- Page 1 User Guide SPOTON USER GUIDE...
- Page 2 Warnings: There is no containment system, including a residential fence or the SpotOn GPS Fence, that can contain all dogs 100% of the time. Some dogs are very smart and can escape any containment. All containment systems can break or malfunction.
-
Page 3: Table Of Contents
B. Set vibration feedback ....21 Using SpotOn ........22 Check collar status . -
Page 4: Getting Started
GPS fence that you create. Build custom fences anywhere you wish—in your yard and beyond. You’ll use the app to set up SpotOn and create your first fence. Simply walk the boundary with the collar in hand and SpotOn automatically creates the fence. - Page 5 GPS fence. Plus, see your dog’s location —any time, from anywhere—in the SpotOn app when you have a cellular signal.* And if your dog ever leaves the GPS fence area, you’ll get notified on your phone.
-
Page 6: What's In The Box
What’s in the box SPOTON USER GUIDE... -
Page 7: Fit The Collar
15 pounds or more and have a neck size between 10 inches and 26 inches. Fit SpotOn to your dog like a regular collar. Use the adjustable strap so it fits snugly but lets you comfortably fit two fingers between the collar and your dog’s... -
Page 8: Setup
Setup STEP 1: Set up the collar and app A. Gather the items you’ll need • SpotOn collar • Wall charger • Charger cable • Charging base Set aside the other accessories for now. B. Turn the collar on Press and hold the Power Button until the LED starts flashing white. - Page 9 You can check the charge status by quickly pressing the power button while SpotOn is in the charger. • Flashing green = charging • Solid green = fully charged D. Download our app...
-
Page 10: Step 2: Create And Test A Fence
FENCE BOUNDARY When you create a fence, SpotOn builds in an alert and warning zone about 10 feet inside the boundary that you walk. As your dog enters this zone, SpotOn makes a series of tones. You’ll train your dog to understand these tones are the fence boundary. - Page 11 Allow for fence boundary drift SpotOn is more accurate than the GPS on your smartphone, but like all GPS systems, it can be affected by buildings, hills, heavy tree cover, the number of satellites detected, and other factors. This means your...
- Page 12 80 feet wide at the narrowest point. Minimum distance from roads and hazards Set boundaries at least 15 feet away from roads or any other hazardous areas. SPOTON USER GUIDE...
- Page 13 For a fence that only covers the backyard be sure to run the fence boundary along the front and sides of the house. This allows your dog to enter the house through the back door without being corrected. SPOTON USER GUIDE...
- Page 14 Hit an obstacle you can’t walk through, like a pond or thick brush? Using the app press Pause to manually drop your next fence post, go around the obstacle and then press Resume. SpotOn will snap a fence line between fence posts.
- Page 15 Using the app start at one boundary point, press Pause and then walk (or drive) to the next point. Tap Resume and the system will snap a fence line between fence posts. TIP: The app will automatically inform you when you have used half of your fence posts. SPOTON USER GUIDE...
-
Page 16: Create The Fence
As you walk SpotOn automatically places one virtual fence post about every 5 feet. You don’t need to walk in straight lines—the boundary can be curved if needed. And if you stand still for a moment SpotOn will wait until you move. -
Page 17: Complete And Save The Fence
C. Complete and save the fence When you approach the starting point the app will automatically inform you to tap Finish. SpotOn will complete the fence and then ask you to name it. Create additional fences Tap the Fence section in the app and tap Add Fence. -
Page 18: Test The Fence
When testing, if you exit the fence and then return, you’ll notice the collar doesn’t vibrate or issue the warning tone because SpotOn never corrects a dog for coming home. You will hear the alert tone upon re-entry. You’ll train your dog to understand the alert tone means he’s within his boundary. - Page 19 You can use the static contact tester to verify static correction is working. Place the tester over the static contact points and walk across your fence boundary. The tester will glow when static correction is applied. SPOTON USER GUIDE...
-
Page 20: Step 3: Train Your Dog
Check out the app for more training information. TIP: Need some extra training support? Contact training@spotonfence.com to learn more about a remote training session with one of our SpotOn expert trainers. SPOTON USER GUIDE... -
Page 21: Set And Test Static Correction
B. Set vibration feedback Vibration feedback provides an alternative to static correction at the fence boundary, or an extra level of protection used with static correction. Go to Collar Settings in the app to turn vibration on or off. SPOTON USER GUIDE... -
Page 22: Using Spoton
You can check the status on the collar or on the app. Check collar status Press and immediately release Power Button. The LED Status Indicator will turn on for a few seconds, then turn off. Power Button LED Status Indicator SPOTON USER GUIDE... - Page 23 Move outdoors and Fence active, wait a few moments Flashing White but no GPS signal. for SpotOn to get a GPS signal. Fence may be inactive. Tap Dog in the app to select your fence. Collar may have a low Solid Red System not ready.
-
Page 24: Battery Information
To turn the system off, press and hold the Power Button until the LED status indicator turns off. SPOTON USER GUIDE... -
Page 25: Keep Tabs On Your Dog - Cellular Plan And Tracking
(both your phone and SpotOn must be in an area with good cell service). • A 90-day free trial on one- and two-year plans offers extra protection as your dog learns the fence. -
Page 26: Tree Coverage (Forest Mode)
See the profile section in the app for details. Care and maintenance SpotOn is waterproof to IP67 standards. Before using it in wet environments, make sure the collar doesn’t have any nicks, cuts, cracks, or other damage that might let water inside. Rinse the collar with tap water and pat dry after exposure to dirt, mud, saltwater, or pool water. -
Page 27: Troubleshooting
If you don’t have a cell plan, visit www. activate tracking spotonfence.com/pages/subscription to subscribe. or refresh my dog’s If you have a cell plan, make sure you have cell location. service. Check the app for more information. SPOTON USER GUIDE... - Page 28 Fence may be inactive, or collar may have a is red low battery. The collar LED Move outdoors and wait a few moments for SpotOn status indicator is to get a GPS signal. Connect to the collar and see flashing white app for details.
-
Page 29: Have A Question? We'll Fetch The Answer
Have a question? We’ll fetch the answer! You can reach us by: Call us at (603) 488-1504 or Email at support@spotonfence.com. You can also browse the help section in our app. SPOTON USER GUIDE... - Page 30 The SAR limit is 1.6 watts per kilogram in countries that set the limit averaged over 1 gram of tissue. During SAR testing, SpotOn radios are set to their highest transmission levels and placed in positions that simulate typical worst-case use conditions when near the body of a person.
- Page 31 Terms of Use This product, associated mobile application, and website are owned by OnPoint Systems, LLC (D/B/A SpotOn Fence). By using any of them, you agree to the terms and conditions outlined at https://www.spotonfence.com/pages/terms-of-use. Please read these terms carefully.
- Page 32 WE ARE PROUD TO DEVELOP, ASSEMBLE, SUPPORT & SERVICE SPOTON IN NEW HAMPSHIRE. SPOTON USER GUIDE © 2022 SpotOn Fence. All rights reserved. SOF-130 Rev 1.
Need help?
Do you have a question about the GPS FENCE and is the answer not in the manual?
Questions and answers
I got 2 gps fences. A medium and a large. How can I tell which is which
You can identify the medium and large SpotOn GPS Fence collars by their sizes. The medium collar fits neck sizes between 12-18 inches, while the large collar fits neck sizes between 19-26 inches. If the dog's neck size falls between sizes, it is recommended to size down.
This answer is automatically generated
How do I set up an inactive zone
To set up an inactive zone (Keep-out zone) on the SpotOn GPS Fence, follow these steps:
1. Open the SpotOn app and select the fence you want to modify.
2. Tap "Edit Fences" and then "Zones."
3. The app will create a copy of the fence.
4. Expand the fence boundaries if needed to allow space for keep-out zones.
5. Adjust or remove unnecessary fence posts.
6. Drag and position the posts to define the keep-out zone.
This feature allows you to create restricted areas within the fenced boundary where your dog cannot enter.
This answer is automatically generated
I received a warning about the geoelectrical field yesterday and today I can't get my collar to turn on. Advise please and thank you! PS I love my dogs fence:)
How to deactivate account so I can be added to friends and family setting. Error message says email address already linked to account.
