BP RSE AD 10.6

Trouble Shooting

Nature of issue
Possible causes
No sound and image
Power disconnected or the device off
Undervoltage
Black screen
1. Press the power key and then press and hold it for 3s to shut it down
Abnormal start
2. Press the reset key to restart the system
Refresh the network or close and re-open WIFI
WIFI cannot connected
Wrong function menu setup or incorrect model
Color shift
1.Incorrect voltage: inspect connection cables and verify there's power
No power
at the connector with DMM
2. Blown Fuse: replace FUSE with exact speci cation
1. Re-insert the HD/USB/TF into the port at the side of the device
Failure to read HD/USB/
2. Select options in audio and video player
TF/audio/video les
1. Long press the headphone power key until the red and blue light blinks
Bluetooth headphone –
alternately, re-pair the headphone
no audio
2. Make sure the display device is paired with only one headphone
3. Check battery charge level of headphone
Attention
1. Do not store the display device wet or humid environment, to avoid re hazard and electrical
damage.
2. Do not attempt to service the device on your own. Please shut down the device and notify BPIN
service immediately. In case the display device needs to be serviced , BPIN authorized service
personnel will be able to handle it
3. Keep the device away from moisture, dust and oil, and do not expose it to direct sunlight.
4. Do not wipe or clean the display device with any harsh or abrasive cleaning agents. Please clean the
Device with a soft cloth.
5. Please keep the device in appropriate environment (storage temperature:-20°C - 65 °C and operation
temperature: -10 °C - 55 °C.
6. Please ensure the display device is installed in an environment that does not affect the functioning of
other devices around it.
7. For safety reasons, please install the display on the front seat headrest with the display screen only
visible to rear seat passengers. In most countries it is illegal and a violation of motoring laws to have
the display mounted on the front dash where moving images are visible to the driver and front
passenger.
8. Power supply: DC 12V
Notice:
The display screen may have some brighter than surrounding spots, this is a natural trait of the screen
and does not mean that the screen has an issue.
BPIN Private Limited
47, Atlanta Society, Nariman Point, Mumbai‐ 400 021. India.
Toll Free: 1800 209 6820 | info@blaupunktcar.in | www.blaupunktcar.in
BP RSE AD 10.6
ANDROID TOUCHSCREEN
Rear Seat Entertainment
1102158106-001
