Summary of Contents for SENZARY IoTlogIQ Rotary IQ
- Page 1 INSTALLATION MANUAL Phone: Senzary LLC 1-833-SENZARY 2114 N Flamingo Road #626 Email Address: Pembroke Pines, 33028 support@senzary.com www.senzary.com...
-
Page 2: Table Of Contents
Table of Contents Bob Assistant Overview Purpose of predictive maintenance Differentiating factors of the Bob Assistant 1. Quick Start-up Guide 1.1 What’s in the Box 1.2 Setting up your account online 1.2.1 Account and location (company address) creation 1.2.2 Adding device to the selected location 1.2.3 Setting up alert system 1.2.4 Setting up report system 1.2.5 Tracking the Bob Assistant... -
Page 3: Bob Assistant Overview
Bob Assistant Overview Bob Assistant Overview The Bob Assistant is a low-power LoRaWAN (a type of low- power, wide-area wireless network) compatible vibration sensor for indoor and outdoor predictive maintenance industrial applications, coupled with a temperature sensor for environmental conditions, a push-button, and an RBG LED light for user interface. -
Page 4: Purpose Of Predictive Maintenance
Purpose of predictive maintenance Purpose Of Predictive Maintenance When a machine starts breaking down, vibration drift is the first measurable symptom: The Bob sensor uses AI to predict when equipment breakdowns might occur. In the process, saving costs in machine evaluations. However, a distinction must be made between breakdowns due to wear and tear (slow drift) and breakage (fast drift). -
Page 5: Differentiating Factors Of The Bob Assistant
Differentiating Factors of the Bob Assistant Differentiating Factors Of The Bob Assistant Unlike traditional predictive maintenance Bob uses its AI to learn quickly and learn sensors, the Bob Assistant has zero infra, well! It applies analysis algorithms zero wiring, and zero configuration. To embedded in its sensor to understand and install Bob, simply place it on your monitor all of your equipment. -
Page 6: Quick Start-Up Guide
- Configure alerts and reports Click on image for video 1.2.1 Account and location (company address) creation To add and view data and performance of any sensors provided by Senzary LLC, first create an account at app.iotlogiq.com V1.0 | 03.28.2020 | Page 4... -
Page 7: Adding Device To The Selected Location
1.2 Setting up your device online Quick Start-up Guide Include your company information and location to continue. This will allow you to allocate, track and manage all devices in your specified location. At least ONE location must be created to associate a sensor to the account 1.2.2 Adding devices to the selected location To add the Bob Assistant sensor to the list of devices used by your... - Page 8 1.2 Setting up your device online button. Then tap on the option. To set up the Bob Assistant sensor to your company, tap on the You will then be taken to an Add Device page. Scan the QR code or enter the Device ID to add the sensor.
-
Page 9: Setting Up Alert System
1.2 Setting up your device online 1.2.3 Setting up the alert system You will then be directed to the Smart monitoring set up page, where you can edit alert and report settings. An alternative way to set up and edit alerts is to return to the MANAGE page by tapping on icon on the upper right side. -
Page 10: Setting Up Report System
1.2 Setting up your device online 1.2.4 Setting up the report system The Summary Report page allows you to edit the type of report received and the frequency it is received. To access the summary report page, return to the MANAGE page by tapping on the icon on the upper right side. -
Page 11: Tracking The Bob Assistant
1.2 Setting up your device online | 1.3 Gateway installation guide 1.2.5 Tracking the Bob Assistant To view the status of all devices added, tap the icon on the upper right side. Then tap MANAGE. Then tap on your company name to view all devices associated with said company. -
Page 12: Led
1.3 Gateway installation guide Example: Once the LoRa RF antenna, the Ethernet cable (if used) or the 4G/3G (with USIM card inserted) and the power supply jack connector are plugged, the Wirnet™ iFemtoCell- evolution can be powered ON by connecting the power supply. 1.3.1 LED If both LED 1 and LED 2 are solid green and do not blink, the device is operational. -
Page 13: Bob Assistant Assembly
1.4 Assembling Bob Assistant 1.4 Bob Assistant assembly 1.4.1 Magnets - default configuration Bob Assistant is delivered with a magnet kit, so you can put your device on your machine out of the box. To assemble, follow the image below: Default configuration: - These magnet references have been successfully tested as compliant with ETSI 300-019 class 5.2... -
Page 14: Quick Installation Guide
1.5 Installation guide 1.5 Quick installation guide Click on image for video To install the Bob Assistant, simply place it on the device you’re measuring. The first step when you install Bob ASSISTANT on a machine you want to monitor will be to start the device, and make sure that: o the LoraWanNetwork is reachable ( TWO GREEN LIGHTS ON YOUR GATEWAY ) o there is a certain vibration level of the machine... -
Page 15: Turning Bob Assistant On
1.5 Installation guide 1.5.1 Turning Bob Assistant ON To turn the device on, push and hold the button for 5 seconds. The LED will blink green twice and a blue light will show for 15 seconds. Bob ASSISTANT is OFF by default when delivered. In order to start Bob ASSISTANT, you need to: •... -
Page 16: Turning Bob Assistant Off
1.5 Installation guide Ensure that the machine connected to the Bob Assistant is vibrating. The device is going to try to connect to the LoRaWAN network 6 times. If it does not connect after 3 hours, try to reset the device by pushing the BUTTON for 15 seconds. (For troubleshooting help, see §2.2.4 Troubleshooting) -
Page 17: Installation And Configuration
2.1 Bob Assistant assembly options 2) Installation and configuration 2.1 Bob Assistant assembly options 2.1.1 Rivet Rivet properties: Ø4mm, length 7/10.2/13.3mm Drilling: Ø4.1mm / Ø4.2mm 2.1.2 Screw V1.0 | 03.28.2020 | Page 15... -
Page 18: Fixation Plate
2.1 Bob Assistant assembly options 2.1.3 Fixation plate In order to fasten Bob ASSISTANT on a circular surface, a fixation plate has been designed. It can be fastened using hose clamps: Default configuration: - Fixation plate (x1): • Manufacturer: EOLANE •... -
Page 19: Bob Assistant Fundamentals
2.2 Bob Assistant fundamentals 2.2 Bob Assistant fundamentals 2.2.1 Learning stages Once the Bob Assistant is installed, it will start to learn the machine cycle(s). The Bob Assistant will start its first learning sessions which will last for a few hours (~1 to 4 hours for a machine with a simple vibration cycle, e.g. -
Page 20: Monitoring
2.2 Bob Assistant fundamentals 2.2.3 Monitoring After the learning mode, Bob ASSISTANT will switch to Monitoring mode, where it will continue its reporting activity, and will start sending alarms if the drift in the vibration signature pass a defined threshold (default value is 25% drift). For each signal sampling (every 5 minutes by default), Bob ASSISTANT will process the sampled signal, and compare it to its dataset. -
Page 21: Frequently Asked Questions
Frequently Asked Questions 3) Frequently Asked Questions 3.1 Which type of equipment is well suited for Bob ASSISTANT? Bob ASSISTANT measures the vibrations of a machine and analyses its evolution over time. Vibration signature deviations are detected in real time and an alert is sent if the deviation exceeds a 25% threshold. -
Page 22: Can We Start Bob Assistant On A Machine That Is Not Running
Frequently Asked Questions 3.4 Can we start Bob ASSISTANT on a machine that is not running? If your machine is stopped during installation, you can still position Bob ASSISTANT and start it. The learning procedure will start when the equipment is back on. You must still make sure that the vibration is sufficient at this position. -
Page 23: How Do I Interpret The Gateway's Led Lights
Frequently Asked Questions 3.7 How do I interpret the gateway’s LED lights? V1.0 | 03.28.2020 | Page 21... -
Page 24: Customer Support
For additional information or if you need any assistance to use the product, please contact our customer support. Schedule a meeting with our customer support agents here: Schedule a meeting link Contact us: Phone: 1-833-SENZARY Email Address: support@senzary.com https://www.senzary.com/contact-us/ V1.0 | 03.28.2020 | Page 22...
