Summary of Contents for Hypex Electronics FusionAmp OLED Display
- Page 1 Fusion OLED Display User Guide...
-
Page 2: Table Of Contents
13. Changes or modifications not expressly approved by persons. Hypex Electronics will void compliance and therefore the user's authority to operate the equipment. The exclamation point within an equilateral triangle is intended to alert the user of the prescence of important 14. -
Page 3: Parts
Parts FRONT BACK Cable 1250mm Details 1: Protective foil 2: IR remote receiver 3: Transparent display area 4: Cable entry to DSP 5: Adhesive tape 6: Flex-cable... -
Page 4: Dimensions
Dimensions (mm) 20.14 -(≥10.5) -2.5... -
Page 5: Preparations, Mouting And Connecting
Preparations, mounting and connecting ❶ ❷ ❸... - Page 6 ❹ FusionAmp ❺...
-
Page 7: Connections
Connections Direction Function J1:1 Input +3V3 Output IR output J1:2 J1:3 Input Front LED1 J1:4 Input Front LED2 J1:5 Connector type JST B5B-ZR Remote Control 1: IR transmitter 2: Power on/off 3: Preset 1 4: Preset 2 5: Preset 3 6: (not used) 7: Input previous 8: Input next... -
Page 8: Notifications
Notifications Default Startscreen / Power Standby Auto source Warning High Warning Clipping Idle Scanning Temperature Feedback EQ ON EQ OFF PR-1 Current Volume Mute Equalizer Enabled / Disabled Preset Number Source SPDIF Analogue Balanced Analogue Unbalanced Digital Coaxial Digital Balanced SCAN Digital Optical High Level input... -
Page 9: Settings
Settings HFD provides the possibility to adjust the brightness of your display. Options: Active brightness (0-15) Idle screen brightness (1-15 / 0 = OFF) ❶ Make sure the Fusion Amp is powered on. Connect it with USB to the computer. Open the latest HFD (v4.97 or higher) and press Device settings. -
Page 10: System Information, Troubleshooting
System information Frequently asked questions How many Fusion OLED Displays can I use in Performance: a master and slave setup? 96x64 Pixels You can use a Fusion OLED Display with every 65536 Colors Fusion amp in your chain. Basically you only need one at your master device. -
Page 11: Disclaimer
Limited Warranty Revisions Hypex Electronics warrants this device for a period Revision Comment Date of two years (B2C) after the original date of Doc. HW. p u r c h a s e a g a i n s t d e f e c t s d u e t o f a u l t y... - Page 12 Hypex Electronics BV Kattegat 8 9723 JP Groningen, The Netherlands +31 50 526 4993 sales@hypex.nl www.hypex.nl...
