KloKick DW0401L Instruction Manual

12 ft trampoline
Hide thumbs

Advertisement

Quick Links

Download this manual
12 ft Trampoline
Instruction Manual
WARNING
Please read the instruction carefully before assembling and using.
Retain this instruction for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DW0401L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KloKick DW0401L

  • Page 1 12 ft Trampoline Instruction Manual WARNING Please read the instruction carefully before assembling and using. Retain this instruction for future reference.
  • Page 2 IMPORTANT SAFETY INFORMATION To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline. Warnings and instructions for the care, maintenance, and the use of this trampoline are included to promote safe, enjoyed use of the equipment.
  • Page 3 19. Learn fundamental bounce and body positions thoroughly before trying more advanced skills. 20. Stop bouncing by flexing knees as feet come in contact with the bed. Learn this skill before attempting others. While keeping the head erect, focus eyes on the trampoline toward the perimeter.
  • Page 4 Put Your Trampoline on A Level Surface 1. The trampoline should be put on level ground to make sure the user’s safety. 2. On level ground, the user could get the most power bounce from it. 3. Never place your trampoline on a hill or somewhere that is sloping. The more sloping, the more danger the jumper will have.

  • Page 5: Table Of Contents

    Galvanized Spring Trampoline Mat with V-rings Safety Pad Upper Pole with Foam Lower Pole with Foam Safety Enclosure Net Shade Net Elastic Fastener Trampoline Bolt (set) Nut Cover Spring Loading Tool Allen Wrench Hexagon Socket Wrench Trampoline Ladder Qty. Picture Description Hook Tube Leg Tube...
  • Page 6 Paddle Ladder Bolt Cross Screwdriver (set) HOW TO ASSEMBLE MY TRAMPOLINE? Attention: Please assemble the trampoline under the following assembly instructions and thereafter go back to check before the first use. The assembly requires at least two adults. Please check and make sure all parts are complete and in good condition before assembly.
  • Page 7 Step 1. Place all tubes according to the following figure. Note: Please pay attention to the joints of the tubes. The male connectors of tubes should be connected with female connectors. Female Connector Male Connector Joint Point Step 2. Connect the leg bases (A) and the support tubes (B), as shown in the figure below.
  • Page 8 Step 3. Connect the frame tubes with leg connectors (C) to the support tubes (B). Step 4. Connect the frame tubes (D) to the frame tubes with leg connectors(c). - 07-...

  • Page 9: Galvanized Spring

    Trampoline Mat Assembly Parts Required Qty. Picture Description Galvanized Spring Trampoline Mat with V-rings Safety Pad Spring Loading Tool Step 1. Place the trampoline mat (F) inside the frame with the warning label facing up. Frame - 08-...
  • Page 10 Step 2. Attach the mat to the frame. Select a start point (marked as point “ZERO”) on the frame, then attach the spring (E) to a V-ring of the mat with the spring loading tool (T1). Spring V-ring Spring Loading Tool Frame 1.

  • Page 11: Safety Pad

    Step 3. Cover the safety pad (G) A. Place the safety pad over the trampoline mat to cover the springs. Safety Pad B. Tie the straps of the pad to the C. Hang the elastic hook of the pad to V-rings of the mat.

  • Page 12: H Upper Pole With Foam

    Trampoline Safety Enclosure Net Assembly Parts Required Qty. Picture Description Upper Pole with Foam Lower Pole with Foam Safety Enclosure Net Trampoline Bolt (set) Nut Cover Allen Wrench Hexagon Socket Wrench - 11-...
  • Page 13 Step 1. Spread the enclosure net (J) out on the trampoline mat. Make sure the sleeves of the net is outside. Safety Net Step 2. Connect the upper poles (H) and lower poles (I). Upper Pole Lower Pole Step 3. Insert the assembled poles into the sleeves in order. - 12-...
  • Page 14 Step 4. Attach the poles with the net to the leg tubes in order. Washer Spacer Notice: Fix the support poles Cover onto the legs with trampoline Screw bolts (K1) and nut covers (K2). - 13-...
  • Page 15 Step 5. Attach the hook to the nearest V-ring of the mat. DO NOT attach to the spring. Trampoline Shade Net Assembly Parts Required Picture Description Qty. Shade Net Elastic Fastener Step 1. Thread the elastic fastener (L) through the hoop of the shade net (K) and the hoop of the safety net.

  • Page 16: M Hook Tube

    Step 2. Repeat the same operation for the rest hoops. Trampoline Ladder Assembly Trampoline Ladder Picture Description Qty. Hook Tube Leg Tube Paddle Ladder Bolt Cross Screwdriver (set) - 15-...
  • Page 17 Step 1. Assemble the ladder as shown in the following figure. Washer Screw - 16-...
  • Page 18 Step 2. Put the assembled ladder to the side with a safety net opening. Notice: Hook the ladder to the frame, then cover with the safety pad. WARNING Always close the net opening before jumping. - 17-...
  • Page 19 HOW TO USE MY TRAMPOLINE? Tips to Reduce the Risk of Accidents 1. Jumper’s role in accident prevention Stay in control of your jumps. Learn fundamental bounce and body positions thoroughly before trying more advanced skills. A host of trampoline activities can be carried out by performing the basic fundamentals in various combinations.
  • Page 20 Lesson 2 1. Review and practice techniques learned in Lesson 1. 2. Knee Bounce—Demonstration and practice. Learn the basic down to knee and back up before trying half twist to left and right. 3. Seat Bounce—Demonstration and practice. Learn basic seat bounce then add a knee bounce, hands and knees;...
  • Page 21 STANDING BOUNCE 1. Start in the center of the mat, feet shoulder-width apart and eyes on the mat. 2. Swing arms forward and up and around in a circular motion. 3. Bring feet together while in mid-air and point toes downward.
  • Page 22 HOW TO MAINTAIN MY TRAMPOLINE? If proper care and maintenance are provided, it will provide all jumpers with years of exercise, fun, and enjoyment as well as reduce the risk of injury. Keep Your Trampoline Clean 1. Please take care of your trampoline and keep it clean especially when anyone use it.
  • Page 23 Be Aware Of the Conditions Below Inspect the trampoline before each use and replace any worn, defective, or missing parts. The following conditions could represent potential hazards: 1. Missing, improperly positioned, or insecurely attached frame padding, barrier or enclosure support system (frame) padding and pole caps. 2.
