Page 1 CAM-UNI Universal Camera User Guide PL 698 Rev A (12/2020)
Page 2: Table Of Contents
INSTALLATION ................. 12 CAMERA SYSTEM HOOK UP TO PEDESTAL STYLE STONEAGE CONTROL BOXES ..12-13 CAMERA SYSTEM HOOK UP TO CB-ABX OR CBX-ABX STONEAGE CONTROL BOXES .
Page 3: Manufacturer's Information
The camera system does not have recording capability, WIFI, or Bluetooth, it is only intended for real-time imagery. • The camera system is intended to be used with all StoneAge automated equipment. DESCRIPTION OF EQUIPMENT AND INTENDED USE The Universal Camera system is a product designed that removes the worker(s) from the work area. Despite the remote operation of the equipment, the operator will need to see with detail the work area.
Page 5: Ec Declaration Of Incorporation
The Technical File for Universal Camera System (CAM-UNI) is maintained at: StoneAge Incorporated, 466 South Skylane Drive, Durango, CO 81303, USA and was compiled by the Engineering Manager. The Technical File is available through the Authorized Representative. This Declaration of Conformity is issued under the exclusive responsibility of StoneAge Incorporated.
Page 6: Warning And Safety Instructions
StoneAge has designed and manufactured this The risk assessment MUST consider potential material or equipment considering all hazards associated with substance hazards including: its operation. StoneAge assessed these risks and Aerosols • incorporated safety features in the design. StoneAge Biological and microbiological (viral or bacterial) •...
Page 7: Personal Protective Equipment Requirements
PERSONAL PROTECTIVE EQUIPMENT PPE may include: REQUIREMENTS • Eye protection: Full face visor • Foot protection: Kevlar ® brand or steel toe capped, Use of Personal Protective Equipment (PPE) is dependent on the working pressure of water and the cleaning waterproof, non-slip safety boots application.
Page 8: Product Overview
UNIVERSAL CAMERA (CAM-UNI-PKG) UNIVERSAL CAMERA PACKAGE CONTENTS 1m and 10m Camera Cables Pedestal US or EU Power Monitor Mount Connector Camera Bracket Camera Assembly Cable Tie Monitor Assembly and Hardware Power Pack Assembly Ball Grip Positioning Assembly Camera Case...
Page 9: Universal Camera Package Shown On Cb-Abx And Cbx-Abx Control Boxes
UNIVERSAL CAMERA PACKAGE CONTENTS SHOWN ON CB-ABX AND CBX-ABX STYLE CONTROL BOX Monitor Assembly and Hardware CB-ABX or CBX-ABX Control Box Monitor Mount Power Pack Assembly US or EU Power Camera Connector Assembly on Camera Cable...
Page 10: Universal Camera Package Shown On Pedestal Style Control Box
UNIVERSAL CAMERA PACKAGE CONTENTS SHOWN ON A PEDESTAL STYLE CONTROL BOX Monitor Assembly and Hardware Pedestal Style Control Box Monitor Mount Power Pack Assembly US or EU Power Connector Camera Assembly on Camera Cable...
Page 11: Universal Camera Mounting Options
UNIVERSAL CAMERA MOUNTING OPTIONS SHOWN WITH THE BALL GRIP POSITIONING ASSEMBLY Camera Assembly Camera Bracket Ball Grip Positioning Assembly Mounted to a Striker Arm Mounted to Positioner Air Motor Mounted to an ABX Tractor Handle Mounted to an ABX Hose Guide...
Page 12: Installation
CAMERA SYSTEM HOOK UP TO PEDESTAL STYLE STONEAGE CONTROL BOXES 1. Attach the Monitor to the Monitor Mount Assembly with the supplied screws, washers, and wing nuts as shown in the figure below. Tighten by hand. 2. Loosen the thumb screws on the Controller box and Monitor Mount. Remove the Controller Box from the stand and slide the Monitor Mount onto the Stand.
Page 13 6. Screw the Camera onto the male end of the Camera Cable. The Camera can be mounted in a variety of ways. (See StoneAge user manuals for the correct mounting procedures related to StoneAge equipment.) 7. Plug the US or EU power cable connector into the opposite side of the Power Pack.
Page 14: Camera System Hook Up To Cb-Abx Or Cbx-Abx Stoneage Control Boxes
CAMERA SYSTEM HOOK UP TO CB-ABX OR CBX-ABX STYLE STONEAGE CONTROL BOXES 1. Remove the two Torx screws from the back of the Control Box. 2. Position the CAM 603-C Bracket as shown and attach with the two Torx Screws previously removed from the Control Box.
Page 15 7. Screw the Camera onto the female end of the Camera Cable. The Camera can be mounted in a variety of ways. (See StoneAge user manuals for the correct mounting procedures related to StoneAge equipment.) 8. Plug the US or EU power cable connector into the opposite side of the Power Pack and the other end into the appropriate outlet.
Page 16: Troubleshooting
TROUBLESHOOTING 1. Each label has an indicator light next to it, as shown below. 2. When the indicator light turns red, it means the cable and/or equipment on that port has a fault and is damaged and requires replacement. Indicator Light...
Page 17: Part Diagrams
UNIVERSAL CAMERA (CAM-UNI-PKG) UNIVERSAL CAMERA PACKAGE PART NUMBER CAM 327-??? POWER CONNECTOR ASSEMBLY CAM 603-P PEDESTAL MONITOR MOUNT CAM-UNI UNIVERSAL CAMERA SYSTEM...
Page 18 UNIVERSAL CAMERA (CAM 327-??) POWER CONNECTOR ASSEMBLY US OR EU -EU PART NUMBERS -US PART NUMBERS CAM 298-001 AC EUROPEAN PLUG CAM 217-002 AC CORD PIGTAIL CAM 320.1 CIRCULAR CONNECTOR 2 PIN CAM 320.1 CIRCULAR CONNECTOR 2 PIN...
Page 19 UNIVERSAL CAMERA (CAM 603-X) PEDESTAL MONITOR MOUNT PART NUMBER CAM 603-C CAM 603-P CAM 149 10-24 WING NUT CAM 331 CBX MONITOR MOUNT CB 488 MONITOR MOUNT ASSY GS 319-02 SHCS 10-24 x .50 SS GW 319-F WASHER, FLAT #10 SS PROP 440-24 CAMERA MOUNT ASSY FOR DBP...
Page 20 UNIVERSAL CAMERA (CB 488) MONITOR MOUNT ASSEMBLY PART NUMBER CB 726 THREE LOBE KNOB, .25-20 CAM 149 10-24 WING NUT GN 319-L-32 NUT, NYLOK 10-32 SS CB 489 MONITOR BRACKET GS 319-02 SHCS 10-24 X .50 SS CB 724 MODIFIED COLLAR GS 319-02-32 SHCS 10-32 X .50 SS CB 725 THREAD LOCKING SLOTTED INSERT, GW 319-F WASHER, FLAT #10 SS...
Page 21 UNIVERSAL CAMERA (PROP 440-24) CAMERA MOUNT ASSEMBLY FOR DBP PART NUMBER -24/QTY DB 242 DOWEL PIN, .25 OD x 1.125 LENGTH HRS 530 HANDLE, ADJUSTABLE PROP 441-24 PLATE, CAMERA CLAMP 1.5 INCH...
Page 22 UNIVERSAL CAMERA (CAM-UNI) UNIVERSAL CAMERA SYSTEM *The CAM 246 Camera Cable is a 1 meter cable that is very flexible. *The CAM 248 Camera Cable is a 10 meter, more robust, less flexible cable PART NUMBER CAM 231 UNIVERSAL CAMERA BRACKET...
Page 23 UNIVERSAL CAMERA (CAM 083-K) BALL GRIP POSITIONING ASSEMBLY PART NUMBER CAM 082 1/4”-20 THREADED STUD BASE FOR BALL GRIP CAM 085 BALL GRIP POSITION ARM, PIPE MOUNT CLAMP 1.5 O.D. CAM 087 BALL-GRIP POSITIONING ARM GN 525-H NUT, HEX .25-20 GW 525-F WASHER, FLAT .25...
Page 24 UNIVERSAL CAMERA (CAM 102-V2) MONITOR ASSEMBLY PART NUMBER CAM 283 VELCRO CAM 102.1 MONITOR GPHS 0125-OLE-A-BK-0500 HEAT SHRINK, .125 ID X .500 LG BLACK CAM 149 10-24 WING NUT GS 319-02 SHCS 10-24 X .50 SS CAM 199 CONEC M12 SCREW TERMINAL MALE 8 POS GS 319-06 SHCS 10-24 X 1.50 SS GN 319-H NUT, HEX 10-24 SS GW 319-F WASHER, FLAT #10 SS...
Page 25 UNIVERSAL CAMERA (CAM 220) CAMERA ASSEMBLY PAGE 1 NOTES: 1. APPLY TO O-RINGS DURING ASSEMBLY: MOLYKOTE 2. APPLY GREEN RETAINING COMPOUND, LOCTITE PN:290 OR EQUIVALENT TO COMPONETS AS NOTED. 3. ENSURE HOUSING ENGRAVING “TOP” AND CAMERA LABELS ARE CLOCKED UPWARDS. 4.
Page 26 UNIVERSAL CAMERA (CAM 220) CAMERA ASSEMBLY PAGE 2...
Page 27 UNIVERSAL CAMERA (CAM 330) CAMERA CASE ASSEMBLY PART NUMBER CAM 330.1 CAMERA ASSEMBLY CASE CAM 330.4 UCS FOAM CAM 330.3 HALF PANEL...
Page 28: Terms And Conditions And Warranty
Terms and Conditions of Sale (“Terms and Conditions”) shall shall pay all charges for transportation and delivery and all operate as the acceptance by StoneAge, Inc. (“Seller”) of the excise, order, occupation, use or similar taxes, duties, levies, order submitted by the purchaser (“Buyer”). Such acceptance...
Page 29 STONEAGE TRADEMARK LIST be submitted to a court of competent jurisdiction in accordance View the list of StoneAge’s trademarks and service marks and learn how with the terms hereof. These procedures are the exclusive the trademarks should be used. Use of StoneAge trademarks may be procedures for the resolution of all such disputes between the prohibited, unless expressly authorized.
Page 30 Unauthorized service, repair or modification of the Product or use of parts not approved by StoneAge will void 1. LIMITED WARRANTY PERIOD. Subject to the limitations this Limited Warranty. StoneAge reserves the right to change...
Page 31 DAMAGES (INCLUDING WITHOUT LIMITATION, LOSS OF from StoneAge or a Dealer. No Product may be returned for PROFITS, LOSS OF GOODWILL, DIMINUTION OF VALUE, credit or adjustment without prior written permission from WORK STOPPAGE, INTERRUPTION OF BUSINESS, RENTAL StoneAge.
