MODEL NO.：WMH-609N2
NAME：HUNGRY DOGS
MANUAL
PROGRAM： W609N0
VERSION：
Ver. 0
PAOKAI ELECTRONIC ENTERPRISE CO., LTD
http://www.PAOKAI.com.tw
ANNOUNCEMENT
Copyright © PAOKAI ELECTRONIC ENTERPRISE CO., LTD
All Rights Reserved. Violators will be prosecuted.
Please read the manual before launching the machine, and preserve the manual properly for reference.
0
Advertisement
Summary of Contents for PAOKAI ELECTONIC ENTERPRISE HUNGRY DOGS
- Page 1 MODEL NO.：WMH-609N2 NAME：HUNGRY DOGS MANUAL PROGRAM： W609N0 VERSION： Ver. 0 PAOKAI ELECTRONIC ENTERPRISE CO., LTD http://www.PAOKAI.com.tw ANNOUNCEMENT Copyright © PAOKAI ELECTRONIC ENTERPRISE CO., LTD All Rights Reserved. Violators will be prosecuted. Please read the manual before launching the machine, and preserve the manual properly for reference.
-
Page 2: Table Of Contents
INDEX ...................................... 0 Chapter 1. OPERATION ..............................2 Chapter 2. DIP SW SETTING ............................3 Chapter 3. Software setting mode ............................. 5 Chapter 4. Test mode ................................ 6 Chapter 5. Error code ................................ 9 Chapter 6. WIRING DIAGRAM ............................ 10... -
Page 3: Chapter 1. Operation
Chapter 1. OPERATION How to play: ◎ INSERT the coin to start the game: After coin in, sound effects “we are hungry”, “Please feed us” and remained sound to start the game, time to start to count down, Dog’s mouse open, game start. ◎... -
Page 4: Chapter 2. Dip Sw Setting
Chapter 2. DIP SW SETTING DIP SW1 DIP SW 1 Free play 1 coin=5plays 1 coin=2plays 5 coins=1play Coin vs. Credit 4 coins=1play 3 coins=1play 2 coins=1play 1 coin = 1play Separate 1p and 2p coin signal Together 1P 2P Open Close 1P Close gun function... - Page 5 DIP SW2 DIP SW 2 3 tickets =1 play 2 tickets=1 play Play vs. Ticket 1 ticket=1 play No ticket Difficult Difficulty Easy Without ticket dispenser Ticket function With ticket dispenser Demo music New records after power on Top records Reserved after power on New bonus after...
-
Page 6: Chapter 3. Software Setting Mode
Chapter 3. SOFTWARE SETTING MODE Press【SET】KEY and turn on the machine at same time. Until 『BOUNS』column display shows『01』enter <Software setting> mode. 『Score』column display setting value: 『01』:Game score can exchange 1 ticket (score 0~100). Default value 5 ==>0、1、2、3、5、10、20、30、50、100 『02』:BONUS can exchange 1 ticket (score 0~100). Default value 5 ==>0、1、2、3、5、10、20、30、50、100 『03』:Each play can increase BONUS value (score 0~99). -
Page 7: Chapter 4. Test Mode
Chapter 4. TEST MODE 1. How to enter “Test Mode” Press【TEST】KEY and turn on the machine at same time, then all RGB lights will start to do self test, start button and eye led lights are twinkling. Press “Set” key to go next test function. 2. - Page 8 ◎ On 1P “Score” Display Digits: A segment: 1P SENSOR Conveyor B segment: 2P SENSOR Conveyor C segment: 1P Gun Top SW D segment: 2P Gun Top SW Ten digits: A segment: 1P Button B segment: 2P Button C segment: VS Button D segment: 1P Coin signal E segment: 2P Coin signal F segment: 1P Ticket signal...
- Page 9 On Bonus Display Digits: A segment: DIPSW1 (NO1) B segment: DIPSW1 (NO2) C segment: DIPSW1 (NO3) D segment: DIPSW1 (NO4) E segment: DIPSW1 (NO5) F segment: DIPSW1 (NO6) G segment: DIPSW1 (NO7) H segment: DIPSW1 (NO8) Ten digits: A segment: DIPSW2 (NO1) B segment: DIPSW2 (NO2) C segment: DIPSW2 (NO3) D segment: DIPSW2 (NO4)
-
Page 10: Chapter 5. Error Code
Chapter 5. Error code Error code message will display on 『TIME』Display. Error code Faulty description Er 09 Operation Record is not correct. Er 12 1P coin meter is out of order. Er 13 2P coin meter is out of order Er 14 1P Ticket meter is out of order. -
Page 11: Chapter 6. Wiring Diagram
Chapter 6. WIRING DIAGRAM W180448 WIRING DIAGRAM (main board) J1 (3.96mm-6P) Power J3 (2.5mm-7P) RS232 +12V RTS IN CTS OUT RXD IN +12V TXD OUT +12V... - Page 12 J2 2.54mm Red(1P) LCM connector J9 2.54mm Blue(2P) LCM connector 1 GND 3 1P/2P LCM-VO 1P/2P LCM-RS 5 GND 1P/2P LCM-E 7 1P/2P –D0 1P/2P –D1 9 1P/2P –D2 1P/2P –D3 11 1P/2P –D4 1P/2P –D5 13 1P/2P –D6 1P/2P –D7 15 +5V J5 (2.5mm-8P) RS232 J4 (2.54mm-12P)
- Page 13 J11 RED(2.54mm-6P) 1P button +12V LAMP1 OUT+ 1P Start SW- 1P button J12 (30 Pin) Dog Driver Assembly Dog 1 motor+ MOTOR1 + D1-SW1- Dog 1 Open mouth SW Dog 1 motor- MOTOR1 - D1-SW2- Dog 1 Close mouth SW Dog 2 motor+ MOTOR2 + D2-SW1-...
- Page 14 BONUS Highest Scores scores scores W100622(1)， W100622(2)，1P W100622(3), 2P W100622(4) J16 (34pin) TIME W141131 To W100622(1)(2) J11-2 ADISPLAY a+ to W100622(1)(2) J11-4 ADISPLAY b+ to W100622(1)(2) J11-6 ADISPLAY c+ to W100622(1)(2) J11-8 ADISPLAY d+ to W100622(1)(2) J11-10 ADISPLAY e+ to W100622(1)(2) J11-12 ADISPLAY f+ to W100622(1)(2) J11-14 ADISPLAY g+...
- Page 15 J15 (50 Pin) W160202 Sensor+ RGB and W120717 Tie to W160202 J1-1 +12V to W160202 J1-2 B1 LED- to W120717 J1-1 +12V to W160202 J1-3 R1 LED- Dog 1 to W120717 J1-2 DB1 LED- Dog 1 to W160202 J1-4 G1 LED- to W120717 J1-3 DR1 LED- to W160202 J1-5...
- Page 16 Blue (2.5mm-4P) 2P Gun RGB light (2.5mm-4P) 1P Gun RGB light RGB light B LED+ RGB light B LED+ W140518(L3) W140518(L3) RGB light R LED+ RGB light R LED+ RGB light G LED+ W140518(L2) W140518(L2) RGB light G LED+ W140518(L1) W140518(L1) to W140518(G) to W140518(G)
- Page 17 W160202 Dog Head Sensor+ RGB light board W160202 *5 W180448 J15 J1 (2.0mm-6P) Dog 1 Dog 2 Dog 3 Dog 4 Dog 5 J15-1 J15-11 J15-21 J15-31 J15-41 LED B - J15-2 J15-12 J15-22 J15-32 J15-42 LED R- J15-4 J15-14 J15-24 J15-34 J15-44 LED G- J15-6 J15-16 J15-26 J15-36 J15-46...
- Page 18 W120717 Dog Tie RGB light board W120717 *5 W180448 J15 J1 (2.0mm-4P) Dog 1 Dog 2 Dog 3 Dog 4 Dog 5 J15-3 J15-13 J15-23 J15-33 J15-43 LED B - J15-5 J15-15 J15-25 J15-35 J15-45 LED R- J15-7 J15-17 J15-27 J15-37 J15-47 LED G- J15-9 J15-19 J15-29 J15-39 J15-49...
- Page 19 W141131 Time Display 1.8" J1 (2.54mm-12P) W161257 J14 DISPLAY a+ to W180448 J16-17 DISPLAY b+ to W180448 J16-18 DISPLAY c+ to W180448 J16-19 DISPLAY d+ to W180448 J16-20 DISPLAY e+ to W180448 J16-21 DISPLAY f+ to W180448 J16-22 DISPLAY g+ to W180448 J16-23 DISPLAY p+ to W180448 J16-24...
- Page 20 W100622 Scores Display 1.8" W180448 J16 W180448 J16 W100622 BONUS Highest BONUS Highest J11 (14pin) Scores Scores Scores Scores Scores Scores J16-25 J16-28 J16-25 J16-28 COM 2- 2 DISPLAY a+ J16-1 J16-1 J16-9 J16-9 J16-26 J16-29 J16-26 J16-29 COM 3- 4 DISPLAY b+ J16-2 J16-2...
- Page 21 W161258 RGB Chasing RGB light board J1 (3.96mm-4P) Power +12V +12V J2 Left / J3 Right (2.5mm-7P) to W161256 J1 J4 (2.5mm-6P) W180448 J24 +12V W180448 J24...
- Page 22 W161256 48LED RGB Cashing light J1 (2.5mm-7P) Left side drivers to W161258 J2 Right side driver to W161258 J3...
- Page 23 W141244 RGB light Driver board J5 (3.96mm-4P) Power +12V J1 (2.5mm-5P) W180448 J20 to W180448 (J20-1) to W180448 (J20-2) to W180448 (J20-3) to W180448 (J20-4) JL1 JL2 JR1 JR2 (2.5mm-4P) Signal Out to W140518 (L3) to W140518 (L2) to W140518 (L1) to W140518 (G)
