HARDWARE INSTALLATION GUIDE
senseon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Plus and is the answer not in the manual?

Questions and answers

Related Manuals for Senseon Plus

Summary of Contents for Senseon Plus

  • Page 1 HARDWARE INSTALLATION GUIDE senseon.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Components Overview ................p. 3 Reader ..................... p. 4 Controller ....................p. 6 Wireless Components ................p. 7 Wireless Module ................p. 7 Wireless Card Programmer ............p. 7 Wireless Gateway ................p. 7 Hub ......................p. 8 Electronic Locks ..................

  • Page 3: Components Overview

    Cloud, Wireless system activity. Module, and Wireless Card Programmer. Electronic Locks Senseon’s low-profile locks can withstand up to 250 lbs. of force. Senseon Plus uses B-model electronic locks. H ARDWARE INST A LLAT IO N GUIDE I 3...
  • Page 4 2. READER The Senseon Plus Reader scans user/administrator cards, fobs, or other RFID access credentials. You can mount a Reader in a variety of locations. These include a cabinet’s outside surface, subsurface, or a surrounding panel or wall. Determine where you want users to scan cards for access beforehand.
  • Page 5 Subsurface Mounting You can mount a Senseon Plus Reader underneath a cabinet surface if the surface is not metallic. You may use the center or the edge of a cabinet as a reference for the location. NOTE! Material composition, may impact the Reader’s signal strength. It’s recommended a subsurface-mounted Reader be under a surface ¾”...
  • Page 6 3. CONTROLLER The Controller is the “brain” of the Senseon Plus System and resides inside the cabinet. One Controller supports up to 10 Hubs. You can mount a Controller by screw attachment or adhesive tape (included). The Controller holds audit trail data and system configurations.
  • Page 7 4. WIRELESS COMPONENTS Senseon Plus uses three wireless components. The Wireless Module sends and receives information from the Controller to the Cloud. The Wireless Card Programmer adds and scans cards. The Wireless Gateway serves as the communication cross-point between Cloud, Module, and Card Programmer.

  • Page 8: Hub

    5. HUB The Hub is the “heart” of the Senseon Plus System. Hubs connect to the Controller, Power Supply, e-locks, or other Hubs. All connected Hubs distribute power and unlock signals amongst each other. A Senseon Plus Controller supports up to ten Hubs.

  • Page 9: Electronic Locks

    6. ELECTRONIC LOCKS Senseon Plus electronic locks (e-locks) secure or unlock openings via an electronic signal from the Hub. A built-in sensor monitors the status of a connected opening. The e-lock reports status, defined as “secure” or “unsecure”, to the Controller.
  • Page 10 MOUNTED on a horizontal partition within a MOUNTED mounted within a FACE FRAME FRAMELESS cabinet. cabinet. An example of a cable route between a Senseon Plus Hub and a 10EL. H ARDWA RE INST A LLA TIO N GUIDE I 1 0...
  • Page 11 An example of a standalone e-lock mounted An example of a standalone e-lock mounted VERTICALLY behind a drawer. HORIZONTALLY behind a drawer. Example of standalone e-lock mounted An example of a pair of standalone e-locks HORIZONTALLY below a drawer (alternate view). mounted VERTICALLY behind a wide drawer.

  • Page 12: Slides

    7. SLIDES Some models of Senseon electronic locks come equipped with Accuride premium drawer slides. Below are blueprint images for the 38EL and 3135EL slides. For more information, including step-by-step installation, please refer to the downloadable technical sheets under “Technical Documentation” located on the Senseon Support Page.

  • Page 13: Cables & Connections

    8. CABLES & CONNECTIONS Cable Name Cable Color Module-to-Controller (36 in.) Reader-to-Controller (36 in.) Reader-to-Controller Ext. (12 in.) Reader-to-Controller Ext. (24 in.) Hub-to-Lock (12 in.) Hub-to-Lock Extension (12 in.) Hub-to-Lock Extension (24 in.) Hub-to-Lock Terminator (3 in.) Hub-to-Hub Connect (12 in.) Hub-to-Hub Connect (24 in.) Module-to-Controller Extension (12 in.) Module-to-Controller Extension (24 in.)

  • Page 14: Power Supply

    9. POWER SUPPLY The Power Supply provides the electrical power to run the Senseon Plus system. The Power Supply connects to the bottom of any Hub in the fixture via the Power Adapter. You can mount a Power Supply by screw attachment with holder.

  • Page 15: Controller Serial

    10. CONTROLLER SERIAL Use this page to enter Controller information for reference. HA RD WA RE INST A LLA TIO N GUIDE I 15...

  • Page 16: Channel List

    11. CHANNEL LIST Use this page to enter Channel list information for reference. Controller #1 Channel # Channel Description Controller #2 Channel # Channel Description HA RD WA RE INST A LLA TIO N GUIDE I 1 6...
  • Page 17 Controller #3 Channel # Channel Description Controller #4 Channel # Channel Description Controller #5 Channel # Channel Description HA RD WA RE INST A LLA TIO N GUIDE I 1 7...
  • Page 18 Have questions? senseon.com (800) 688-8242 Please contact Senseon Technical Support at Senseon is a trademark of Accuride International, Inc. I 12311 Shoemaker Ave., Santa Fe Springs, CA 90670 | ©2022 Accuride International, Inc. (Ver. 3.0) ®...
