TYPING STAND
IM P O RTA N T !
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a carpeted
surface.
0920
TSS
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX 1-800-445-5281.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TSS and is the answer not in the manual?

Questions and answers

Summary of Contents for Ironwood TSS

  • Page 1 TYPING STAND IM P O RTA N T ! In the event any parts are missing from Assembly may require the assistance of this package, send your name, address, another person. telephone number, and a description of Before you begin assembly: the missing part(s) to: PARTS, Box 1420, Missoula, MT 59806 or call: READ THE DIRECTIONS all the way through one...
  • Page 2: Parts Diagram

    PARTS DIAGRAM Left Side 05850241 1 ea. Right Side 05850241 1 ea. Work Surface 05850201 1 ea. Drop Leaf 05850281 1 ea. Facia Strip 05850286 1 ea. Back 05850252 1 ea.
  • Page 3 HARDWARE Flat Head H2040 12 ea. Screw Drop Leaf Support 401030 2 ea. Pan Head Screw 988056 4 ea. Angle Bracket 401200 2 ea. Caster H1192 2 ea. Caster-Locking H1193 2 ea. Rafix Flush 909834 12 ea. Rafix Bolt 909925 12 ea.
  • Page 4 Using the Rafix System: Insert the Rafix Cams into the appropriate holes. The flat edge of the cam should be facing the edge Flat of the panel. edges must be Slide Rafix Cams of the panel to be aligned attached onto the corresponding posts. When screwing post into hole, Do Not over tighten.
  • Page 5 Attach the Drop Leaf (D) using six Flat Head Screws (H2) as shown. Attach an Angle Bracket (H3) to the Right Side (B) using a Panhead Screw (H4) in the predrilled hole as shown. Insert 2 Flush Rafix cams (H7) in to side B.
  • Page 6 Follow the same procedure as Step #3 for the Left Side (A). Insert 6 Flush Rafix cams (H7) into the Back Panel (E) and 2 Flush Rafix cams into the Facia Strip (F)
  • Page 7 Secure Angle Bracket (H3) to the Work Surface using a Panhead Screw (H4) in the pre-drilled hole. Insert 9 Rafix Bolts (H8) into desegnated spots as shown. Position Back (E) onto the Worksurface as shown. Insert Flush Rafix Cams and secure.
  • Page 8 Position Facia Strip (F) onto the Worksurface as shown. Secure Cams Secure Angle Bracket (H3) to the Worksurface using a Panhead Screw (H4) in the pre-drilled hole.
  • Page 9 # 10 Attach the both the caster and locking caster to the bottom as shown. # 11 LIFT 1/4" Allow about ten minutes for the glue to set, then turn the unit upright. PUSH BOTH SUPPORTS TO LOWER THE DROP LEAF. Your Typing Stand is now completely assembled and ready to use.
