Wireless-G Broadband Router with 2 Phone Ports

Chapter 5: Configuring the Wireless-G Broadband

Router with 2 Phone Ports

Overview

Linksys recommends using the Setup CD-ROM for first-time installation of the Router. If you do not wish to run

the Setup Wizard on the Setup CD-ROM, then you can use the Web-based Utility to configure the Router. For

advanced users, you may configure the Router's advanced settings through the Web-based Utility.

This chapter will describe each web page in the Utility and each page's key functions. The utility can be accessed

via your web browser through use of a computer connected to the Router. For a basic network setup, most users

will use these two screens of the Utility:

• Basic Setup. On the Basic Setup screen, enter the settings provided by your ISP.

• Management. Click the Administration tab and then the Management tab. The Router's default password is

admin. To secure the Router, change the Password from its default.

There are seven main tabs: Setup, Wireless, Security, Access Restrictions, Applications & Gaming, Administration,

and Status. Additional tabs will be available after you click one of the main tabs.

To access the Web-based Utility, launch Internet Explorer or Netscape Navigator, and enter the Router's default IP

address, 192.168.0.1, in the Address field. Then press Enter.

A password request page, shown in Figure 5-1 will appear. (Non-Windows XP users will see a similar screen.)

Leave the User Name field blank. The first time you open the Web-based Utility, use the default password admin.

(You can set a new password from the Administration tab's Management screen.) Then click the OK button.
