tema AD699/L10M Quick Start Manual

Multicolor LED flashing
"IP COMMUNICATION AND SECURITY COMPANY"

Installation

● Install the flasher on a smooth and flat surface so that the rear gasket fits snugly
● Clean the back of the box from dust or grease
● Apply the adhesive gasket so that it seals the edges of the exposed area
● Press the gasket so that the adhesive adheres perfectly to the box
● Fix the box so that it is pressed as much as possible on the installation surface
● If necessary, seal the exposed printed circuit area (where there is the input terminal block) and the rest of the
box with silicone
● Close the transparent cover tightly by turning it clockwise
Note: images are indicative and may vary according to production
AD699/L10M-SEGN-MULTICOLORE-2203 *Product specifications may change without notice*
AD699/L10M
Multicolor LED flashing
The AD699/L10M light indicator allows you to emit light with programmable
colors and intermittent emission, which are also programmable through 2
buttons which can be accessed by unlocking the cover with a clockwise rota-
tion. The following 7 colors can be selected: white, red, green, blue, light
blue, yellow, pink. Activation can be programmed simply by powering the in-
dicator with a voltage from 9V to 24V in direct or from 9 to 18V in alternat-
ing. It is possible to keep the module powered at rest and provide a contact
from the outside on a specific terminal. During the programming phase, by
setting up a special internal switch, the brightness of the LEDs is reduced so
as not to disturb the operator, at the end of the programming the normal
brightness will be restored.

Technical Features

Supply voltage DC
Supply voltage AC
Power
Temperature
Protection grade
Diffusion cap color
LED
Functionality
: 12Vdc – 24Vdc
: 12Vac – 18Vac
: 2,5W-5W
: -20° +60°
: IP56
: White
: 6 Multicolor LEDs, 6 White LEDs
: steady or flashing light, with programming
buttons
