Fracarro SWP524TS Operating Instructions Manual

Fracarro SWP524TS Operating Instructions Manual

Cascadable 5 input switches with active and passive tv gain

Advertisement

Quick Links

SWP508TS-SWP512TS-SWP516TS
SWP524TS-SWP532TS
GB: CASCADABLE 5 INPUT SWITCHES WITH ACTIVE AND PASSIVE TV GAIN.
I:
MULTISWITCH IN CASCATA A 5 INGRESSI CON SEGNALE TV ATTIVO E PASSIVO.
F:
MULTISWITCHS CASCADABLES 5 TV ENTREES AVEC VOIE TERRESTRE ACTIVE ET PASSIVE.
D:
KASKADEN-MULTISCHALTER MIT 5 EINGÄNGEN, MIT AKTIVEM UND PASSIVEM TV-SIGNAL.
I: ISTRUZIONI PER L'USO
GB: OPERATING INSTRUCTIONS
F: INSTRUCTIONS D'EMPLOI
D: BETRIEBSANLEITUNG
