- Page 1 User's Manual Bed Frame Queen size KLV-UP-088 / KLV-UP-089 V1.0...
- Page 2 Thank you for purchase on our products. Please contact us if you have difficulty with assembly or need replacement parts. Our customer service is here to assist you. Please attach your User Name or Order ID so that we can assist you better. WARNING Serious or fatal injury may occur from unexpected assembly or use.
- Page 3 Parts List(EN) / Teile Liste(DE) Front Slat Headboard side leg 2PCS 2PCS Right Siderails 2PCS Front Middle cross beam 2PCS Front Leg 10+1PCS 2PCS Screw 8+1PCS M3.5×30mm - 2 -...
- Page 4 Assembly Steps(EN) / Montageschritte(DE) STEP 1 Adjustable height, The matress height from 8"-12" N x 4PCS P x 1PC STEP 2 - 3 -...
- Page 5 Assembly Steps(EN) / Montageschritte(DE) STEP 3 Loosen the screw of siderails, install the edge of the foot, and tight the innerscrew. P x 1PC STEP 4 Noted that the middle cross beam, the direction of the red arrow is the front N x 2PCS P x 1PC - 4 -...
- Page 6 Assembly Steps(EN) / Montageschritte(DE) STEP 5 Loosen the screw of headboard side leg and both sides of footboard, hanging the bracket and tight the innerscrew. P x 1PC STEP 6 Loosen the screw of the middle of footboard, hanging the bracket and tight the innerscrew. P x 1PC - 5 -...
- Page 7 Assembly Steps(EN) / Montageschritte(DE) STEP 7 N x 3PCS P x 1PC STEP 8 N x 1PC P x 1PC - 6 -...
- Page 8 Assembly Steps(EN) / Montageschritte(DE) STEP 9 O x 8PCS P x 1PC STEP 10 - 7 -...
