EN
Replacing the Main Burner
W ARNING
If you wish to replace a main burner, we strongly recommend that you hire a professionally trained technician to replace it.
Please understand that we will not be responsible for any liability, personal injury, or property damage resulting from an
improperly assembled burner.
1. Remove the main burner "R" pin on the back wall of grill box with needle nose pliers.
2. Use a flathead screwdriver to remove the burner pin cover.
3. Remove the burner on the front wall of fire box.
4. Insert the new burner onto the orifice.
18
PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_User Man_V1_EN_BK1.indb 18 PR-KMY0YMPZVX_B0B8R16CS2_6 burner Gas Grill_User Man_V1_EN_BK1.indb 18
Main burner "R" pin
Burner pin cover
Burner
Burner
