Culver Mobility 7001R User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7001R and is the answer not in the manual?

Questions and answers

Related Manuals for Culver Mobility 7001R

Summary of Contents for Culver Mobility 7001R

  • Page 2 USER MANUAL Please , Read and follow all instructions, warnings, and notes in this manual before attempting to operate your power wheelchair for the first time. If there is any information in this manual which you do not understand, or if you require additional assistance for assembly or operation, please contact with your authorized local provider.
  • Page 3 Important Note: You need lots of practice to grasp the skill before you ride power chair safely. If you are not skilled or fail to follow the user guide of this product, it may cause rider or others injury or property loss. Our company only takes the responsibility for product defects or damage, and we are NOT responsible for physical injury or property loss related with using products.
  • Page 4 speed, stopping, moving backward, moving uphill, moving downhill and turning direction in a safe pace with less people and good road condition. Then you can officially drive on road after getting familiar with all these operations.  Do not drive the power chair after you drink, are exhausted or are not consciously clear to guarantee your safety.
  • Page 5 1. If you are not going to use the power chair for over 48 hours, Please, turn off the power switch. When bring power chair to other vehicles, make sure the battery is fixed. Battery usage: 1. Auxiliary charge: such as short delivery time, users can directly use the battery.

  • Page 6: Table Of Contents

    Contents Introduction………………………………………………..6 Quick Reference Guide……………………………………..8 Specification…………………………………………....12 Practice before operation………………………………..13 EMI warning……………………..…........15 Safety instruction………………………………………..…..23 Terminology…………………………………………..…..27 Joystick controller operation instruction…………………..28 lectric mode handle …………………………..…..34 Fold your wheelchair……………………………………..35 Adjust the controller out of length……………….………..36 Back flip rotating armrest……………………………....37 Remove the battery……………………………………..…..38 Battery application……………………………………...…..39 Warranty………………………………………......43 remote controller…………............43...
  • Page 7 Joystick Charger port on joystick Safe belt Footfest 8’ front wheel Headrest Armrest flip lock 12’ rear wheel...

  • Page 8: Quick Reference Guide

    1. electric/manual model adjust handle 2. Castor 3. Battery socket 4. Castor adjust lock 5. Backrest electric push rod 6. Push handle Packing detail 1pcs charger 1pcs remote controller 1pcs user manual 1pcs power wheelcahir 1set tools bag...
  • Page 9 A:Install the headrest Using the tools inside the buttom pack to install the headrest If you don’t know it ,kindly contact us to get the video please. 1.Take out the headrest from the carton. B:Install the joystick Lie down button Confirm button 1.This is the controller buttons look like.
  • Page 10 3.Take out the wheelchair and spare parts from the packing box. 4.Install the controller to the right or left armrest of the driver; 5.Turn on the joystick,click on the lie down button until the indicator light flash to be on the middle Then click on the confirm button till hear three beep sound , You can push the joystick forward or backward to...
  • Page 11 control the angle of the backrest. backward forward...

  • Page 12: Specification

    Specification Model Name 7001R Automatically lie down Whole product size (unfolded) 1100*630*1180mm Net Weight (With battery) 30kgs Front wheel 200mm×50mm Rear wheel 320×60 mm Loading capacity 130kg Forward speed 0-6km/h(adjustable) Range per charge ≥13KM Motor 24v/250w×2 Turning radius 600mm Battery (Lithium) 24V/26AH,24V/20AH,24V/12AH,24V/6.6AH*2...

  • Page 13: Practice Before Operation

    Failure to follow the instructions below may result in damage to the electric wheelchair or serious injury. Practice before operation Find an open area such as a park and have an assistant to help you practice until you can operate this vehicle skilled. Make sure that the power is off before getting on or off the seat.
  • Page 14 Stop, forward, and Reverse operation practice. Push the joystick in the directions as above picture show when you want to drive to the direction accordingly. First, practice moving forward. Be sure to set the speed to the lowest shift. After familiar with moving forward, practice "S"...

  • Page 15: Emi Warning

    EMI warning The rapid development of electronic technology, especially in the communication area, is filled with electromagnetic waves in our living environment, such as television, radio and communication signals. These electromagnetic waves are invisible, and its intensity is enhanced. All the electronic devices as the antenna to the electromagnetic signal and its degree of change.
  • Page 16 the once you release your hand from the joystick, it stops completely. ATTENTION： 1, Electric wheelchair buyers or users should be using electric wheelchair in the electromagnetic environment specified in the table 201,202,204,206 , otherwise it may lead to electric wheelchair not working properly.
  • Page 17 Table 201 Guidance and manufacturer's statement - Electromagnetic emission Electric wheelchair is expected to be used in the following specified electromagnetic environment, the purchaser or the user should ensure that it is used in this electromagnetic environment: Electromagnetic Environment - Launch test Compliance Guide...
  • Page 18 The ground should be wood, concrete or ±6 kV Contact ±6 kVContact Electrostatic tiles, if the ground discharge discharge discharge with synthetic ±8 kV Air ±8 GB/T 17626.2 materials, the relative discharge discharge humidity should be at least 30% ±2 kV On the The network power Electrical power cord...
  • Page 19 95%Sag） frequency Frequency magnetic field should magnetic field have the frequency （ 50 Hz/60 3 A/m 3 A/m characteristics of the Hz） frequency field in a GB/T 17626.8 typical commercial or hospital environment Note: UT refers to the AC voltage before applying the test voltage. Table 204 Guidance and manufacturer's statement - electromagnetic immunity Electric wheelchair is expected to be used in the following specified...
  • Page 20 GB/T 80 MHz 3 V/m transmitter frequency. 17626.6 Recommended isolation 3 V/m distance Radio 80 MHz～ 80 MHz～800 MHz  frequency 2.5 GHz radiation 800 MHz～2.5 GHz  GB/T 17626.3 P- According to the maximum rated output power of the transmitter provided by the transmitter manufacturer...
  • Page 21 A. Fixed transmitter, such as: wireless (cellular / cordless) telephones and terrestrial mobile radio base stations, amateur radio, AM and FM radio and television broadcasting, the field strength in theory can not accurately predict. In order to evaluate the electromagnetic environment of fixed RF transmitters, the investigation of electromagnetic sites should be considered.
  • Page 22 For the maximum rated output power of the transmitter not listed in the table above, the recommended isolation distance d, in meters (m), can be determined using the formula in the corresponding transmitter frequency column, here P is the transmitter's maximum rated output power provided by the transmitter manufacturer in watts (W).

  • Page 23: Safety Instruction

    When the following occurs, you should immediately turn off the electric wheelchair power supply: 1、Suddenly move； 2、Operation direction is not controlled； 3、 Brake failure； Safety instructions Check all screws and make sure the screws is tight every three months ! Do not carry passengers.
  • Page 24 Do not drive over deep and soft terrain (soft dirt, loose gravel, or deep grass). Do not attempt to climb stairs which height above 50mm (2") unless the slide way is installed. Do not disassemble the power wheelchair unless the electromagnetic brakes are engaged and the joystick controller is turned off.
  • Page 25 Make sure there is no obstacle behind when braking; It is recommended that the speed be the lowest when reversing. Avoid emergency braking, irregular shaking or emergency turning. Keep your arm on or in the armrest and keep your foot on the footrest. Do not cross roadsides that are more than 5mm high.
  • Page 26 Do not cross a gap that is more than 10cm wide. Precautions when driving on slopes: Driving on a slope is much more dangerous than driving on a flat road. Please note the following. Falling or losing control will happen and cause serious harm to users and others. Do not climb slopes that exceed 12°.

  • Page 27: Terminology

    Do not drive on soft, uneven or unprotected roads such as grass and gravel. Slow the speed when going downhill. It takes longer to stop the wheelchair completely when braking downhill. Do not climb up and down the slope. Stop the wheelchair before getting on and off.

  • Page 28: Joystick Controller Operation Instruction

    Drive Wheel: Wheels that move the power chair. These are the main wheels. Caster Wheel: The front wheels. WARNING Do not use electric wheelchair, in the motor is unlocked; Do not disassemble the motor, may cause the vehicle performance to decline, resulting in damage;...
  • Page 29 The operation of the controller Try to avoid knocking the controller, especially the joystick. Do not beat the controller and the joystick while traveling. Do not hit the controller. When operating a wheelchair, ensure that the control system is safe and reliable.
  • Page 30 Joystick button 1. joystick 2. Confirm button 3. Acceleration button 4. Speed indicator 5. Power button 6. Lie down button 7. Deceleration button 8. Horn 9. Battery indicator On/Off button and power display The on / off button provides power to the electronic components of the control system to provide power to the wheelchair motor.
  • Page 31 time, the power display also shows the status of the wheelchair. For details, refer to the "Controller Status Indication". Turn on the power Press the power button Each indicator will light At the same time the current battery charge will also have instructions Turn off the power Press the power button...
  • Page 32 Speed display (S1-S5) This is a speed that indicates the wheelchair setting, a total of 5 files, S1 is the lowest speed, S1 to S5 is the highest speed Horn Press the Horn, there is a sound issued. Deceleration button This button can reduce the speed setting gear, the corresponding speed indicator lights off.
  • Page 33 power on self test passes. The product can be used normally. The leftmost red Extremely low power Charge in time, or bad battery, LED is on and supply replace battery the voice alarm Two long sounds Left motor failure Check whether the left motor after two short connector is plugged into sounds...

  • Page 34: 1.Electric Mode Handle

    1.electric mode handle As long as the handle that is at the motor is down on both sides this means that you can push it manually. To change it to the electric mode, pull the handles up...

  • Page 35: Fold Your Wheelchair

    How to fold your power wheelchair Step1:pull the bottom of the buckle Step2:Grab the push handle and push forward...
  • Page 36 Step3: the power wheelchair will be folded...

  • Page 37: Adjust The Controller Out Of Length

    KIND REMIND. IF YOU FEEL HEAVY TO UNFOLD IT OR FOLD IT,PLEASE DO SOME MORE TIMES , IT WILL BE NO PROBLEM PLEASE. Adjust the controller out of length Loosen the plumb bolts under the armrest, pull the controller bracket outwards, and lock the plum bolts after pulling it to the proper position.

  • Page 38: Remove The Battery

    cannot turn the armrest independently, it is recommended that the assistant help turn the armrest of the wheelchair. Any assistant who helps a user of a wheelchair must perform appropriate training in the handling of wheelchairs. Remove the battery （ sometimes you will get alloy aluminum battery kit,which should be no problem to use please）...

  • Page 39: Battery Application

    Battery use The electric wheelchair uses a 24V battery. This is a maintenance-free sealed lithium battery. The batteries are designed to handle deep discharges. Although they are similar in performance to car batteries, they cannot be replaced. Car batteries are not designed for long periods of deep discharge and are not safe for use in electric wheelchairs.
  • Page 40 battery can achieve 90% of the effect; 2 ． When you use an electric wheelchair in your home or yard, start slowly and do not drive too far away. Until you adapt to this control system, the battery discharge is complete. 3 ．...
  • Page 41 Maintenance-free Fully enclosed lithium batteries are designed for wheelchairs and other mobile vehicles. Overall, maintenance-free, fully enclosed lithium batteries are safe, green and environmentally friendly, such as aircraft, buses and trains.We recommend that you contact the public transport department for packaging and shipping according to special performance.
  • Page 42 Do not use water to clean your wheelchair. Charger usage: 1. Carefully check whether the charger's rated input voltage (AC100-240V) and the grid voltage is consistent. 2. When the vehicle needs charging,first connect the battery to the charger, and then connect the charger to AC power source . The charging indicator is red meaning it is charging.

  • Page 43: Warranty

    Warranty: From the date of your purchase, our company provided repairs and replacements to the original purchaser. The local dealer or our company inspected and found any of the following damaged parts: ●one year for the motor and controller; ●two years for the frame; ●6 month For the battery.

  • Page 44: Remote Controller

    Remote controller: 1.Take out the wheelchair and spare parts from the packing box 2.Install the controller to the right or left armrest of the drriver. 3.take out the remote controller from the box 4.1）press the power button of the power wheelchair and turn it on. 2）press the power of the remote controller for 5 seconds.(make sure that two AAA batteries have been installed.)
  • Page 45 press the deceleration button on the joystick until the middle light on press the horn button to autopmatically match. 5）press the down arrow button until the power button of the remote controller does not flash and enter the matching state.
  • Page 46 the joystick light is off,the matching is complete. you can use the remote controller to take place the joystick function. A.press backrest button 1.Press the up arrow to lie down 2.Press down arrow the backrest back Backrest button...
  • Page 47 B.The small joystick on the remote control can replace the joystick on the powerchair to drive the powerchair Small joystick The remote control has been matched before leaving the factory, so you don’t need to match it again.When matching remote controller, if you have any questions,please contact us.
