AssemblyInstructions
SwingFrame
Assembly requires at least two adults.
Read the instruction manual carefully before assembling or using the swing set.
Make sure all parts are complete, and identify and separate all parts first.
Keep this manual for future reference.
SAFETY INSTRUCTION
The safety of your children is our primary concern!
The swing frame is ONLY for domestic use, not for public use.
Do not use this swing frame on hard-packed soil, concrete, or any kind of hard surface.
The swing frame should be set on a flat surface and maintain a distance of at least 2
meters from other structures or obstacles, such as fences, garages, houses, projecting
branches, clotheslines or electric cables, etc.
People who participate in the assembly process should wear safety glasses throughout
the assembly.
Children MUST NOT use this swing frame until the installation is complete.
Choking hazard! Small parts should be kept away from children.
Children under 3 years old are not suitable for playing this product.
Children must be under supervision when they contact or use the product to prevent
the risk of falling or the strangulation of long ropes.
Periodically check and maintain the swing frame, and ensure that all hardware is in
good condition.
TOOLS NEEDED
Spanner （ included）
Tools may required (not included): Tape Measure, Hammer, Flathead and Phillips Head
Screwdriver.
Spanner(included)
- 01 -
Advertisement
Table of Contents
Summary of Contents for KloKick DR0544G
- Page 1 SAFETY INSTRUCTION The safety of your children is our primary concern! AssemblyInstructions The swing frame is ONLY for domestic use, not for public use. Do not use this swing frame on hard-packed soil, concrete, or any kind of hard surface. SwingFrame The swing frame should be set on a flat surface and maintain a distance of at least 2 meters from other structures or obstacles, such as fences, garages, houses, projecting...
- Page 2 PARTS LIST ASSEMBLYANDINSTALLATIONINSTRUCTIONS Quantity Item Picture Item Name Step 1: Assemble the top bar frame of the swing frame Connect the A1 tube and A2 tube and secure with reinforcing plate B and accessories G, TOP BAR-LEFT H and I, as shown below. NOTE: For easier assembly, do not tighten the bolts all the way initially to allow room for TOP BAR-RIGHT adjustment.
- Page 3 Step 3: Side Leg Assembly 1) Hold the other leg tube and pull it outwards until the bar hole align to the LOWER tube hole. Install the D bottom leg. Tips: Do not install the bars directly without pulling the leg tube outwards. Otherwise, you will find the side bars too long.
- Page 4 Step 5: Ground Stakes Assembly Congratulations! Place the ground stakes near the swing frame's lower legs, screw them into the ground, You have now completed installing the equipment. Please make sure to go back and then secure the stakes to the legs using K, I, F, L and M as shown below. check all hardware and ensure all bolts and nuts are securely tightened before using the playground equipment.
