Page 1: Table Of Contents
Sensors Setting up a Modbus IP Network on the Hub: Creating gateway Adding properties 25-26 Modbus table Download tables Support Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 1 of 27...
Page 2: Safety Rules
When power for SELV or PELV circuits is obtained from higher voltage power systems, it shall be provided by a safety transformer or converter designed for continuous operation to power the SELV or PELV circuits. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved...
Page 3: Markings
Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved...
Page 4 Kent - TN8 6AB - UK The cellular antenna delivered by Sontay meets the FCC-IC regulations. If the installer makes the choice to use another antenna, it must follow the specifications listed for the device used to comply with FCC/IC regulations limiting both maximum RF output power and human exposure to RF radiation.
Page 5: Power Supply
USB Micro 55mm RS485 Interfaces 1 & 2 110mm USB 2.0 interfaces 1 & 2 Ethernet interfaces 1 & 2 Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 5 of 27...
Page 6: Installation Guide
You can either copy/past the code into the Web browser or click on the ’Start now’ link. Once this is completed you are then ready to start using the Hub. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved...
Page 7: Adding New Users To The Organization
Then click on "Save", your user is now ready to work. • (*): You can find here the signification of the different rights, and made a custom one if needed. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 7 of 27...
Page 8: Powering The Hub
LED if it is not suitable. Change the power supply to avoid damaging the Hub. • Wait about 10 seconds: the "Heartbeat" LED flashes (green light). Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 8 of 27...
Page 9: Gsm Antenna
Please note that, beyond 15 meters of cable, the GSM signal is significantly weakened. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved...
Page 10: Connecting The Hub To Lorawan Sensors
If the quality of the LoRa signal is good: keep the original antenna installed on the Hub. You can check the quality of the LoRaWAN signal using the with the Sontay User Console. Once the Box and the LoRaWAN device are paired you can verify the quality of the signal.
Page 11 Once you have made your selections, click ‘Save’ • Pop up box will appear, you can either ‘add another equipment’ or go ‘Check Box configuration’ Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 11 of 27...
Page 12 During the pairing period the ‘Error’ & ‘Status’ LED’s will blink together every 10 seconds. When paired just the ‘Status’ LED will blink every 30 seconds. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved...
Page 13: To Connect The Hub To The Bms
Write down the BACnet port of the network. This information will be necessary for the installation configuration and to retrieve data. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 13 of 27...
Page 14: Bacnet Ip
Connect the other end of this cable to the Ethernet switch. • Check that the LED ETH1 or ETH2 lights up. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 14 of 27...
Page 15: Modbus Ip
Connect the other end of the cable to the equipment. • Verify that the LED ETH1 or ETH2 lights up. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 15 of 27...
Page 16 Connect an Ethernet cable to the Ethernet port of the Hub ETH1 or EHT2. • Connect the other end of this cable to the Ethernet switch. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 16 of 27...
Page 17 Write down the BACnet port of the network. This information will be necessary for the installation configuration and to retrieve data. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 17 of 27...
Page 18: Setting Up A Bacnet Ip Network On The Hub
If ETH1 is configured for 192.168.1.xxx, then enter 192.168.0.xxx or 10.0.20.xxx for ETH2 for example. Click on the Hub ‘Configuration’ tab on the Sontay User Console, then click on the ‘Connectors’ tab. A list of available connections should be visible, including ETH1 and ETH2 at the top of the list.
Page 19: Setting Bacnet Ip Gateway
When you’ve filled in the settings, don’t forget to click the ‘Save’ button at the bottom right of the screen. Setting up a BACnet IP Gateway Click on the ‘Hub Configuration’ tab of the Sontay User Console, then click on the ‘Gateways’ tab. Sontay No records to display Click on the ‘Create new gateway’...
Page 20 Here you can also give the hub a name and location. NB - Click ‘Save’ at the bottom of the screen when complete. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved...
Page 21: Adding Device Points To The Gateway
Click the ‘Save Changes’ button at the bottom of the screen. Then ‘Send to the Box’ All BACnet points that were selected will then be available to view. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 21 of 27...
Page 22: Bacnet Pics
A BACnet Gateway (B-GW) mapping Wsgateway data input, outputs and values into BACnet objects from a single BACnet device. The Sontay data are referred as all the properties that a Sontay Hub is able to read or write from different HVAC protocols, such as ModBus, Mbus, LON.
Page 23: Hub
The number of objects is determined by the client of the Sontay Hub. This is done by means of local mechanism outside of this scope. The Sontay Hub doesn’t support BACnet services such as CreateObject and/or DestroyObject.
Page 24: Sensors
“Spreading Factor (SF)” Object_Type Analog Input (0) Out_Of_Service FALSE Present_Value Signal Noise Ratio in Decibels Status_Flags {FALSE, FALSE, FALSE, FALSE} Units Decibels Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 24 of 27...
Page 25: Setting Up A Modbus Ip Network On The Hub
Important information: SlaveID needs to be unique in order to avoid conflict Step 3: To add properties in your gateway, select the "Properties" button Click on the "Add Property" button. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved 25 of 27...
Page 26: Modbus Table
Be sure that your Modbus IP client configuration is matching these parameters. Tel: +44 (0)1732 861200 - E-mail: sales@sontay.com - Web: www.sontay.com © 2017 Sontay Limited. All rights reserved...
Page 27: Download Tables
The support team will get back to you as soon as possible. Whilst every effort has been made to ensure the accuracy of this specification, Sontay cannot accept responsibility for damage, injury, loss or expense resulting from errors or omissions. In the interest of technical improvement, this specification may be altered without notice.
