ASSEMBLY INSTRUCTIONS
MONTAGE INSTRUCTIES | MONTAGEANLEITUNG | INSTRUCTIONS DE MONTAGE | INSTRUCCIONES DE MONTAJE
NARDO 2 SEATER BENCH
SUNS GREEN COLLECTION
Ⓒ
Ⓕ
*When required
the holes can be closed
by using these dowels
Ⓔ
Ⓓ
ASSEMBLY PARTS
Ⓐ Seat = 1 Pc
Ⓑ Backrest = 2 Pcs
Ⓑ
Ⓐ
ASSEMBLY TOOLS
Ⓒ Bolts M8x20mm = 10 Pcs
Ⓕ Wooden dowel = 10 Pcs
Ⓓ Washer = 10 Pcs
Ø17
Ⓔ Hexa key = 1 Pc
