USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR ELECTRICAL
Dear User,
we are sincerely grateful to you for purchasing one of our products.
We are sure that the appliance modern, functional and easy to use, built with the finest materials
and components will satisfy all your needs.
We would ask that you read the instructions within this booklet very carefully so as to enable you
to obtain quality results from the outsets.
The appliance must be installed only by a qualified electrician in compliance with the
instructions provided. The manufacturer declines all responsability for improper installation.
MODELS: PT1356 - PT1358
The manufacturer is not responsible for any transcription errors or misprints contained in this handbook and,
furthermore, reserves the right to make any modification on the products, which might be deemed
necessary or usefull, this being in the user's interest, without altering their basic operating or safety
features. This cook top was designed to be used exclusively as a cooking appliance: any other use
(such as heating rooms) is to be considered improper and dangerous.
BUILT-IN HOT PLATES
COD. 04083DN - 16.07.2019
Advertisement
Table of Contents
Related Manuals for Airxcel PT1356
Summary of Contents for Airxcel PT1356
- Page 1 The appliance must be installed only by a qualified electrician in compliance with the instructions provided. The manufacturer declines all responsability for improper installation. MODELS: PT1356 - PT1358 The manufacturer is not responsible for any transcription errors or misprints contained in this handbook and, furthermore, reserves the right to make any modification on the products, which might be deemed necessary or usefull, this being in the user’s interest, without altering their basic operating or safety...
- Page 2 WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe...
- Page 3 DESCRIPTION OF THE HOT PLATES TYPE: PCZ VTC 30 TYPE: PCZ VTC 6077 MODEL: PT1356 MODEL: PT1358 The appliance has 2/4 heating elements of different sizes and power levels. The heating elements are of the Hi-light type, which come on after a few seconds, and the heat is adjusted using the controls on the front panel, from a minimum of 1 to a maximum of 9.
- Page 4 DESCRIPTION OF THE HOT PLATES DESCRIPTION OF THE FRONT PANEL CONTROLS MODEL: PT1356 1 - ON/OFF button cooking zone 2 - Capacity level display (0 - 9) 4 - Safety lock button 5 - Button + increase power level 6 - Button – decrease power level...
- Page 5 DESCRIPTION OF THE HOT PLATES WARNING FOR USE: ► the appliance is built to perform the following function: cooking and heating food. Every other use must be considered improper. ► Never use this appliance to heat the environment. ► Do not attempt to change the technical characteristics of the product because it can be dangerous.
-
Page 6: Instructions For The User
When cook-top will be connected to power supply, a long beep will be hear. All leds and displays in the Touch Control will be turned ON during 4 seconds. After an auto adjust period, cook-top will show software version during 10 seconds or while no touch any key. MODEL: PT1356 ARRANGEMENT OF THE HEATING ELEMENTS CENTRAL REAR... -
Page 7: Child Lock Option
DESCRIPTION OF THE HOT PLATES INCREASE/DECREASE POWER LEVEL – With a short press on ‘ ’ or ‘ ‘ keys, increase or decrease power in the selected zones digit: 0 - 1 - 2 - 3... 9 - P. – ●... - Page 8 DESCRIPTION OF THE HOT PLATES Power Max. time on level (hours) AUTOMATIC SAFETY OFF If the power level is not changed during a preset time, the corresponding heater turns off automatically. The maximum time a heater can stay on, depends on the selected cooking level.
-
Page 9: Display Of Errors
DISPLAY OF ERRORS ERRORS/ALARMS The corresponding heater display alternates between two characters depending on the Error. Heater All heater Event Description Action display display (Visualization priority order) ------------- FalloONOFFLevel Security Key Error App Off (*) ------------- FalloSw Security Sw Error App Off (*) ------------- FalloKeySensError... - Page 10 MODEL: PT1358 USER INSTRUCTIONS Every time that any symbol is pressed, it is confirmed by a check beep. The functions of hobs that use this type of technology are activated by gently pressing the serigraph symbols on the surface of the hob. The first time the hob is connected to the electricity supply, an operating check will be run automatically and all the warning lights will come on for several seconds.
- Page 11 HEAT-UP FUNCTIONS This function takes the cooking level to maximum power for a defined time. Activate the heat-up function After removing the control panel lock (pressing the symbol for 2 seconds), switch on the hob by pressing the button for a few seconds. Use the button to activate the heating element required (the indicator flashes) then use the buttons to adjust the cooking level to 9 (maximum) and press again the...
-
Page 12: Residual Heat
FUNCTIONS COMMON TO ALL MODELS ): this function prevents the hob from being switched on accidentally (childproof Lock function ( safety device). To activate it, the sensor must be pressed for about three seconds (the warning light comes on). It is not possible to operate the heated areas when is active. -
Page 13: Troubleshotting
TROUBLESHOTTING TROUBLESHOTTING If you encounter a problem, it frecuently will merilly be something minor. So, before you call customer service, consider the following suggestions and instructions: Check the condition of the fuses/circuit breakers The cooktop is not working your location. Check you are experiencing a power failure. - Page 14 TROUBLESHOTTING Heater Fault Action display Wait until temperature goes down. If messa- Touch control temperature ge persist when temperature reaches an envi- sensor can be damaged. ronment value, call after-sales service. Excessive sensitivity See if cook-top is mounted correctly. Be sure on any key.
-
Page 15: Guide To Cooking
3) GUIDE TO COOKING The table below indicates the power values that can be set and the type of food to prepare is shown next to each one. The values can change according to the amount of food and consumer preference. Power and dimensions Position for regulation Possible... -
Page 16: Electric Hob
CLEANING Before any cleaning operation, disconnect the - Marks of liquid, overflowed from the pot, can be appliance from the electric circuit. removed using vinegar or lemon. - Pay attention to not let fall sugar or element 4) ELECTRIC HOB with sugar. -
Page 17: Installation
INSTALLATION TECHNICAL INSTRUCTIONS 5) INSERTING FOR THE INSTALLER After having cleared out all the packing Installation, transformations and maintenances components, make sure of the integrity of the below listed, may only be carried out by a appliance. competent technician. Please keep children away from all packing The appliance must be installed following the elements (carton, polystyrene, nails...). - Page 18 INSTALLATION 6) FIXING WARNINGS! A special sealing strip underneath the hob for damage. Make sure it is correctly positioned with no Be aware that the glue that join the laminated gaps; it avoids any water infiltration. To fix in the right plastic to the furniture, has to resist to way the strip, please, respect the following temperature not below 150 °C, to avoid the...
- Page 19 INSTALLATION MODEL: PT1356 FIG. 8 FIG. 7 POSITION HOOKS ON THE BOTTOM...
- Page 20 INSTALLATION MODEL: PT1358 FIG. 9 FIG. 10 POSITION HOOKS ON THE BOTTOM...
- Page 21 - EcoDesign (ERP). respondences: Letter L (Live) = cable brown colour; Letter N (Neutral) = cable blue colour; MODEL: PT1356 Earth symbol = green - yellow wire. - The input cable has to be located so that never The product complies with IEC/EN 61000-3-11.
-
Page 22: Maintenance
MAINTENANCE Before doing any action, disconnect the longer than "live" ones, and must respect the appliance from the input power. cautions paragraph "ELECTRICAL CONNECTION". 8) COMPONENTS SUBSTITUTION To reassemble the appliance repeat the inverse To replace the components lodged in the internal process. -
Page 23: Technical Data
TECHNICAL DATA POWER OF ELECTRICAL COMPONENTS electric cooking* Denominations (Wh/kg) 1200 187,0 Radiant electric heating element Ø 14,0 cm "Hi-light" 1800 188,5 Radiant electric heating element Ø 18,0 cm "Hi-light" *ECelectric cooking: Energy consumption per kg calculated according to Regulation (EU) 66/2014. MODEL 2 HEATING ELEMENTS (30) (2 “HI-LIGHT”) -
Page 24: Technical Assistance And Spare Parts
TECHNICAL ASSISTANCE AND SPARE PARTS This appliance, before leaving the factory, has been carefully tested and regulated by expert and specialized personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention.
