc. / 262-439-9261
Visit https://www.sblawnsystems.com
Model No.
GEN– 61522B
6/16/22 11:50 AM
6/16/22 11:50 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GENERATION 3 LAWN STRYPER GEN-61522B and is the answer not in the manual?

Questions and answers

Summary of Contents for S&B Lawn Systems GENERATION 3 LAWN STRYPER GEN-61522B

  • Page 1 Owner s Manual ’ CONSTRUCTED WITH AMERICAN STEEL PACKAGED AND ASSEMBLED IN AMERICA Model No. GEN– 61522B Read, Understand and Follow ALL Instructions prior to use. Lea, entienda y siga todas las instrucciones antes de usar. S&B Lawn Systems, Inc. / 262-439-9261 Visit https://www.sblawnsystems.com Stryper Manual.indd 1 Stryper Manual.indd 1...
  • Page 2 Congratulations... On your purchase of the GENERATION 3 Lawn Stryper , a S&B Lawn Systems, Inc. product. The Lawn Stryper attachment is designed to easily and safely attach to most walk-behind, self-propelled and push-type lawn mowers. When used properly, the Lawn Stryper attachment will allow you to pattern your lawn just like the pros do at golf courses, landscape firms and major league ballparks.
  • Page 3 Safety: • Read, and understand all of the instructions in this manual prior to using the Lawn Stryper attachment. Follow those GENERATION 3 instructions whenever using the Lawn Stryper attachment. • Lawn Stryper attaches to and follows behind your lawn mower during normal grass-cutting operations, and should not affect the operating characteristics of your mower.
  • Page 4 Assembly: • TOOLS Required: Phillips or Flat Head Screw Driver. • Fill Roller, completely, with DRY Sand. (sand not included) IMPORTANT: Work on a flat level surface – make certain mower is NOT running. Parts: A. (2) YSB-G3-011 Gen 3 Lawn Stryper Inner Clamp(s) B.

  • Page 5: Parts View

    Lawn Stryper Parts View CAUTION: Do not assemble, disassemble, attach, inspect, or adjust the Lawn Stryper attachment while the mower is running. SHUT OFF THE MOWER before performing any of these actions. DO NOT place clamp system over any type of existing wires/ cables that may be present on lawn mower handlebars.
  • Page 6 Step 1 Pour sand into opening. Step 1: Fill Roller, Completely, with DRY Sand. Completely fill Roller Tube (H), WITH DRY SAND, via holes located on ends of tube. Once completely filled, thread and FULLY TIGHTEN Roller Plug using a flat head screwdriver. User Tip! Once Completely Filled with DRY Sand, carefully place Roller Plug(s) (I) back in place.
  • Page 7 Step 2 Step 2: Attach Inner Clamps, Outer Clamps with applicable inserts to Handlebars. Place appropriate Inserts (O & P) into the Inner (A) and Outer (B) clamps. When properly assembled, ALIGNMENT MARKS will show a STRAIGHT LINE. Within the LOWER THIRD of handlebars, place Inner Clamp (A) on inside of handlebar while attaching Outer Clamp (B) on outside of handlebar.
  • Page 8 Step 3 Step 3: Attach Hitch Tube (D), Corner Tubes (E), and Vertical Tubes (F). Attach Hitch Tube (D) to Corner Tubes (E) by pressing down on the Valco Pins and locking into place as outlined in the diagram above. SET width of this assembly to the approximate width of mower handlebars (adjust- ments can be made later).
  • Page 9 Step 4 Step 4: Insert Vertical Tubes into Angle Adjusters. Set Vertical Tube (F) into Angle Adjuster (C). Make certain that top portion of Vertical Tube (F) rests FLAT on inner portion of Angle Adjuster (C) as outlined in above diagram. Screw holes should match up. Insert PH Combo Machine Screw ¼...
  • Page 10 Step 5 Step 5: Attach Angle Adjuster (C) & Tube Assembly to Handlebar Step 5: Attach Hitch Tube and Corner Tubes to Vertical Mount System. Clamp Assembly. Attach Hitch Tube (D) to Corner Tubes (E) by pressing down on Valco Pins and locking into place as outlined in diagram above.
  • Page 11 Step 6 Step 6: Setting Angle and Height. Swing assembly AS CLOSE to mower as possible without hitting mower or impeding the mower bagging system*. Make certain left Clamp and right Clamp angles are the same. Once proper angle is achieved, FULLY TIGHTEN ALL SCREWS (do not overtighten). Set height of assembly, via Valco Pins, to NO LESS than 2.5 inches off the ground.
  • Page 12 Step 7 Step 7: - Attach Roller Assembly to Hitch Tube. Attach sand filled Roller Assembly (H) onto Stainless Steel Hook (G) by Vertically sliding onto hitch as outlined in above diagram. User Tip! When you don’t want the patterning effect, or perimeter cut is necessary, or when there are obstructions such as fence line, retaining wall, or other objects, remove Roller Assembly (with mower turned off) while keeping tubing and clamp system intact...

  • Page 13: Double Check

    Finished GENERATION 3 Lawn Stryper Double Check: • Make certain stride does not impede with the roller assembly. • Make certain Lawn Stryper attachment is adjusted to the correct height, width and angle. • Make certain all clamps, tubes and screws are secure. Additional width, height and angle adjustments may need to be made based upon personal preference.

  • Page 14: Owner Responsibilities

    Lawn Stryper Warranty: ™ S&B Lawn Systems, Inc. shall repair any Lawn Stryper attachment, when used for residential use*, if defective in materials or if it ceases to function due to a failure of it’s components. S&B Lawn Systems, Inc. will repair or replace, at it’s sole discretion, a defective Lawn Stryper unit.

  • Page 15: General Tips

    General Tips: Visual results may vary based upon health of grass, length of grass, available sunlight and seasonal conditions. A less dramatic patterning effect can be a result of insufficient sunlight, dormant grass, unhealthy grass, or when used on Bermuda, St. Augustine, oysia or other warm season grass types.
  • Page 16 General Tips Continued: Patterning Effect: The Lawn Stryper attachment is specifically designed to properly ‘bend’ grass after it has been cut. This proper ‘bend’ results in light reflecting differently off grass blades thus producing the pattern effect. Results may vary based upon health of grass, length of grass, type of grass, dormant/drought stricken grass, available sunlight and/or seasonal conditions.

  • Page 17: Troubleshooting

    Troubleshooting: Roller Does Not Turn: • With mower turned OFF, check to see if any type of debris such as bark, twigs, stones, or other objects have obstructed the roller’s ability to turn. If so, with mower turned OFF, remove debris from the roller. •...
  • Page 18 Lawn Care Tips: It is important to have a healthy lawn in order to experience all of the benefits of the Lawn Stryper attachment. Please find below a few general lawn care tips that will help to ensure a strong and beautiful lawn. Keep Lawn Mower Blade Sharp: A common error is to neglect the lawn mower’s blade.
  • Page 19 Lawn Care Tips Continued: Watering Your Lawn: When your lawn begins to look stressed or when you step on and it does not bounce back, it may be time for a thorough watering. Approximately 1 to 2 inches of water, equally distributed, should do the job. Watering should occur during the early morning hours.
  • Page 20 Visit https://www.sblawnsystems.com S&B Lawn Systems, Inc. 262-439-9261 Copyright © 2022 S&B Lawn Systems, Inc. Printed in the USA CONSTRUCTED WITH AMERICAN STEEL PACKAGED AND ASSEMBLED IN AMERICA 22-YSB-G3 Stryper Manual.indd 20 Stryper Manual.indd 20 6/15/22 8:02 PM 6/15/22 8:02 PM...
