Summary of Contents for Amada DUAL EZ-AIR KIT
- Page 1 (EZ/DAK) DUAL EZ-AIR™ KIT OPERATION MANUAL 990-127 REV H...
- Page 2 Copyright © 1999, 2002, 2005, 2014 - 2020 Amada Weld Tech The engineering designs, drawings and data contained herein are the proprietary work of Amada Weld Tech and may not be reproduced, copied, exhibited or otherwise used without the written authorization of Amada Weld Tech.
-
Page 3: Table Of Contents
Section I: Precautions ........................4-1 General Operator Safety ......................4-1 Section II: Operator Maintenance ....................4-1 Preventive Maintenance ......................4-1 Corrective Maintenance ......................4-1 Clearing Clogged Four-Way Valve ................... 4-3 Repair ..........................4-3 Appendix A: Specifications ........................ A-1 DUAL EZ-AIR KIT 990-127... - Page 4 The contents of this manual are subject to change without notice. Amada Weld Tech is not responsible for any loss due to improper use of this product. DUAL EZ-AIR KIT...
- Page 5 SAFETY NOTES This instruction manual describes how to operate, maintain and service the Dual EZ-Air Kit, and provides instructions relating to its SAFE use. Separate manuals provide similar information for the Power Supply and the Weld head. Procedures described in these manuals MUST be performed, as detailed, by QUALIFIED and TRAINED personnel.
- Page 6 1. Applicability. (a) These terms and conditions of sale (these “Terms”) are the only terms which govern the sale of the goods (“Goods”) by Amada Weld Tech Inc. (“Seller”) to the buyer identified in the Sales Quotation and/or Acknowledgment (as each defined below) to which these Terms are attached or incorporated by reference (“Buyer”).
- Page 7 Agreement. Buyer shall immediately discontinue use of the Software upon any termination of this license or Agreement. This license shall terminate upon any termination of the Agreement. DUAL EZ-AIR KIT 990-127...
- Page 8 (b) IN NO EVENT SHALL SELLER’S AGGREGATE LIABILITY ARISING OUT OF OR RELATED TO THIS AGREEMENT, WHETHER ARISING OUT OF OR RELATED TO BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE) OR OTHERWISE, EXCEED THE TOTAL OF THE AMOUNTS PAID TO SELLER FOR THE GOODS SOLD HEREUNDER. DUAL EZ-AIR KIT viii 990-127...
- Page 9 (whether or not relating to either party’s workforce), or restraints or delays affecting carriers or inability or delay in obtaining supplies of adequate or suitable materials, materials or telecommunication breakdown or power outage (each a “Force Majeure Event”), provided that, if the event DUAL EZ-AIR KIT 990-127...
- Page 10 27. Survival. Provisions of these Terms which by their nature should apply beyond their terms will remain in force after any termination or expiration of this Order including, but not limited to, the following provisions: Compliance with Laws, Confidentiality, Governing Law, Dispute Resolution, Survival, and the restrictions on Software in Sections 10(b), (c) and (d). DUAL EZ-AIR KIT 990-127...
-
Page 11: Chapter 1: Description
Section I: Features Features The Dual EZ-Air Kit, herein called EZ-Air, is an accessory for weld heads that pneumatically controls the actuation of the electrodes and maintains the preset firing force. At a predetermined firing force the EZ- Air closes the inlet and outlet valves to the weld head actuation cylinder and eliminates over-force. EZ- Air operates from power supply-generated power and has the following features: •... -
Page 12: Section Ii. Kit Components
EZ-Air. Shop air supply must be 85 – 140 psi (586 – 965 kPa). Fixed Air Regulator. Controls pressure of air from shop air source into EZ-Air. Regulator is factory set for 78 psi (538 kPa) and does not require any user adjustment. DUAL EZ-AIR KIT 990-127... - Page 13 Signal Cable and Connector. Two-conductor male plug to connect firing signal to the power supply. 24 Volt Power Source Cable and Connector. Conducts 24 volt solenoid drive power from the power supply to the EZ-Air. Figure 1-1. Dual EZ-Air Components DUAL EZ-AIR KIT 990-127...
- Page 14 CHAPTER 1: SYSTEM DESCRIPTION EZ-AIR-DC EZ-AIR-DC: 8-pin connector. Connects to back of the welder. Includes signals for 24VDC valve driver, firing switch and voltage sense Figure 1-2. Dual EZ-AIR-DC Cables and Connectors DUAL EZ-AIR KIT 990-127...
-
Page 15: Section Iii: Sequence Of Operation
Weld force remains constant as the air cylinder piston cannot move. The four-way solenoid valve also switches to its off position, reversing the air connections to the up and down solenoid valves. DUAL EZ-AIR KIT 990-127... - Page 16 CHAPTER 1: SYSTEM DESCRIPTION Stroke. completion of the weld, the up and down solenoid valves open. This causes application of air pressure to the lower chamber of the cylinder, returning the piston to its up position. DUAL EZ-AIR KIT 990-127...
-
Page 17: Chapter 2: Getting Started
The EZ-Air has a 1/8 inch FNPT (Female NPT) fitting for connection to a shop air source of 85 – 140 psi (586 – 965 kPa). It is recommended that an auto drain air filter with a 5-micron element (Amada Weld Tech Part Number 10-373-01, catalog number ADAF) be placed in the air line. -
Page 18: Section Ii: Ez-Air Set-Up
Unpacking Unpack the EZ-Air from its shipping box and verify that all parts are present. Table 1-2 lists the components of the ship kit, Amada Weld Tech Part Number 4-81109-01, which contains parts needed to install the EZ-Air. NOTE: Carefully place the packing materials back in the packing boxes and store for future shipping. -
Page 19: Installing The Ez-Air
Air is in the vertical support slot, tighten the mounting screw. CAUTION: Be sure no part of the EZ-Air touches the copper power bars; any contact Figure 2-2. Installing EZ-Air will cause shorting of the weld current. 4. Re-install the vertical support end cap. DUAL EZ-AIR KIT 990-127... -
Page 20: Section Iii: Pneumatic And Power Connections
A Connect weld head driver cable to connector labeled WELD HEAD on the power supply. B Connect voltage sense cable between EZ-AIR-DC and electrodes, if desired. Figure 2-3. Installation of New Elbow Fittings and Pneumatic Tubes DUAL EZ-AIR KIT 990-127... -
Page 21: Chapter 3: Operating Instructions
EZ-Clean valve can be actuated to purge the air during electrode dressing. To do so, push the EZ-Clean (red) slide valve away from the EZ-Air. To restore pressure, slide the valve toward the EZ-Air. DUAL EZ-AIR KIT 990-127... -
Page 23: Chapter 4: User Maintenance
Corrective Maintenance The only recommended user corrective maintenance is clearing foreign matter that might jam a valve open. If the weld head fails to move up or down, refer to table 4-1 and perform the actions prescribed. DUAL EZ-AIR KIT 990-127... - Page 24 (first position for two-step foot switches). Green firing indicator on side of Speed Control valve Contact company weld head that does (of side that doesn’t representative. not go downward move) is stuck. lights. DUAL EZ-AIR KIT 990-127...
-
Page 25: Clearing Clogged Four-Way Valve
EZ-Air cover (figure 4-1). Repair Access to If problems cannot be resolved using the above four-way troubleshooting table, contact Amada Weld Tech at the valve address/telephone/fax shown in the Foreword. override Figure 4-1. Location of Four- Way Valve Override... -
Page 27: Appendix A: Specifications
An auto drain air filter with a 5-micron element (part number 10- Compressed air 373-01, catalog number ADAF) is recommended. Requirements CAUTION: Compressor supplying air must not be lubricated with synthetic oil. 60 - 113ºF (15.5 - 45ºC) Operating Environment 93% Relative Humidity (maximum) at 104ºF (40ºC) DUAL EZ-AIR KIT 990-127... - Page 28 APPENDIX A: SPECIFICATIONS Outline Drawing (Dimensions are in inches) DUAL EZ-AIR KIT 990-127...
- Page 29 TEL. +1-626-303-5676 FAX, +1-626-358-8048 http://www.amadaweldtech.com AMADA WELD TECH CO., LTD. 200, Ishida, Isehara-shi, Kanagawa 259-1196, Japan AMADA WELD TECH KOREA CO., LTD. 28, Dongtanhana 1-gil, Hwaseong-si, Gyeonggi-do, 18423, Korea TEL. +82-31-8015-6810 FAX. +82-31-8003-5995 AMADA WELD TECH SHANGHAI CO., LTD. Unit 401, A206(C8), No. 77, Hongcao Road, Xuhui District, Shanghai, China TEL.
- Page 30 AMADA WELD TECH INC. 1820 South Myrtle Ave., Monrovia, CA 91016, U.S.A. TEL. +1-626-303-5676 FAX. +1-626-358-8048...
