Wiegand 125 kHz Passive Proximity Readers
SPECIFICATIONS
Read Capability ............................
Working Environment
WPR900 and WPK900 ..................
WMR900 and WMK900 .................
WDP900 ........................................
WKM900 ........................................
Input Voltage Rating ....................
INSTALLATION MANUAL
Slim Tags, Omega Tags, Impro Trinary Tags
and HID 125 kHz Tags.
NOTE:
Designed to work in indoor or outdoor
environments similar to IP53.
NOTE:
Designed to work in harsh (industrial) indoor or
outdoor environments similar to IP53.
The IP rating for this Wiegand Reader is
dependant on the user supplied housing. The
rating of the Reader on its own is similar to
IP35.
NOTE:
Designed to work in an indoor or outdoor
environment similar to IP42.
NOTE:
5 V DC to 16 V DC, polarity sensitive.
MODEL NUMBER:
WPR900-1-0-AC-XX WMR900-1-0-AC-XX
WPK900-1-0-AC-XX WMK900-1-0-AC-XX
WDP900-1-0-AC-XX WKM900-1-0-AC-XX
R
EADERS
HID is a registered trademark of
HID Global Corporation (an ASSA
ABLOY Group Brand).
These Readers are RoHS
compliant and do not contain any
UV stabilizer.
These Readers are RoHS
compliant and do not contain any
UV stabilizer.
These Readers are RoHS
compliant and do not contain any
UV stabilizer.
Advertisement
Related Manuals for Amano WPR900-1-0-AC Series
Summary of Contents for Amano WPR900-1-0-AC Series
- Page 1 MODEL NUMBER: WPR900-1-0-AC-XX WMR900-1-0-AC-XX WPK900-1-0-AC-XX WMK900-1-0-AC-XX WDP900-1-0-AC-XX WKM900-1-0-AC-XX IEGAND EADERS Wiegand 125 kHz Passive Proximity Readers INSTALLATION MANUAL SPECIFICATIONS Read Capability ......Slim Tags, Omega Tags, Impro Trinary Tags and HID 125 kHz Tags. NOTE: HID is a registered trademark of HID Global Corporation (an ASSA ABLOY Group Brand).
- Page 2 Power Requirements Current (mA) Power (W) Supply Voltage 5 V DC all 0.25 Indicators on......Supply Voltage 12 V DC all 0.60 Indicators on......Wiegand Bus „0‟ and „1‟ Data streams. Electrical Interface ....Data Format ......Tag information: 44-bit or 26-bit Wiegand. Key information: 26-bit Wiegand only.
-
Page 3: Installation Information
INSTALLATION INFORMATION Accessories Find the following when unpacking the Wiegand Reader: WPR900 and WPK900 Either a Wiegand Plastic Non-keypad Reader (WPR900-1-0-AC-XX) housed in a dark gray, ABS plastic housing. The Wiegand Reader consists of a Front Cover and a Backing Plate (the Backing Plate is attached with a Self-tapping Screw (M3 x 8 mm)). - Page 4 WKM900 A Wiegand Keypad Mullion Reader (WKM900-1-AC-XX) housed in a Black, ABS Plastic housing. The Wiegand Reader consists of a Front Cover and a Mounting Bracket (the Mounting Bracket is attached with a Self-tapping Screw (M2 x 6 mm)). ...
-
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS Connecting the Wiegand Reader Figure 1 to Figure 5 show typical connection diagrams for the Wiegand Reader. Figure 1: Wiegand Reader Connected to the Amano TRT WPR300-0-0-AC-04 March 2009 Page 5... - Page 6 Figure 2: Wiegand Reader Connected to the Nexus 220 Controller WPR300-0-0-AC-04 March 2009 Page 6...
- Page 7 Figure 3: Wiegand Reader Connected to the Amano MfT or the AXP121 Controller WPR300-0-0-AC-04 March 2009 Page 7...
- Page 8 Figure 4: Wiegand Reader Connected to the Amano TA or Amano iTA WPR300-0-0-AC-04 March 2009 Page 8...
- Page 9 Figure 5: Wiegand Reader Connected to the Amano RL (Amano RS and Amano RH) WPR300-0-0-AC-04 March 2009 Page 9...
- Page 10 Wiegand Mode The Wiegand Readers offer four different Output Mode Combinations: Mode 1 (1 Beep): 26-bit, HID Normal. Mode 2 (2 Beeps): 44-bit, HID Normal (Default). Mode 3 (3 Beeps): 26-bit, HID Raw. Mode 4 (4 Beeps): 44-bit, HID Raw.
- Page 11 Wiegand 44-bit Protocol Tags are reported using Wiegand 44-bit Protocol. An “EMM” Tag has an 8-bit User Code and a 32-bit Serial Number. These are reported as follows: The 8-bit User Code is reported in bits 1 to 8 of the Protocol. ...
- Page 12 Fixed Length Key Output Mode Once the specified number of keys are pressed, all the buffered keys are output in hexadecimal format: Output 0000 0001 0010 0011 0100 0101 0110 0111 1000 1001 1010 1011 Doorbell (WKM900 only) 00111100 Table 1: Fixed Length Key Output Mode Setting the Fixed Length Mode The number of keys to be buffered and the parity option in the Fixed Length Mode is set as follows:...
- Page 13 Single Key 8-bit Burst Mode To select this mode, specify the Fixed Length Buffered Mode to be “018”. This mode reports each single key press as 8-bit code. Use Single Key 8-bit Burst Mode when using Wiegand Readers in PAC Mode or TAG+PIN Mode. Output 11110000 11100001...
-
Page 14: Guarantee Or Warranty
Serial Number Label Once the Wiegand Reader is installed, sketch a rough site plan. Attach the Wiegand Reader‟s loose Serial Number Label and the Terminal or Controller‟s Fixed Address Label, to the sketched site plan in the position of the Wiegand Reader. - Page 15 USER NOTES WPR300-0-0-AC-04 March 2009 Page 15...
- Page 16 This manual is applicable to the Wiegand Readers WPR900-1-0-AC-00, WPK900-1-0-AC-00, WMR900-1-0-AC-00, WMK900-1-0-AC-00, WDP900-1-0-AC-00 and WKM900-1-0-AC-00 (The last two digits of the Impro stock code indicate the issue status of the product). Wiegand Readers\Amano USA\LATEST WPR300-0-0-AC-04 Issue 05 Mar 2009 ISSUE\AWiegRdr-insm-en-05.docx...
