AQUAPOOL
LIGHT-ONE
Maintenance
User's Manual
Features
Tutorial
Before the drone utilization read
DRONE
carefully the informations
contained in this paper and
consult the tutorials on our
website.
Assistance
Keelcrab.com
© Aeffe srl
All the rights reserved 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KEELCRAB AQUAPOOL LIGHT-ONE and is the answer not in the manual?

Questions and answers

Summary of Contents for Aeffe KEELCRAB AQUAPOOL LIGHT-ONE

  • Page 1 AQUAPOOL LIGHT-ONE Maintenance User's Manual Features Tutorial Before the drone utilization read DRONE carefully the informations contained in this paper and consult the tutorials on our website. Assistance Keelcrab.com © Aeffe srl All the rights reserved 2022...
  • Page 2 Thank you for purchasing AQUAPOOL LIGHT-ONE® Automatic or Manual Cleaning You can decide if start automatically the cleaning or driving the drone manually using the App. Disinfection Brushes are efficient on every material, sanitizing pool surface. Temperature - Water Control The sensor constantly detects the temperature level in the pool water on the go, favoring a constant and realistic control.

  • Page 3: Table Of Contents

    INDEX 1.AQUAPOOL LIGHT-ONE®............2.IMPORTANT MAINTENANCE NOTICE........3.USE OF KEELCRAB AQUAPOOL..........4.APP....................5.HYDROSTATIC STRUCTURE.............. 6.ORDINARY MAINTENANCE..............13 6.1 Brush Replacement....................6.2 Keelcrab Bag Cleaning ....................6.3 Keelcrab Bag Replacement...................

  • Page 4: Index

    INDEX 6.4 Propeller Cleaning................... 6.5 Rubber Brush Replacement..............6.6 PVA-Wall Grip Sponges Replacement............6.7 Sanitizing Pads Replacement................ 7.EXTRAORDINARY MAINTENANCE..........

  • Page 5: Aquapool Light-One

    INDICATIONS ON USE Optimal temperature for use: from 5 ° to 35 ° C. Maximum depth of use tested by Aeffe ltd: up to 10 meters. Suggested maintenance / ordinary service (suggested): 350 hours of use. Second maintenance, extraordinary service (mandatory): 500 hours of...

  • Page 6: Important Maintenance Notice

    2.IMPORTANT MAINTENANCE NOTICE Aeffe ltd is not responsible for any damage or injury that occurs at any time and caused by poor maintenance. To extend the life of the drone, the following maintenance operations must be performed regularly: 1. Before and after each cleaning cycle, rinse the drone, brushes with fresh water, the internal section, the wall grip sponges, the shaft and the propeller.
  • Page 7 2.IMPORTANT MAINTENANCE NOTICE IMPORTANT: In case of non-execution of the ordinary maintenance as mentioned in the previous points, Aeffe ltd will not be held responsible for any future damage or injury to consumables as well as mechanical, electronic or power elements.

  • Page 8: Use Of Keelcrab Aquapool

    3.USE OF AQUAPOOL LIGHT-ONE® Lay the cable along its entire length. Connect the electronics box to a 220/110v power source. Turn on the robot by turning the on/off lever to “ON”. Immerse the drone into the water using the handle on the back of the body as far as possible.

  • Page 9: App

    4.APP 1) WI-FI - Open Wifi settings and connect: Name: KEELCRAB - Password: KEELCRAB - Open App and tap on "Wifi Connect" - Check IP server that must correspond to: 192.168.4.1 2) Control options Switch between manual or automatic mode. In case of automatic mode choose between 1,5 hour or 3 hours cleaning.
  • Page 10 4.APP 5) Diagnostic indicator light The following alarms are indicated by priority on the application: Power Supply: Power supply is out of range Overtemperature: motherboard is overheated Pump Fault: generic error about pump Traction Fault: generic error about traction Reach 500h: you used the drone for 500 hours Reach 300h: you used the drone 350 hours NOTES: When a warning is activated, the robot continues to work correctly.
  • Page 11 4.APP 6) Functionalities App connection and disconnection Connection state: online indicates connected to <name_rete> Errors state: NO Error indicates “- -" Data collection (PH, Temperature and usage time) Waterline function Manual or automatic function Time cleaning programme Current settings...

  • Page 12: Hydrostatic Structure

    5.HIDROSTATIC STRUCTURE A kit of spare floating discs is supplied  in order to be able to replace or adjust the hydrostatic set-up of the drone. If one realizes the lack of buoyancy thrust (with the engine off) of the drone, you add to the individual rollers (in all 4 and in a balanced way in order not to vary the buoyancy thrust on one side only) one disc of floating material at a time.

  • Page 13: Ordinary Maintenance

    6.ORDINARY MAINTENANCE Read all the instructions carefully for correct periodic maintenance of the following mechanical components: Brush Propeller Natural rubber brush Wall-Grip Sanitizing Pads IMPORTANT: In in each pdf manual you will find clickable images with links to the video tutorial.

  • Page 14: Brush Replacement

    6.1 Brush Replacement Note: a Φ4 mm hex wrench (Allen wrench) is required. 1) Completely loosen both screws (right and left side) and remove the brush body. WATCH BRUSHES REPLACEMENT TUTORIAL 2) Remove the belts connected to the ends of the brushes. 3) Before installing the new brush, return the toothed drive belt to the pulley and then check that the device rotates correctly.
  • Page 15 6.1 Brush Replacement...

  • Page 16: Keelcrab Bag Cleaning

    6.2 Bag Cleaning 1. Open the two filter locks before removing the filter holder. 2. After placing the filter holder rods in a vertical position, remove the WATCH BAG CLEANING TUTORIAL valve (see figure 2). 3. Open the top of the valve putting the rods in horizontal position and pulling up it.
  • Page 17 6.2 Bag Cleaning...

  • Page 18: Keelcrab Bag Replacement

    6.3 Bag Replacement 1. Unscrew washer and self-blocking from inox T bracket. 2. Place the inox T bracket as in figure 2. WATCH BAG REPLACEMENT TUTORIAL 3. Screw manually washer and self-blocking. 4. Tighten self-blocking using 7/16 wrench and philips-drill bit as in figure 4...
  • Page 19 6.3 Bag Replacement...

  • Page 20: Propeller Cleaning

    6.4 Propeller Cleaning 1. Remove the propeller section cover after placing the latches in an upright position. 2. Unscrew the screw at the head of the propeller (use a Phillips WATCH PROPELLER MAINTENANCE TUTORIAL screwdriver). 3. Remove the propeller by storing the direction of extraction (part gleaned downwards).
  • Page 21 6.4 Propeller Cleaning...

  • Page 22: Rubber Brush Replacement

    6.5 Rubber Brush Replacement 1. Place the drone as in Figure 1. WATCH BLACK RUBBER 2. Remove the three joints of the rubber brushes one at a time by REPLACEMENT bringing one end upwards and keeping the other end fixed and firm. 3.
  • Page 23 6.5 Rubber Brush Replacement...

  • Page 24: Pva-Wall Grip Sponges Replacement

    6.6 PVA-Wall Grip Sponges Replacement 1. Unscrew the side screws of the rollers at the same time (left and right) with a flat screwdriver and then remove screws and washers. WATCH WALL GRIP REPLACEMENT TUTORIAL 2. Widen the space between the roller and carter to facilitate removal. (be careful not to lose the plastic spacer).
  • Page 25 6.6 PVA-Wall Grip Sponges Replacement...
  • Page 26 6.6 PVA-Wall Grip Sponges Replacement 8. Insert the new PVA-Wall grip. WATCH WALL GRIP REPLACEMENT TUTORIAL 9. Insert transmission belts. 10. Place the roller on the central frame stop paying to block it correctly (figure 10). 11. Insert the white spacers. 12.
  • Page 27 6.6 PVA-Wall Grip Sponges Replacement...

  • Page 28: Sanitizing Pads Replacement

    6.7 Sanitizing pads Replacement Insert one or two sanitizing pads for each space at the extremes of the brush directly assembled on the drone. The pads will release slowly their substances on the surface in order to disinfect it.

  • Page 29: Extraordinary Maintenance

    7.EXTRAORDINARY MAINTENANCE Aeffe ltd  provides a customer support service in case of malfunction (read the warranty certificate for all information). In specific cases, only after the approval of Aeffe ltd,the customer can request a remote assistant and manage a replacementof the following:...
  • Page 30 Product compliant with EU regulations Aeffe Srl Via Rezzonico, 39 22100 - Como - Italy VAT no.: 03385790138 Mail: info@keelcrab.com WWW.KEELCRAB.COM © Aeffe srl, All the rights reserved 2022...
