Champion Para LINK 201108 Operator's Manual

Power station parallel kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
MODEL #201108
POwER STATiON PARALLEL KiT
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com
or visit championpowerequipment.com
SAVE THESE iNSTRUCTiONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do
so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
EN
3590-M-OP REV 20220705
Champion Power Equipment, Inc., Santa Fe Springs, CA USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Para LINK 201108 and is the answer not in the manual?

Questions and answers

Related Manuals for Champion Para LINK 201108

Summary of Contents for Champion Para LINK 201108

  • Page 1 This manual should remain with the product. Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice. 3590-M-OP REV 20220705 Champion Power Equipment, Inc., Santa Fe Springs, CA USA...

  • Page 2: Table Of Contents

    TAbLE Of CONTENTS 201108 - POwER STATiON PARALLEL KiT TAbLE Of CONTENTS Assembly and Operation ....... Paralleling Two Power Stations ........introduction .

  • Page 3: Introduction

    201108 - POwER STATiON PARALLEL KiT SAfETY DEfiNiTiONS iNTRODUCTiON Congratulations on your purchase of a Champion Power Equipment The purpose of safety symbols is to attract your attention to (CPE) product. CPE designs, builds, and supports all of our possible dangers. The safety symbols, and their explanations, products to strict specifications and guidelines.

  • Page 4: Important Safety Instructions

    Do not operate the parallel kit with a damaged cord, plug, or a Parallel kit produces heat. Skin burns can occur on contact. damaged output cable. Use only Champion electrical cords for Do not touch hot surfaces. proper application.

  • Page 5: Safety Symbols

    iMPORTANT SAfETY iNSTRUCTiONS 201108 - POwER STATiON PARALLEL KiT Safety Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product. SYMBOL MEANING Read Operator’s Manual.
  • Page 6 iMPORTANT SAfETY iNSTRUCTiONS 201108 - POwER STATiON PARALLEL KiT SYMBOL MEANING Open Flame Alert. Keep away from fuel, smoking, open flames, sparks, pilot lights, heat, and other ignition sources. Wet Conditions Alert. Do not operate parallel kit in wet or damp conditions.

  • Page 7: Controls And Features

    CONTROLS AND fEATURES 201108 - POwER STATiON PARALLEL KiT CONTROLS AND fEATURES Read this operator’s manual before operating your parallel kit. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Control Panel 1.

  • Page 8: Assembly And Operation

    4. Place the second Power Station on top of the parallel kit so that the Power Stations feet fit securely into the slots on top This parallel kit is intended for use with Champion Power of the parallel kit. Equipment Power Stations. Please refer to your Power Stations Operator’s Manuals for safety rules, start up and shut down...
  • Page 9 ASSEMbLY AND OPERATiON 201108 - POwER STATiON PARALLEL KiT 6. Connect one green and yellow grounding wire from the 8. Connect devices to the parallel kit and/or Power Stations parallel kit to each Power Station by securing the ring up to the receptacles’ rated amperages. Never exceed the terminal of the grounding wire between the nuts of the specified rated capacity of the receptacle.

  • Page 10: Cable Storage

    CAbLE STORAGE 201108 - POwER STATiON PARALLEL KiT SPECifiCATiONS CAbLE STORAGE When not in use, neatly wrap the cables and store them in the Specifications parallel kit’s storage compartment. Model ............201108 Volts AC ............Frequency ............. 60 Hz Phase ...........
  • Page 11 To complete registration you will need to include a copy of the – Problems caused by parts that are not original Champion purchase receipt as proof of original purchase. Proof of purchase Power Equipment parts.
