Coopers of Stortford J024 Instructions For Use

Compact Dehumidifier
Please read and retain these instructions for future reference
Features
The Compact Dehumidifier uses Peltier
technology (no compressor), which makes
it light and quiet. It is perfect for small
rooms. Poor ventilation causes musty
odours and fungus in wardrobes, larders,
cabinets or storage rooms etc. The
Compact Dehumidifier eliminates this
problem by keeping them free of
unwanted moisture.
•
To avoid electric shock. Do not open.
There are no user serviceable parts
inside.
•
Any repair work must be done by a
qualified technician.
•
Specifications are subject to change
for improvement without prior notice.
Specifications
Capacity: approximately 200ml – 250ml
per day at 30°C, 80% RH
Cooling element: thermos-electric Peltier
module
Fan: 80mm x80mm DC Brushless motor
Power adaptor: DC 9V 2.5Amp
Power consumption: 21W
Removable water tank: 500ml
Water Level Detector: Automatic switch
off with "Yellow" LED Indicator when
water tank is full.
Product dimension: 155mm (W) x 220mm
(H) x 1300mm (D)
Working environment: Over 15°C, over
40% RH (relative humidity)
Instructions for Use
J024
Connections
1. After removing the packaging materials, there should be 2
items:
a. Compact Dehumidifier.
b. AC/DC Power adaptor.
2. Plug the DC power jack of AC/DC power adaptor to the DC
power socket, then connect the AC plug of the AC/DC
power adaptor to the appropriate main socket.
3. Press the "On/Off" button to "On" position, the Compact
Dehumidifier will begin to operate. The green LED will turn
on. Listen and feel for the air blowing from dry air outlet.
4. To switch off unit, press "On/Off" button to "Off" position,
the Compact Dehumidifier will be turned off.
Removable Water tank
When the water tank is full, with approximately 500ml of
water collected, the unit will switch off automatically and the
"Yellow" LED will be on.
To remove the water tank, first switch off the Compact
Dehumidifier, press "On/Off" button to the "Off" position.
Then, remove the water tank from the unit and put the water
tank back into the unit. To continue dehumidifying press the
"On/Off" button to "On" position again.
v002: 03/10/22
