CARDIOSTRONG CST-CB Assembly And Operating Instructions Manual
Heart rate sensorsmart
For more information, please visit cardiostrong.com, sport-tiedje.com
Summary of Contents for CARDIOSTRONG CST-CB
- Page 1 Assembly and Operating Instructions CSTCB.01.02 Art. No. CST-CB Cardiostrong Heart Rate SensorSmart...
- Page 2 HR Sensor Smart...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety ASSEMBLY- AND OPERATING INSTRUCTIONS General Instructions Scope of Delivery Assembly Assembly of the Transmitter Battery Initial Operation of the Heart Rate Transmitter 2.5.1 Bluetooth Smart 2.5.2 ANT+ 2.5.3 5.3 Khz TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Care and Maintenance of the Textile Elastic Strap... - Page 4 HR Sensor Smart...
- Page 5 With cardiostrong® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data Strap length: 88 cm (suitable for chest: 70-120cm/ 27.5”-47.2”) Battery lifetime (approx.): 300 hours (1 hr/day usage) Battery: CR2032 x 1 pcs (included) Transmission Range: BLE smart and ANT + up to 10 meters; 5.3khz under 80cm Waterproof : IPX 7 Operating temperature:... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. ⚠ WARNING This equipment may not be used by children under the age of 14. Children should not be allowed unsupervised access to the equipment. -
Page 9: Assembly- And Operating Instructions
ASSEMBLY- AND OPERATING INSTRUCTIONS General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. WARNING ⚠... -
Page 10: Assembly
Assembly NOTICE If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. smartphone, tablet or PC). There you have the option of zooming in closer. Please note that the Adobe Acrobat Reader programme must be installed on your end device in order to open the file. - Page 11 Step 3: Adjust the strap length and wrap it around your chest. Insert the clasp to the loop end of the strap and make sure the strap is wrapped properly around your chest. Step 4: NOTICE Do not use vaseline or oils which may insulate the transmitter and make it unable to detect the heart rate signals.
-
Page 12: Assembly Of The Transmitter Battery
Assembly of the Transmitter Battery NOTICE During the insertion of the battery: Make sure that the battery is first pressed against the side contact (mark „+“ facing up) and then pressed into the battery compartment. Slide the battery (CR2032) angled into the battery compartment (shown in Figure 2). Check if the o-ring is already inserted in the battery cover to ensure the battery compartment is water proof. -
Page 13: Initial Operation Of The Heart Rate Transmitter
Initial Operation of the Heart Rate Transmitter This heart rate chest belt has a soft adjustable textile strap which needs to be adjusted to the proper length to get the effective heart rate detection. The BLE smart, ANT+ and 5.3Khz 3 in 1 Heart Rate Transmitter is compatible with versions above IOS 6.0 and Android 4.3. -
Page 14: Ant
2.5.2 ANT+ The 3 in 1 heart rate transmitter is compatible with some devices that are eqipped with ANT+. Go to Device Settings Switch on ANT+ Pair your heart rate transmitter with the device. When you see the heart rate value, it means that the connection is successful. NOTICE Smartphones with embedded ANT+ connection can be used directly but other smartphones will need to use an ANT+ dongle to activate the ANT+ functions. -
Page 15: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. - Page 16 Make sure that bluetooth in the app Bluetooth is only for one- is paired with your product. on-one pairing. Bluetooth / Ant+ is lf the sensor in your product has been not working or not Phone is not equipped paired with your phone’s bluetooth paired with your with Bluetooth smart 4.0 (not from the app’s bluetooth), turn it...
-
Page 17: Care And Maintenance Of The Textile Elastic Strap
Care and Maintenance of the Textile Elastic Strap NOTICE The strap should be dried lying flat, hanging or dripping wet. The strap does not resist soaking , dry - cleaning or bleaching. The textile strap can be washed in a gentle washing programme in the machine at +40°C/104 °F with most common laundry detergents. -
Page 18: Contact
CONTACT TECHNIK TEKNIK OG SERVICE TECHNIQUE & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de �� �� Åbningstider kan findes på... - Page 19 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
- Page 20 Cardiostrong Chest Belt Smart...
