Linksys PC22604 Specifications

ProConnect II 2604 Layer 2 Management
4-Port Gigabit Ethernet Switch
Model No.: PC22604
Benefits
Benefits
• Four non-blocking,
(10/100/1000BaseTX) auto MDI/MDI-X ports
• Four Expansion slots for optional Gigabit
Ethernet (TX) or Gigabit Fiber (SX) Modules
• Supports 802.1p traffic prioritization, 802.1q
port-based VLAN tagging support, eight-high
stacking, and port trunking
• Manageable via console, telnet, web browser,
and SNMP/RMON
wire-speed Gigabit
ProConnect
ProConnect II 2604
Layer 2 Management 4-Port
Gigabit Ethernet Switch
Wire-Speed Gigabit Switching,
Manageability, and Stackability
igrate your network to Gigabit speed with the
M
ProConnect ® II 2604 Gigabit Ethernet Switch. Perfect for
today's high-speed network demands, this switch from
Linksys delivers non-blocking wire speed switching and
blazing Gigabit transfer speeds for all your network applications.
With the ProConnect II 2604 Switch as your network's backbone,
you'll connect your servers at Gigabit speeds. The four built-in
auto MDI/MDI-X ports deliver 8Gbps of non-blocking switching
performance. And as your needs grow, add Gigabit Ethernet or
Gigabit Fiber ports using the four available expansion slots. Three
Port Trunking groups eliminate bottlenecks, and you can stack up
to 8 switches and manage them as one.
The ProConnect II 2604 provides broadcast storm suppression,
has hardware MAC and IP address learning, and supports packet
filtering and port security. Partition your network into up to 256
VLANs, using port-based 802.1q tagging. Use the 802.1p packet
prioritization support to put time-sensitive data at the head of the
line. Configuration and monitoring your network performance is
a snap using the Web management interface, console, telnet, or
SNMP/RMON.
This expandable, managed switch is the perfect solution for your
Gigabit backbone.
Features
Features
• 4 RJ-45 ports for 10Base-T/100Base-TX/1000Base-TX con-
nections
• 4 Expansion slots for optional Gigabit Fiber or Gigabit Copper
modules
• Support for stacking up to 8 switches in one stack
• Port trunking support for up to 3 Port trunk groups
• Provides 8Gps non-blocking switching performance
• Supports Packet filtering and port security based on source or
destination MAC address
• Supports 802.1p/q Quality of Service, and VLAN tagging
• Traffic classification based on Port#, VLAN, and UDP/TCP logi-
cal port
• Optional expansion modules including EFPC2GE, and EFPC2SC
• Supports port mirroring for traffic analysis
• Manageable via Console, Telnet, Web, and SNMP
® II Series
