This product manual provides further detail on the AZBAT24100C LiFePO4 battery. Please
familiarise yourself with the operating instructions in this document before operating the battery.
Table of Contents
REVISION HISTORY ................................................................................................................................. 2
DISCLAIMER ............................................................................................................................................ 2
OVERVIEW................................................................................................................................................ 2
PRODUCT INFORMATION ....................................................................................................................... 4
INSTALLATION ........................................................................................................................................ 7
TROUBLESHOOTING .............................................................................................................................. 9
PRECAUTIONS ....................................................................................................................................... 11
..................................................................................................................................... 11
Before use ....................................................................................................................................11
During use ....................................................................................................................................11
Other .............................................................................................................................................12
EMERGENCY CONDITIONS .................................................................................................................. 12
.......................................................................................................................................... 12
O
...................................................................................................................................... 12
THER
Copyright © Azoteq (Pty) Ltd 2022
All Rights Reserved.
PowerSense
Lithium-Iron Phosphate Battery
AZBAT24100C
Product Manual
.............................................................................................................4
................................................................................................................................5
.....................................................................................................................6
...................................................................................................................7
...............................................................................................................8
...........................................................................................................8
.................................................................................................................8
.....................................................................................................................9
................................................................................................ 10
.................................................................................................................................. 11
.......................................................................................................................... 12
®
Series
................................................................................... 10
AZBAT24100C User Manual
Revision 1.02
Page 1 of 13
September 2022
Advertisement
Table of Contents
Related Manuals for Azoteq AZBAT24100C
Summary of Contents for Azoteq AZBAT24100C
-
Page 1: Table Of Contents
Series Lithium-Iron Phosphate Battery AZBAT24100C Product Manual This product manual provides further detail on the AZBAT24100C LiFePO4 battery. Please familiarise yourself with the operating instructions in this document before operating the battery. Table of Contents REVISION HISTORY ..........................2 DISCLAIMER ............................2 OVERVIEW.............................. -
Page 2: Revision History
Website Warranty Link Disclaimer This product manual provides further detail on the AZBAT24100C LiFePO4 battery. Please read the operating instructions in this document before using the battery. Also familiarise yourself with the warranty conditions of this product to ensure it is operated within stipulated requirements. - Page 3 Series Safety Precautions The AZBAT24100C Lithium Ion battery operates at hazardous low DC voltage, please be aware of potential arc and shock hazards and handle with caution. Please make use of a qualified installer and have them familiarize themselves with this product manual.
-
Page 4: Product Information
® PowerSense Series Product Information Production dimensions Figure 1: AZBAT24100C physical dimensions Copyright © Azoteq (Pty) Ltd 2022 AZBAT24100C User Manual Page 4 of 13 All Rights Reserved. Revision 1.02 September 2022... -
Page 5: Parameters
® PowerSense Series Parameters Table 1: AZBAT24100C electrical and environmental parameters Model AZBAT24100C Battery Type LiFePO4 Nominal Voltage Nominal Battery Capacity 100Ah Nominal Capacity 2.56kW @ 100% DoD Cycle life @ 80% DoD* 5 000 @ 25°C Cycle life @ 100% DoD* 2000 @ 25°C... -
Page 6: Battery Interface
Balance Voltage (while charging) IEC 62619 CERTIFICATION UN38.3 Battery interface This section details the front panel interface of the battery. Copyright © Azoteq (Pty) Ltd 2022 AZBAT24100C User Manual Page 6 of 13 All Rights Reserved. Revision 1.02 September 2022... -
Page 7: Installation
The installation details must be sent to Azoteq for the warranty to apply along with an electrical Certificate of Compliance (CoC). Please download and complete the warranty document from the Azoteq website (https://www.azoteq.com/warranty/) -
Page 8: Installation Location
Charge Current : 30 A (per battery connected) d. Equalization: Disabled Parallel connection The AZBAT24100C battery can be used in parallel with batteries of the same model, capacity, and manufacturer. 1. DO NOT connect different batteries in parallel. 2. A maximum of 4 batteries connected in parallel is allowed. -
Page 9: Series Connection
Figure 3: Parallel Battery Diagonal Wiring Series connection The AZBAT24100C battery can be used in series with batteries of the same model, capacity and manufacturer. 1. Ensure that both batteries are fully charged and all cells are balanced before connecting them in series. -
Page 10: Battery Pack Voltage Is Low Or Zero
Insufficient Energy Capacity Cycle the battery 4 – 5 times by discharging to 80% DoD and then charging with a low charging current between 2A to 10A. Copyright © Azoteq (Pty) Ltd 2022 AZBAT24100C User Manual Page 10 of 13 All Rights Reserved. -
Page 11: Precautions
4. Do not exceed the charging current and discharging current parameters of the battery. 5. Overcharging or over-discharging will shorten the life-span of the battery and may cause the battery pack fail or overheat and catch fire. Copyright © Azoteq (Pty) Ltd 2022 AZBAT24100C User Manual Page 11 of 13 All Rights Reserved. -
Page 12: Other
Please refer to the terms and conditions of sale and the warranty document. Emergency conditions Please refer the material safety datasheet (MSDS) for the batteries on the Azoteq website. Leaking cells 1. In the event of a cell leaking liquid or gas, take caution to prevent any contact with the skin and eyes and inhaling the gas. - Page 13 Azoteq products are not authorized for use as critical components in life support devices or systems.
