Summary of Contents for BROHN BRR108 600
- Page 1 Please read this manual carefully before using, and keep it for future reference. User Manual WALL CANOPY RANGEHOOD Model: BRR108 600; BRR108 900; BRR129 900; BRR206B 900...
-
Page 2: Table Of Contents
STAINLESS STEEL SURFACES ......................20 CONTROL PANEL SURFACE ......................20 CHARCOAL FILTERS ........................20 CHANGING A LIGHT GLOBE ...................... 20 TROUBLESHOOTING ..........................22 IN CASE OF EMERGENCY ......................22 TECHNICAL SPECIFICATIONS ......................24 DISPOSAL ..............................26 10 CUSTOMER CARE ........................... 27 web: brohn.com.au... -
Page 3: Package
Ensure that the packaging is securely closed during handling and transportation. Protect from external factors (such as humidity, water, etc.) that may damage the packaging. Take caution while handling and transporting appliance to prevent risk of poor operationdue to possibility of bumps, crashes, drops, etc. web: brohn.com.au... -
Page 4: Unpacking
This instruction manual has been prepared jointly for multiple models. Some of the specifications explained in the manual, may be slightly different or not be included in your appliance. Pay attention to the explanations with illustrations while reading the manual. web: brohn.com.au... -
Page 5: Safety Warnings
Regulations concerning the discharge of air have to be fulfilled. There must be adequate ventilation of the room when the cooker hood is used at the same time as appliances burning gas or other fuels. web: brohn.com.au... - Page 6 Exhaust air must not be discharged into a wall cavity, unless the cavity is designed for that purpose. The exhaust from the cooker hood must not be discharged into any heating flue which may carry combustion products from other sources. web: brohn.com.au...
-
Page 7: Usage Conditions And Restrictions
Incorrect use can result in property damage, injury or death. We assume no liability for misuse of the appliance or noncompliance with these instructions. Only plug this unit into a properly earthed outlet. If in doubt, seek advice from a suitably qualified technician web: brohn.com.au... -
Page 8: Product Overview
P a g e 3 PRODUCT OVERVIEW 3.1 LAYOUT MODEL: BRR108 600 / BRR108 900 web: brohn.com.au... - Page 9 P a g e MODEL: BRR129 900 web: brohn.com.au...
- Page 10 P a g e | 10 MODEL: BRR206B 900 web: brohn.com.au...
-
Page 11: Rangehood Components
1 × User Manual 3.3 OPTIONAL ACCESSORIES Following accessories can be purchased separately via contacting our Customer Service. Carbon Filter Various ducting solutions (rigid ducting, adapters, vents/outlets and elbow bends) Stainless Steel Flue extensions for various ceiling heights web: brohn.com.au... -
Page 12: Installation
4.2 INSTALLATION PREPARATION TOOLS AND MATERIAL REQUIRED FOR INSTALLATION: Duct tape or cable ties Ducting relevant to your installation requirements (including any rigid bends, vents and/or adapters) Drill and/or screwdriver Spirit Level Tape Measure web: brohn.com.au... -
Page 13: Exhaust Way Selection
Avoid sharp 90-degree bends as much as possible. Use 45-degree bends instead wherever possible. Duct to the outside using the shortest duct run possible. Use cylindrical ducting whenever possible. 1. Into the ceiling cavity and then vented through your eaves web: brohn.com.au... -
Page 14: Recirculation / Ductless, Vent Inside Option
To install the carbon filter, the grease aluminum filter should be detached first. Press the lock and pull it downward. Plug the activated carbon filter into the fan motor inlet and turn it in clockwise direction. If the motor requires two filters, repeat the same on the other side. web: brohn.com.au... -
Page 15: Positioning The Rangehood
Set the installation height. Drill 3 holes to install the mounting bracket (hook) onto the wall ensuring that it’s secured in a level position. Tighten the bracket with the screw plug and screw (ST4mm X 30mm). Line up the hood and hang onto the wall bracket hook (See Figure 1). web: brohn.com.au... - Page 16 (ST4mm X 30mm). When finished, fix the inner chimney with the screws (4mm X 8mm) to the inner chimney bracket (See Figure 3). web: brohn.com.au...
-
Page 17: Using Rangehood
Speed increase button For increasing the speed of the fan Speed decrease button For decreasing the speed of the fan. Light button Digital display Fan speed display:"1" for Low speed, "2" for Medium speed, "3" for High speed. web: brohn.com.au... -
Page 18: Using Touch Controls
You will hear a “beep” like noise each time a touch is registered. Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or a cloth) covering them. Even a thin film of water may make the controls difficult to operate. web: brohn.com.au... -
Page 19: Care And Maintenance
CAUTION: The filters should be cleaned every few weeks of use to prevent fat and oil buildup and condensation. We do not recommend washing the aluminium filters in a dishwasher. This can damage the filter and cause discoloration of the filter. Cleaning the filter every month can prevent risk of fire. web: brohn.com.au... -
Page 20: Stainless Steel Surfaces
The LED lights should not require service. If it requires replacement, plsease check below or contact Customers Service for more information. Replacing the bulb: Model BRR108 600, BRR108 900; 60cm/90cm * LED Light* 1. Switch the unit off and unplug the appliance. - Page 21 2. Unplug the LED panel light cable. 3. Unscrew the screws and nuts on the 2 brackets. 4. Replace the LED panel light and screw back on to the brackets. 5. Plug the LED panel light cable back in. web: brohn.com.au...
-
Page 22: Troubleshooting
Re-adjust the installation position, Too long distance between ensuring that the minimum Insufficient suction the rangehood and the distances are observed as per the cooktop building code and relevant standards. web: brohn.com.au... - Page 23 This includes situations where appliances have been tiled in or sealed in with sealant. Please do not disassemble the unit by yourself to avoid any dangers and damages to the appliance, contact the supplier or Customer Service. web: brohn.com.au...
-
Page 24: Technical Specifications
P a g e | 24 8 TECHNICAL SPECIFICATIONS BRR108 600 SPECIFICATIONS Model BRR108 600 Dimensions 600mm × 500mm × 548-1028mm (W × D × H) Extraction 1000m3/hr Control Touch TO01 Speed settings Lighting 2x1.5w Multi Bulb LED light (LE01) - Page 25 Filters filters 220–240 Volts 50Hz Power supply Connects to standard household 10 Amp power point NOTE: Weight and Dimensions are approximate. Because we continually strive to improve our products we may change specifications and designs without prior notice. web: brohn.com.au...
-
Page 26: Disposal
9 DISPOSAL This appliance requires special waste disposal. For further information regarding the treatment, recovery and recycling of this product please contact your local council, household waste disposal service or store of purchase. The packaging materials are recyclable. web: brohn.com.au... -
Page 27: Customer Care
For further information on the appliance, service, spare parts or to obtain dimension and installation information, please contact our customer service or visit website. Please have above information and documents on hands before contacting customer service Phone: 1300 615 001 Email: info@brohn.com.au Web: brohn.com.au web: brohn.com.au...
