PCB Piezotronics IMI SENSORS M622B01 Installation And Operating Manual page 18

Model Number
PLATINUM PRECISION INDUSTRIAL ICP® ACCELEROMETER
622B01
Performance
Sensitivity(± 5 %)
Measurement Range
Frequency Range(± 5 %)
Frequency Range(± 10 %)
Frequency Range(± 3 dB)
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Enclosure Rating
Electrical
Settling Time(within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Electrical Protection
Electrical Isolation
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
[6]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ENGLISH SI
100 mV/g 10.2 mV/(m/s²)
± 50 g ± 490 m/s²
35 to 360,000 cpm 0.58 to 6000 Hz
25 to 600,000 cpm 0.42 to 10,000 Hz
12 to 900,000 cpm 0.2 to 15,000 Hz
1800 kcpm 30 kHz
2
50 µg
490 µm/sec
± 1 % ± 1 %
≤ 5 % ≤ 5 %
5000 g pk 49,050 m/s² pk
-65 to +250 °F -54 to +121 °C
See Graph See Graph
IP68 IP68
≤ 5.0 sec ≤ 5.0 sec
≥ 0.8 sec ≥ 0.8 sec
18 to 28 VDC 18 to 28 VDC
2 to 20 mA 2 to 20 mA
<100 Ohm <100 Ohm
8 to 12 VDC 8 to 12 VDC
2
4.0 µg/√Hz
39.2 (µm/sec )/√Hz
2
0.8 µg/√Hz
7.85 (µm/sec )/√Hz
2
0.4 µg/√Hz
3.92 (µm/sec )/√Hz
RFI/ESD RFI/ESD
8 8
>10 Ohm >10 Ohm
7/8 in x 2.06 in 22 mm x 52.3 mm
3.3 oz 94 gm
1/4-28 Female No Metric Equivalent
2 to 5 ft-lb 2.7 to 6.8 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
2-Pin MIL-C-5015 2-Pin MIL-C-5015
Top Top
OPTIONAL VERSIONS
[2]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[3]
- Hazardous Area Approval- contact factory for specific approvals
EX
[1] M - Metric Mount
Supplied Accessory : Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1)
[1]
[4]
TO - Temperature Output
Temperature Output Range
Temperature Scale Factor
Electrical Connector
Electrical Connections(Pin A)
[1]
Electrical Connections(Pin B)
Electrical Connections(Pin C) Temperature Output
[1]
[1]
[1]
NOTES:
[1] Typical.
[2] Conversion Factor 1g = 9.81 m/s².
[3] The high frequency tolerance is accurate within ±10% of the specified frequency.
[4] Zero-based, least-squares, straight line method.
[5] 1/4-28 has no equivalent in S.I. units.
[5]
[6] See PCB Declaration of Conformance PS023 or PS061 for details.
[7] EEx ia IIC T4.
SUPPLIED ACCESSORIES:
Model 081A40 Mounting Stud (1)
Model ICS-1 NIST-traceable single-axis amplitude response calibration from 600 cpm (10 Hz) to
upper 5% frequency (1)
Entered: LK Engineer: gs Sales: MC
Date: 7/31/2017 Date: 7/31/2017 Date: 7/31/2017
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 47050
+36 to +250 °F +2 to +121 °C
5.56 mV/°F + 32 +10 mV/°C
3-Pin 3-Pin
Acceleration Output Acceleration Output
Ground Ground
Temperature Output
Approved: NJF Spec Number:
35885
Date: 7/31/2017
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
[7]
[5]
