Snell FLIR C5 Quick Start

Power Button
AC Power
USB-C
Touch screen

1. MEMORY:

• Memory is internal only. Can be accessed vis USC-C cable for download into computer, or WI-FI / Bluetooth to
Flir Ignite (cloud)
• Gallery can be accessed by the Gallery / Replay button to the right of screen.

2. POWER:

• Battery is internal and not removable. Battery is charged at the USB-C connection.

3. START:

• Turn power on/off at the power button on the top of the unit.

4. FOCUS:

• Is fixed, there is no adjustment.

5. AUTO ADJUST (Level and Span):

• This feature is turned on/off in the Menu Access (three dots lower right of screen). Icon appears as a thermometer,
select by tapping Auto.
6. MANUAL ADJUST (Level & Span):
• This feature is turned on/off in the Menu Access (three dots lower right of screen). Icon appears as a thermometer,
select by tapping Manual (looks like a hand).
• The span values will highlight, highlighted values will be changed by swiping up or down on the scale.
Tap on value to lock or unlock. If both are highlighted, level is adjusted.
If only one is highlighted, span is adjusted.
© 2022 The Snell Group / 322 N. Main St. / Suite 8 / Barre, VT 05641 / 800.636.9820 / www.thesnellgroup.com
Save Button
Setting
buttons
Camera
Gallery
Device
settings
Menu access
(touch screen)
QuickStart
FLIR C5
