Summary of Contents for Houseper GMB-HAR-PL1-M02
- Page 1 Smart metering plug Model Logical devices GMB-HAR-PL1-M02 1 x Smart plug User Guide version 2.0...
- Page 2 The device has a built-in module for measuring current and total electricity consumption. Connected to a Houseper system, it provides information on the cash equivalent of the energy consumption spent.
- Page 3 Functionality (Clusters) (input 0x0000) Basic (input 0x0006) On/Off (input 0x0702) Consumption metering (input 0x0003) Identify (input 0x0004) Groups (input 0x0005) Scenes Control By pressing the button once, the power supply to the consumer is toggled. ...
- Page 4 Initial power on On power up, the device will check if it has a configured ZigBee network and: a. If there is a ZigBee network configured, the device will start periodically trying to join it until it successfully joins. If you want to terminate this process, you need to execute the "Leave network"...
- Page 5 3. Follow the binding instructions of the device you want to control the plug with. It must be part of the same ZigBee network. Alternatively: When both devices you want to bind are part of a Houseper system, binding can be done via the Houseper app.
- Page 6 2. The command will return the device to its factory default settings and the device will reboot. Alternatively: If the device is a part of a Houseper system, you can execute this command through the app. * To execute this command, the device must be part of a ZigBee network. When leaving a ZigBee network, the PIN code does not return to its original value, but the last one entered is saved.
- Page 7 Lock/Unlock Submit Lock/Unlock command by pressing the button and wait for 10 blinks. A. Lock If the device is unlocked, it will lock. The blue LED indicator will blink 3 times SLOWLY, indicating that the device is now locked and no reconfiguration commands can be executed.
- Page 8 A digit greater than 9 has been entered. No digit has been entered for 10 seconds. Enable/Disable backlight 1. Submit Enable/Disable backlight command by pressing the button and wait for 12 blinks. 2. If the blue backlight is off, it will turn on and vice versa: if it is on, it will turn off. * Turning off the blue backlight does not affect the blue indication when executing commands.
