VS Sassoon VS5548K Instruction Booklet

VS 1800W PROFESSIONAL DRYER
The VS 1800W PROFESSIONAL DRYER has 1800W of power
for fast drying. It has 3 heat / 2 speed settings and comes with a
concentrator nozzle.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, especially when children are
present, basic safety precautions should always be followed,
사 용 설 명 서 including the following:
READ ALL INSTRUCTIONS BEFORE USING
KEEP AWAY FROM WATER
SAFETY PRECAUTIONS
WARNING: The polyethylene bags over the product or
its packaging may be dangerous. Keep these bags out
of the reach of babies and children.
Never use them in cribs, children's beds, pushchairs or
playpens. The thin fi lm may cling to the nose and mouth
and prevent breathing. A bag is not a toy.
WARNING: Do not use this appliance near bathtubs,
showers, basins or other vessels containing water.
1. If you are using the unit in a bathroom, unplug it after
you have fi nished using it. Using the unit close to a
source of water can, in fact, be dangerous, even if the unit is
switched off. To ensure additional protection, have installed in
your bathroom a residual current device (RCD) with a nominal
trip current no higher than 30 mA. Ask your electrical fi tter for
advice.
2. Never immerse the unit in water or any other liquid.
3. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualifi ed persons in
order to avoid a hazard.
4. When using the unit, make sure the unit's air vent is not blocked.
Make sure there is no hair or any other dirt obstructing the unit's
rear fi lter.
5. This unit has been equipped with a temperature cut-out. If the
1800W
unit overheats, it will shut off automatically or will stop heating.
PROFESSIONAL DRYER
If this happens, slide the switch on the unit's handle into the
OFF position, unplug the unit and allow it to cool for 10 minutes.
1800W
BEFORE using it again, make sure there is no hair or any other
프로페셔널 드라이어 dirt in the unit's rear fi lter. Plug the unit in and switch it on. If
it overheats again, stop using it immediately, switch it off and
unplug it. Return the unit to the CONAIR service centre.
6. Do not use the unit if it has fallen or if it appears to be damaged.
7. Do not leave the unit unattended when it is plugged in or
switched on.
8. Unplug the unit immediately if you have problems when using it.
9. Do not use any accessories other than those recommended by
manufacturer.
10. Unplug the unit after each use and before cleaning it.
11. Avoid any contact between the unit's hot surfaces and your
skin, in particular, your ears, eyes, face and neck.
12. This unit is not intended for use by people (including children)
with reduced physical, sensory or mental capabilities, or by
persons who lack experience or knowledge, unless they are COOL SHOT BUTTON
supervised or have been given instructions beforehand on the Use the cool shot button on warm hair to set the wave or curl in place
use of the unit by a person responsible for their safety. Children for a really long lasting effect.
should be supervised to make sure they do not treat the unit
like a toy.
STYLING TIPS
13. Allow the unit to cool before storing.
BODY & VOLUME
14. To prevent damage to the cord, do not wrap it around the unit
To help create extra body and volume in the hair, tilt your head
and ensure it is stored without twisting or folding it.
forward so the hair is upside down when drying. Position the airfl ow
towards the roots for maximum lift. When hair is dry brush in to
FEATURES:
desired style.
1. 1800W
2. 3 heat / 2 speed settings
3. Cool shot button STRAIGHTENING
4. Concentrator nozzle To create a super straight look, fi rst divide the hair into sections then
5. Hanging loop using a brush and the concentrator nozzle, hold hair taut and let the
brush glide down the hair as you dry.
CLEANING THE FILTER
• Ensure the appliance is switched off, unplugged and cool.
1 1
• Holding the handle of the dryer using the raised thumb grips
4 4
push the rear fi lter away from the dryer.
• Using a soft brush, clean any hair and other debris from the
fi lter.
• Replace the rear fi lter by pushing back into position.
IMPORTANT!
3 3 • This appliance should only be used as described within this
instruction booklet. Please retain for reference.
2 2
USER MAINTENANCE
Your dryer is virtually maintenance-free. No lubrication is needed.
For proper operating performance, the dryer must be kept clean.
Blocked or clogged air intake vents will cause the dryer to overheat.
When cleaning is needed, unplug the cord, and clean dust and lint
from air intake openings with a small brush or the brush attachment
5 5
of a vacuum cleaner. The outer surface of the dryer should be wiped
clean with a damp cloth only.
CAUTION
NEVER allow the power supply cord to be pulled, twisted, or severely
bent. Never wrap the cord tightly around the dryer. Damage will occur
INSTRUCTIONS FOR USE
at the high fl ex point of entry into the dryer, causing it to rupture and
GENERAL
short. Inspect the cord frequently for damage. Stop use immediately
• Towel dry and detangle the hair.
if damage is visible or unit stops or operates intermittently.
• There are 3 heat / 2 speed settings. Use a high heat/speed
setting for rough drying. Use the low heat/speed setting as hair
STORAGE
begins to dry and for styling and scrunch drying.
When not in use, your dryer should be disconnected and stored in
• Use the cool shot button on warm hair to "set" a curl or wave.
a safe, dry location, out of reach of children. Do not wrap line cord
• After use, switch off and unplug the appliance. Allow to cool
around dryer.
before storing away.
THE DATE CODE MENTIONED
HOW TO USE THE CONCENTRATOR NOZZLE
WWYYXXX was mentioned on unit as manufactured date so
The concentrator nozzle is great for straightening or styling
you can see W as week and Y as year for your reference.
hair with a brush. Use the professional concentrator nozzle for
directing the air just where you want it. For additional control use one
of the lower settings and point the air-fl ow along the surface of the
hair to be dried.
CONTINENTAL CONAIR LIMITED
CHINA CREATIVE DEPARTMENT
Date
Customer
Model No.
Description
Job No.
Reference No.
Revision No.
Color
Open Size
Folded Size
Material
Prepared by
Approved by
Vendor
Supplier
수입 판매원
IB-14/095
VS5548K
05/02/2014
VS-KOREA(K)
VS5548K
IB
14VS057
IB-14/095
0
1C+1C(Black)
552mm(W) X 214mm(H)
92mm(W) X 214mm(H)
80gsm Artpaper
Edna Cheng
Jimmy Ng/Elodie Lee
Yueli
