TIS -TM120 Installation Manual

INSTALLATION MANUAL
TIS ROLLER MOTOR
Model: TIS-TM120
Input
Motor
TIS Bus
Protection
Reaction time
Mounting
Connection terminal
Operating and display
elements
Functions
Weight
Dimensions
Housing
BARCODE (UPC-A)
6 58921 79882 9
This solution is used to control blinds and roman
rollers and features an RF antenna, so you can
control your curtains using the TIS remote control
or via the TIS mobile application and software.
P R O D U C T S P E C I F I C AT I O N S
Input Voltage
Current rating
Rated power
Rated Torque
Rated speed
Motor noise
Security Payload
Number of devices on 1 line
Bus connection
Memory
Data / Bus
Programming button/LED
By TIS bus
Without packaging
Materials
IP Rating
PRODUCT INFORMATION
AC 230V 50 HZ
<0.5A
120W
6 N.m
22 rpm
<35db(A)
20KG
Max. 64
Reverse Polarity Protection
Open/Close position programmable
approx. 20ms
Inside the roller tube
3 bin bus terminal
For programming /resetting remote
TIS Protocol messages and commands
Open / Close / Stop
1.0 KG
50mm (diameter) × 480mm (length)
Aluminum black
IP 44
