Model: MS-21 In-wall Streaming A/V Receiver

USB

Table of Contents

Need help?

Do you have a question about the MS-21 and is the answer not in the manual?

Questions and answers

Summary of Contents for MainStation MS-21

Page 1 User Manual Model: MS-21 In-wall Streaming A/V Receiver...
Page 2 R E A D M E F I R S T ! The MS-21 has been designed to be used in residential, commercial, and the RV environments. The MS-21 is built on an automotive platform with its associated ruggedness and reliability. It uses the Android GO operating system for efficiency.
Page 3: Safety Instructions
(servicing) instructions in the enclosure that may be of sufficient magnitude literature accompanying the product. to constitute a risk of electric shock to persons. MS-21: In-wall Streaming A/V Receiver Bluetooth • WiFi • AM • FM • AUX • USB • A/V...
Page 4 Please record the Serial Number located on the rear of the unit in the space below: S/N: Bluetooth • WiFi • AM • FM • AUX • USB • A/V MS-21: In-wall Streaming A/V Receiver...
Page 5: Table Of Contents
8. INPUTS AND OUTPUTS ................18 9. CARING FOR YOUR UNIT ................19 10. SPECIFICATIONS ................... 19 11. SERVICE ....................19 Additional information for operating the MS-21 can be found by opening the Description Application. Description MS-21: In-wall Streaming A/V Receiver...
Page 6: Installation
The MS-21 can be connected and operated from any 12-15V DC power source. For in-wall installations using 110-250V AC, where the power supply will be installed in the wall, the MS-21-IK must be used since it contains an installation frame and power supply with 4.2mm mini connector that is safety rated for in-wall installations.
Page 7: Speaker Connections
Flip up lever, insert wire fully, & flip down. Use 3rd position for connecting additional speaker. MS-21: In-wall Streaming A/V Receiver Bluetooth • WiFi • AM • FM • AUX • USB • A/V...
Page 8: Connections
Either attachment method may also be used to attach antenna next to the power input connector on the rear panel of the MS-21. Miscellaneous Connections Make any accessory connections such as Auxiliary A/V inputs and outputs, subwoofer, cameras, USB, etc.
Page 9: Attaching To The Wall
(2.5mm) IMAGE NOT TO SCALE (FOR REFERENCE ONLY) It is recommended that you predrill the mounting holes using a 3/32" (2.5mm) bit. Use the MS-21 as a template to mark the holes, ensuring the unit is level. MS-21: In-wall Streaming A/V Receiver...
Page 10: Installing Screw Caps
3/32" (2.5mm) bit. Use care to keep the tip of the driver from slipping out of the screw. Use of other screw types could lead to damage of the MS-21 if the driver slips out. Installing Screw Caps Press the supplied caps (x4) into the holes to cover the screws.
Page 11: Getting To Know Your System
GETTING TO KNOW YOUR SYSTEM Front Panel Layout The following will introduce you to the basics of the MS-21 operation and setup. For the most current information, visit www.oemsystems.com. Main Power Button: Turns power on and off. Shuts down screen. Press, to change mode.
Page 12: Navigating The Screens
STEP 3: Select Network from the Settings Menu. Your WiFi Network Your neighbor's WiFi STEP 4: Touch desired network and Enter password. Add network Bluetooth • WiFi • AM • FM • AUX • USB • A/V MS-21: In-wall Streaming A/V Receiver...
Page 13: Setting Homepage Style
STEP 2: Select Common from the Settings Menu. Settings. Select STEP 3: Select Homepage style to select a new homepage (Graphical User Interface, “GUI”) MS-21: In-wall Streaming A/V Receiver Bluetooth • WiFi • AM • FM • AUX • USB • A/V...
Page 14: Setting Default Features
NAVIGATING THE SCREENS Setting Default Features The MS-21 has been designed to be used in residential, commercial, and RV environments. The MS-21 is built on an automotive platform with its associated ruggedness and reliability. It uses the Android GO operating system for efficiency.
Page 15: Using The Radio
Station Frequency: Displays tuning frequency in MHz or KHz. Frequency Band: Displays tuning frequency; MHz = FM or KHz = AM (North America). MS-21: In-wall Streaming A/V Receiver Bluetooth • WiFi • AM • FM • AUX • USB • A/V...
Page 16: Working With Apps
Additional information Install only the Apps you will use. This will keep the memory uncluttered and allow the MS-21 to work more efficiently. Apps cannot be placed into folders or hidden. Apps on the home screen cannot be moved or changed.
Page 17: Modes Of Operation
Music The Music App allows playback of digital audio files that are stored within the MS-21 or from an SD card or USB flash drive that is inserted into one of the 3 USB inputs. The available drives and...
Page 18: Bluetooth
8. Press “Search” on the MS-21 (Top right corner). 9. When you see the default or unique name of the MS-21 appear on your phone or device, select it and enter the passcode. Note: You may need to enter scan mode again if it has timed-out. Successful connection of the paired device will show on the screen of the MS-21.
Page 19: Inputs And Outputs
USB/SD Input There is 1 USB input and 1 Micro SD input located on the front panel of the MS-21. There are 2 additional USB inputs on the rear panel. Each input is USB type A and can accept up to 32GB of storage with either FAT32 or exFAT formatting.
Page 20: Caring For Your Unit
DO NOT use harsh chemicals or alcohol for cleaning. SPECIFICATIONS DC Input Voltage (MS-21 Base Unit): ..........12-15 VDC 7A Peak Fuse Size: ..................7.5A ATM Mini AC Input Voltage Range (Power Supply Unit PS-9015): ....100 - 277 VAC Auto Select Output Power (Peak @ 4 ohms): ............
