文件名称:
File Name:
项目编码:
Project Item:
项目名称:
Project Item:
文件编码:
File Item:
文件版本号:
File Version NO.:
文件类型:
□软件
File Type:
Software
密级:
□普通
文件
File Level:
Common
制作:李炳光/赖德星
Prepared by:
确认:周鹏坤/王朝林
Checked by:
批准:沈志刚
Approved by:
产品规格书
Specification
R1448021
RN56H8
RD-QT33-1801002
V0.0
■硬件
■结构
Hardware
Structure
■重要
Important
日期: 2018.01.06
Date:
日期: 2018.01.06
Date:
日期: 2018.01.06
Date:
第 1 页 共 15 页
□其它(
Other
□保密
Secret
保存期限:现行生产再加一个日历年

Advertisement

loading
Need help?

Need help?

Do you have a question about the FORYOU RN56H8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Adayo FORYOU RN56H8

  • Page 1 文件名称: 产品规格书 File Name: Specification 项目编码: R1448021 Project Item: 项目名称: RN56H8 Project Item: 文件编码: RD-QT33-1801002 File Item: 文件版本号: V0.0 File Version NO.: 文件类型: □软件 ■硬件 ■结构 □其它( ) File Type: Software Hardware Structure Other 密级: □普通 ■重要 □保密 文件 File Level: Common Important Secret...
  • Page 2 变更履历表 版本 发布日期 变更内容 备注 V0.0 全部 首次发布 2018.01.06 第 2 页 共 15 页...
  • Page 3 一、 范围Scope 1. 本产品规格书适用于华阳通用公司车用音响系统 (产品型号:RN56H8;产品代号:RN56H8)。 This specification is only suitable for FORYOU CAR-Audio system (Model: RN56H8, Product Code: RN56H8). 2. 本产品规格书规格书尽可能包含客户关注的技术指标,但不涉及具体的技术实现手段,出于 改善性能或其它因素引起的内部电路的更改不再另行通知。 This specification almost includes all the technology parameters which the client pays attention to. But it does not include idiographic realization method of technology. We will not notify again for the improvement of capability or the internal circuit correction which is caused by other factors.
  • Page 4 equipment GB8898-2011 音频、视频及类似电子设备安全要求 Audio, video similar electronic apparatus-safety requirements GB2846-2011 调幅广播收音机测量方法 Methods of measurement on radio receivers for AM broadcast transmissions GB6163-2011 调频广播接收机测量方法 Methods of measurement on radio receivers for FM broadcast transmissions 二、 基本信息描述 1. 效果图 2. 外形尺寸:277.29× 149.55× 93.39 mm Outline Dimension: 277.29×...
  • Page 5 车机互联 手机充电 倒车视频 音效设置、声场设置 三、 基本功能描述 Basic Function Description 1. 收音功能(全制式) Radio Function (All Radio Systems Compatible) 1) 手动及自动搜索电台 Manual & Auto search station 2) 扫描存储电台 Scan and store station 3) 电台预置:包含FM波段,AM波段; preset stations: FM bands, AM bands 4) 调入预设电台 Preset stations loading supported 2.
  • Page 6 5) 图标,标记点显示功能 Road mark / landmark display function 6) 惯导功能 Gryo function 4. 蓝牙功能 Bluetooth function 1) 可与蓝牙手机配对连接,实现电话免提功能 The unit can be paired with mobile phone; connection to achieve hands free phone function 2) 支持电话本同步功能 Support phone Book synchronization 3) A2DP功能...
  • Page 7 Loudness selection 12. 其他功能 Others 1) 方向盘键控 SWC interface 2) 输入视频信号制式自动识别 (NTSC/PAL/SECAM) Identifying color system of input video signal automatically (NTSC/PAL/SECAM) 3) 倒车摄像头视频输入 Camera video input 4) 车辆状态检测(ACC/倒车/停车) Auto detection for car status(ACC/Reverse/Parking) 5) 天线供电输出 Antenna POWER output 6) 时钟显示 Clock display 7)...
  • Page 8 首。 Requirement: audible mutes, video intermission or track jumps are not allowed in the given below: vibration-level: Z-direction (bottom-top)=1.0G; Y-direction (front to rear)=1.0G; X-direction (left to right)=1.0G; Vibration frequency=10~200Hz; Sweep time=5mins; Installation=Horizontal; Test temperature=25± 5℃; Test disc: TDV-540 track 20. 8.
  • Page 9 其中W为宽度,L为长度,D为直径。 注:关于屏的交货前检查标准最终以屏的生产厂家正式发行的产品规格书为标准。 The number of such scrape trace that accords with following size should be less than 4: 0.05mm≤W≤0.2mm, 1mm≤L≤5mm. The number of such dent that accords with following size should less than 4: 0.15mm ≤D≤0.5mm. Here, W=width, L=length, D=diameter. Note: The final check standard of TFT LCD will be the product specification issued officially by the LCD supplier.
  • Page 10 1. 36PIN插座定义 2. 收音插座定义 3. USB插座定义 4. GPS插座定义 5. T-BOX接口定义 第 10 页 共 15 页...
  • Page 11 AUX接口 六、 性能指标 Specification 1. 测试环境要求:Environment requirement Temperature: 25 ℃ ±5 ℃ 温度:25℃ ±5 ℃; 湿度: 45%~75%RH; Humidity: 45%~75%RH; 14.4V DC 最大电流10A (车用电瓶为准); 系统供电电压: Power supply: 14.4V DC, Max. Current 10A (car-used battery) 标准输出功率:Standard output power: 1W(4Ω); 调谐信号源 Tuning signal source: AM: 1KHz 30%Mod.
  • Page 12 整机在 +45℃/90%RH环境下连续工作4小时(4欧负载,1W标准功率输出),在此过程 高温高湿工作试 验 中整机功能、性能应正常。 Under +45℃/90%RH environment condition running 4 hours(4Ω load, amplifier High output=1W), the function & performance should be OK at whole testing. temperature & high humidity running test 整机在 +60℃、90%RH环境下放置96h,然后取出在常温常湿下放置24h后测试,整机 高温高湿保存试 验 性能应正常。 Under +60℃/90%RH environment condition stored 96 hours, the function & High temperature high performance should be OK after staying at room temperature/humidity for 24 hours.
  • Page 13 振动频率在10~200Hz(保持加速度2.5G)扫描周期为15分钟,被测机在 下列时间振动后应能维持正常功能:垂直方向(Z):2H, 前后方向(Y): 振动耐久性实验 1H, 左右方向(X):1H。 Vibration durability test Vibration frequency 10~200Hz, Acceleration 2.5G, scan cycle 15min, Direction Z: 2hours, Direction Y: 1hour, Direction X: 1hour. 八、 整机安全性要求 1. 符合E-MARK认证标准要求。 E-MARK safety certification organization requirement 2. 安全性 Safety 安全性符合ECE R21标准。 Safety requirements are supposed to fully conform to the Regulations of ECE R21 standard.
  • Page 14 十、 附图表 整机结构示意图:Complete set sketch map 十一、 注意事项Caution 1. 储存:机器应避免储存在高温,潮湿,多尘的环境。 Storage: high temperature, high wet and dust-full place should be avoided. FCC Compliance Statement: This device complies with Part 15 of the FCC rules. Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 15 interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna.
