Summary of Contents for Tsun TSOL-MT-F
- Page 1 STORE THE FUTURE User Manual TSOL-MT-F TSOL-MT-M TSOL-MP-F TSOL-MP-M TSOL-MC200-G2 TSUNESS Co., Ltd...
-
Page 2: Table Of Contents
Accessories Instruction CONTENT Read Me First Warning Contact Female AC Connector (TSOL-MT-F) Accessory Size Connection Diagram Technical Data Male AC Connector (TSOL-MT-M) Accessory Size Connection Diagram Technical Data Female Protection Cap (TSOL-MP-F) Accessory Size Connection Diagram Technical Data Male Protection Cap (TSOL-MP-M) -
Page 3: Read Me First
Accessories Instruction Read Me First Dear customer, thank you for choosing the TSOL micro inverter from TSUN. We hope you will find our products meet your needs for renewable energy. Meantime, we appre- ciate your feedbacks regarding our products. This manual contains important instructions for the accessories of TSOL-M350 / M400 / M800 / M1600 micro inverter and must be read in its entirety before installing or commissioning the equipment. -
Page 4: Female Ac Connector (Tsol-Mt-F)
The connection of pin and wire is screw type which is easy for field installation. For each project the usage quantity of AC connectors is depended on the system design and at least 1 pcs. TSUN recommend the use of female AC connector. Accessory Size Connection Diagram... -
Page 5: Technical Data
Accessories Instruction Technical Data Item Parameter Type TSOL-MT-F Applicable environment temperature -40℃～+85℃ ≤95% Relative humidity 2P+PE Electrode number Nominal voltage TUV: 250V AC Nominal current 25A (4mm²) Copper alloy &silver plated Material of pin ≤1mΩ Contact resistance Pollution degree Enclosure flame class... -
Page 6: Male Ac Connector (Tsol-Mt-M)
The connection of pin and wire is screw type which is easy for field installation. For each project the usage quantity of AC connectors is depended on the system design and at least 1 pcs. Accessory Size Connection Diagram TSOL-MT-M Distribution Box Female Connector Microinverter www.tsun-ess.com... -
Page 7: Technical Data
Enclosure flame class UL94-V0 Over-voltage category Wiring Connection Screw type Insulation resistance ≥100MΩ Rated impulse withstand voltage 4000V AC Degree of protection IP68（1.5m,24h） Insertion and withdraw force(unlocked) 10～50N Applicable wire gauge 2.5/4.0 mm2 10～13mm Outer cable diameter UL6703A,EN 61535,PPP 59015A:2013 Standards www.tsun-ess.com... -
Page 8: Female Protection Cap (Tsol-Mp-F)
Protection Cap are used to give the unused AC connector an IP67 protection from water and dust. For each project the usage quantity of protection caps is depended on the system design and at least 1 pcs. TSUN recommend the use of female protection caps. Accessory Size Connection Diagram... -
Page 9: Technical Data
Accessories Instruction Technical Data Item Parameter Type TSOL-MP-F Material silicone rubber IP67 Degree of protection UL94-V0 Flame retardant rating Standards ROHS www.tsun-ess.com... -
Page 10: Male Protection Cap (Tsol-Mp-M)
Protection Cap are used to give the unused AC connector an IP67 protection from water and dust. For each project the usage quantity of protection caps is depended on the system design and at least 1 pcs. Accessory Size Connection Diagram TSOL-MP-M Male Connector Microinverter www.tsun-ess.com... -
Page 11: Technical Data
Accessories Instruction Technical Data Item Parameter Type TSOL-MP-M Material silicone rubber IP67 Degree of protection UL94-V0 Flame retardant rating Standards ROHS www.tsun-ess.com... -
Page 12: Ac Extension Cable (Tsol-Mc200-G2)
AC Extension Cable (TSOL-MC200-G2) AC connectors are used to connect the micro-inverter in terrestrial PV systems to the distribution box. The connection of pin and wire is screw type which is easy for field installation. Connection Diagram TSOL-MC200-G2 Microinverter Microinverter TSOL-MC200-G2 www.tsun-ess.com... -
Page 13: Technical Data
Accessories Instruction Technical Data Parameter Item Type TSOL-MC200-G2 TSOL-MT-F * 1 pcs Connector type TSOL-MT-M * 1 pcs Nominal voltage for connector 250V AC Nominal current 25A (4mm²) Wire gauge 4.0 mm2 Length UV resistant UL1581 Fire performance of cable... -
Page 14: Connector Assembly
Screw twisting torque 0.4±0.1N•m. after it , giving a reverse pull force lightly ( about 10N ) by manual to test crimping result. Please pay attention to avoiding damage of pins and pin-holder. www.tsun-ess.com... - Page 15 Push the male or female cable body into housing body correctly according to the position of the clamping groove , and will hear a crisp “click” sound in place. click click Push the sealing body and sealing craw into the housing body, and then tighten the end locker, torque 4.0±0.5N•m. www.tsun-ess.com...
-
Page 16: Instructions Of Operation
Please switch off the system power and ensure the male and female connector are of the same type before using; When mating connectors, align mate-locker on the male connector with grooves on the female connector, and insert gradually .Connected in place, there will be a sound of "click"; www.tsun-ess.com... - Page 17 2) Use a suitable flat screwdriver to press the elastic tongue on the male or female cable body inward and push forward slightly, and when the tongue comes off a little, use the same method to the tongue on other side. Give a force along the axial direction until separation. www.tsun-ess.com...
- Page 18 TSUNESS Co., Ltd www.tsun-ess.com sales@tsun-ess.com Building E1, No. 555, Chuangye Road, Dayun Town, Jiashan County, Jiaxing City, Zhejiang Province, China ©2018 TSUNESS. All rights reserved. All specifications are subject to change without prior notice.
