- Page 1 HEATIZON SYSTEMS RADIANT HEATING AND SNOW MELTING SYSTEMS Self Regulating Cable ® ® Cozy Heat is a Registered Trademark of Heatizon Systems © 2015 Heatizon Systems www.heatizon.com 01-15...
-
Page 3: Table Of Contents
Table Of Contents: Product Overview………………………………………………………………..…………………….………….1 Cable Specifications……………………………………………………………………………………………. 2 Cable Diagrams………………………………………………………………..……………….…………...…….3 Warnings and Reminders………………………………………………………………….…………………….4 Design and Installation………………………………………..…………………………………………..…….5 Resistance Recording Page……………………………………………………………………………………10 Warranty…………………………………………………………………..……………………………..………..11... -
Page 5: Product Overview
Cozy Heat® SR Specifications Watts per linear foot at Note: It is important that Cozy Heat® be in- 32° in iced water stalled only by a qualified individual who is famil- iar with the proper sizing, installation, construc- Cable type Self Regulating (SR) tion and operation of floor warming systems and the hazards involved. -
Page 6: Cable Specifications
® STEP 2 COZY HEAT SR SPECIFICATIONS PERFORMANCE RATINGS POWER OUTPUT CURVE Watts per linear foot at 32° in iced water Cable type Self Regulating (SR) Copper bus wire 22 AWG Min 12GM Maximum maintenance 185ºF (85ºC) temperature Maximum intermittent 212ºF (100ºC) exposure temperature T rating: T5... -
Page 7: Cable Diagrams
Cozy Heat® SR Cable System Heatizon Relay Panel /Contactor Power Distribution Panel Panel or Junction Box Activation Device Power Cable/Ground Wire Cold Lead (One) Junction Box Cozy Heat® SR Heating Element Cozy Heat® SR Cable... -
Page 8: Warnings And Reminders
In the event the heat load required for space heating is great- with the NEC in the US. er than 15 Watts per square foot, call Heatizon Systems at 801-293-1232 prior to installing. Floor warming applications Please contact Heatizon Systems with additional are typically satisfied with 8 to 12 Watts per square foot. -
Page 9: Design And Installation
Systems recommends 3” to 9” spacing as required to satisfy the heat loss calculation for spacing and 8 to 15 watts per square foot for floor warming, see an authorized Heatizon Systems distributor for more details. Note that the minimum distance between the cables cannot be less than 1 inch. - Page 10 Design and Installation STEP 4 LAYOUT AND PREPARE FLOOR SENSOR If a floor temperature sensor is being used, mark the sensor position between two Cozy Heat® Heating Element runs, ap- proximately 10 inches away from the wall, and as close as possible to the thermostat. STEP 5 INSTALL SENSOR CONDUIT When using a conduit for an in-floor sensor, install...
- Page 11 Always avoid walking on the heating element. Never cut or damage the insulator on Cozy Heat® SR Heating Element. In the event Cozy Heat® Heating Element is damaged, contact Heatizon Systems at 801-293-1232 for repair options and do not cover.
- Page 12 Design and Installation STEP 9 APPLY THE CEMENTITOUS MATERIAL Ensure that the optional sensor conduit or that the in-floor sensor have been properly installed before proceeding beyond this point. For stone and tiling applications For all other applications Proceed with the installation of the tiles by covering the Cozy Proceed with the applying or self-leveling cement, or other Heat®...
- Page 13 ® technical support @ 801-293-1232. For Warranty claims, please return the entire length of Cozy Heat® to Heatizon Systems with requested forms (RMA, Warranty, Resistance Recording), with the end termination and power termination connections intact, for evaluation prior to replacement.
-
Page 14: Resistance Recording Page
Resistance Recording Page Use a Digital Multi Meter to measure the resistance of the Cozy Heat® Heating Element, and compare it to the expected resistance for the product purchased. Cozy Heat® SR Cable should be tested using a megohmmeter, set at 2500 VDC. The measured value should not be less than 20 Megohms. Record all test results below. -
Page 15: Warranty
Heatizon Systems Cozy Heat® SR Warranty Heatizon Systems warrants Cozy Heat® Heating Element to be free from defects in material and workmanship for a period of ten (10) years and Acti- vation Device(s) for a period of one (1) year. Such warranty periods shall commence on the date of shipment by Heatizon Systems. - Page 17 Mail: Heatizon Systems 4137 South 500 West Murray, UT 84123 Phone: (801) 293-1232 Toll Free: (888) 239-1232 Fax: (801) 293-3077 Email: info@heatizon.com Website: www.heatizon.com...
